Portable Micromanometer
MT is an innovative product combining the elegance and prestige of the BEINATs.r.l brand with the
versatility of a multi-functional instrument.
It offers two products in a single appliance:
a pressure gauge, thermometer.
Its main use is to assist technicians carry out their work, both during the installation of new systems
and the inspection of existing ones.
T h ermo meter
Temperature is measured using a built-in, hidden probe and detected from -50 °C to +100 °C, with
0.5 °C resolution.
Pressure Gauge
It 'a differential portable compact pressure gauge easy to use. The accuracy and autonomy make this
an indispensable tool for testing and control of heating systems.
It is calibrated with sophisticated testing machines, so its measurement is very precise and is also
calibrated example for:
Pressure of gas mains; Gas pressure to burner nozzles; Flue efficiency.
F i r m w a r e .
User guide
Ver sione 3 .1
Firmware Version 1.0
Conformity EMC EN50270
Thank you for choosing the BEINAT S.r.L. digital tool, model MT.
This manual was designed to help you obtain the best results and efficiency from the product.
Important Note
Read these instructions carefully before use and always keep them within hands reach while using the
instrument.
The illustrations and texts shown on the screens in this manual may differ from those actually displayed
Temperature Gauge
Pressure Gauge mm H
Belonging
MT
O - mbar
2
Advertisement
Table of Contents
Related Manuals for BEINAT MT
Summary of Contents for BEINAT MT
- Page 1 Belonging Portable Micromanometer MT is an innovative product combining the elegance and prestige of the BEINATs.r.l brand with the versatility of a multi-functional instrument. It offers two products in a single appliance: a pressure gauge, thermometer. Its main use is to assist technicians carry out their work, both during the installation of new systems and the inspection of existing ones.
- Page 2 Do not allow it to get wet. The MT is not waterproof and can be seriously damaged if immersed in water or exposed to high levels of humidity. Do not drop it.
- Page 3 Pressure Battery charger View from above View from below Button functions MT On/Off button. To turn the instrument on or off, press the button for 5 seconds PRESSURE GAUGE Function. The instrument can display 2 scales: one in mmH O and the other in mbar, Keep the “Press”...
- Page 4 Pressure Gauge Function Components and Commands Pressure Gauge Display Press+ Press - 99.9 Measurement display: 99,9 mmH O maximum Measurement display: 150 mbar. m ba r Press Temp Battery charger status display The display depicts a battery. When the battery is charged the figure is completely black and as it is used it becomes white.
- Page 5 Check the battery is charged. If not, recharge it. The battery is not recharging. Check voltage is arriving from the power supply. In the event other problems arise, directly contact a specialist and/or authorised technician or your BEINAT S.r.l. dealer. Page 5...
- Page 6 Calibration The MT digital instrument leaves the factory with a testing and calibration certificate. Such calibration corresponds to that declared by the test instrument, according to international standards. N.B. The test instrument is kept in the manufacturing plant. Measurement uncertainty is assessed as “category B”...
-
Page 7: Technical Specifications
These operations must be carried out in compliance with the methods described in this manual. Remember measurements taken with batteries in need of recharge can give false measurements CERTIFICATE OF CALIBRATION pressure gauge MT Instrument: Digital pressure gauge MT Version: V. - Page 8 The BEINAT S.r.L. company is not liable for possible damage, direct or indirect, to people, animals, or things; from product faults and from its enforced suspension of use.
