TECHNICAL – INSTALLATION MANUAL
PRELIMINARY DOCUMENTATION
Recommendations
1.
Use only original spare parts and consumables supplied by Tema Telecomunicazioni Srl for this equipment. The company shall
not be held responsible for any damage caused by the use of materials that they have not supplied.
2.
The device has been carefully manufactured and tested. In any case, the product is not recommended for use in situations in
which incorrect operating may result in damage to persons and/or property.
3.
We recommend that you carefully read all this manual before starting to use the device.
4.
Do not expose the device to sunlight and protect it from sources of heat, dust, humidity and chemical agents.
5.
This manual is the property of Tema Telecomunicazioni Srl and any duplication and reproduction, even partial, as well as
storage on any type of media is forbidden without written permission from Tema Telecomunicazioni Srl.
Revision
Date
Revision reason
6
14/07/2010
Update
MAS-DIAL112-REV06EN
TEMA TELECOMUNICAZIONI S.r.l.
Telecommunications - Electronics
DIAL-112
GSM Gateway Voice Interface
for ISDN BRI
Version HW 1.0 - Version SW 1.11
Made in Italy by TEMA TELECOMUNICAZIONI S.r.l.
Prepared
GBC,MM
Checked/Approved
FL
Page 1 of 35
Advertisement
Table of Contents
Summary of Contents for Tema Telecomunicazioni DIAL-112
- Page 1 Do not expose the device to sunlight and protect it from sources of heat, dust, humidity and chemical agents. This manual is the property of Tema Telecomunicazioni Srl and any duplication and reproduction, even partial, as well as storage on any type of media is forbidden without written permission from Tema Telecomunicazioni Srl.
- Page 2 Via C. Girardengo, 1/4 - 20161 MILANO dichiara che il prodotto: Interfaccia GSM Gateway voce – GSM Gateway Codici: DIAL-112 nelle versioni 1-2 SIM è stato costruito in conformità alle seguenti normative: SICUREZZA EN 60950-1 EN 55022...
- Page 3 GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL IMPORTANT INFORMATIONS REGARDING THE RECOVERY AND RECYCLING OF THIS ELECTRONIC DEVICE The crossed-out wheeled bin symbol below indicates that this electronic equipment is intended to be disposed in a separate collection and not in an unsorted municipal waste, in order to provide for the treatment of WEEE (Waste Electrical and Electronic Equipment) using best available recovery and recycling techniques.
-
Page 4: Table Of Contents
GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL TABLE OF CONTENTS PAGE INTRODUCTION OF GATEWAY DIAL-112................6 CHARACTERISTICS OF DIAL-112 ..................7 PARTS COMPRISING THE SYSTEM (PACKING LIST) ............8 TECHNICAL SPECIFICATIONS ....................8 DESCRIPTION OF THE DEVICE ....................9 5.1. F .............................. - Page 5 GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL REMOTE PROGRAMMING....................31 10.1. ISDN ) ..............31 OCAL PROGRAMMING FROM A DIRECT CONNECTION 10.2........................32 EMOTE PROGRAMMING 10.2.1..........32 ABLES OF ADJUSTABLE PARAMETERS VIA REMOTE LOCAL PHONE 10.2.2..................34 ELAY DRIVE FOR REMOTE CONTROL 10.2.3.
-
Page 6: Introduction Of Gateway Dial-112
GSM line. The unit has a NT port for ISDN attach and double GSM module. Using DIAL-112 as the default output interface for all calls directed to one or more telephone prefixes selected by internal... -
Page 7: Characteristics Of Dial-112
Access to the module for local programming via DTMF Services for inbound calls (converted from GSM to wired line) DIAL-112 receives calls from the GSM network and reroutes them to the PBX (or telephone) in wired line ISDN mode. Moreover: •... -
Page 8: Parts Comprising The System (Packing List)
GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL 3. PARTS COMPRISING THE SYSTEM (PACKING LIST) DIAL-112 system consists of the following parts: • A DIAL-112 device • An external power supply with 12V – 1A output • Two external antennas with 2.5 meter cables •... -
Page 9: Description Of The Device
GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL 5. DESCRIPTION OF THE DEVICE 5.1. Front view ISDN LINES 1-2 SIM CARD SLOT SIM CARD SLOT ANTENNA STATUS CONNECTORS 5.2. Rear view TE PORT TO THE POWER NT-BRI SIDE ONLY NT PORT TO THE... -
Page 10: Installation And Diagnostics
GSM telephone. 6.1. Installation of the DIAL-112 unit In addition to resting on table, a desktop or shelf, the DIAL-112 unit can be wall-mounted, using the appropriate slots located on its rear panel. To do that proceed as follows: •... - Page 11 This method of connection requires that DIAL-112 is related to an external ISDN line (ISDN port TE) of the PBX: in other words, DIAL-112 has the same role of a new NT port. From the perspective of the PBX, there is no difference between the external lines available, and between one or more BRI lines existing and the new BRI attack system offered by the DIAL-112 that goes to be installed.
-
Page 12: Operational And Diagnostic Indicators
6.3. Operational and diagnostic indicators When DIAL-112 is correctly connected and powered, the LEDs signal the status of the system in a simple, effective manner. For each GSM section, the yellow LED “GSM” has diagnostic purposes, and the way it blinks depends on the GSM engine onboard (see next page for details). The built-in modules now will registrate itself to the GSM network. -
Page 13: Pc Connection
GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL Meaning of the LED “GSM” (yellow): Slow flashing Stand-by status of the line, SIM correctly registered and no ongoing conversation Quick flashing Call or conversation in progress SIM not inserted or not yet registered 6.5. - Page 14 GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL Make sure you have inserted the supplied CD in the CD-ROM reader of your PC, set the option ® "Search removable media” and click "Next". Windows will find a suitable driver to install: Pressing "Finish", you will be prompted to install the driver for the virtual serial port:...
- Page 15 GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL Now, a virtual serial port has been added to your system. Since the device is not equipped of a video or a keyboard, for programming is necessary to connect to the new COM port a terminal ANSI emulator set at 115,200 BPS.
- Page 16 If everything was done correctly, confirming by the OK button and pressing <enter>/<esc> few times, then the main form of DIAL-112 will appear. If the mask appears to be confused, because of used characters of program' s emulation, please choose the option "Character" from "View" menu: From the selection mask choose the font type "Terminal"...
-
Page 17: Services
PBX phones to one or more mobile telephone line prefixes. If the PBX does not have the function of LCR, you can set a code selection where the DIAL-112 ISDN attack is linked, before the phone number every time you want to use DIAL-112 as an output gateway. -
Page 18: Inbound Call Gateway
In its basic function DIAL-112, when receives a direct call to internal GSM module, diverts the call to the PBX ISDN line; if you receive the caller identification it will be send by DIAL-112 to PBX so it can appear on the phone display. After the answer, the caller and the called are in communication. -
Page 19: Cli Presentation Service Associated To The Individual Prefixes Or Numbers
In detail, DIAL-112 automatically performs these steps: • When from the PBX is making a call to a GSM module and it does not answer, DIAL-112 stores in its own large callback table the association between internal number caller and called. •... -
Page 20: Sms Callback Service
7.11. Module access for remote programming via GSM Call the number of the SIM card inserted in DIAL-112, wait for someone to answer on the downstream line and in the first 30 seconds of conversation dial ### (3 pound) + programming password (default is 1111, can be modified by the user, see paragraph 8.1). -
Page 21: Pc Programming
GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL 8. PC PROGRAMMING This is the main form of the program which is accessed just made the connection to the PC and the terminal via USB. To choose any function of the program, simply press the letter that appears on the left menu (for example, "C"... -
Page 22: General Configuration
SIM in a balanced mode • Follow ISDN-BCH: in this mode, if from the PBX arrives a call from the B-channel 1, DIAL-112 uses the GSM module 1, if the call comes from the B-channel 2, will use the GSM module 2. - Page 23 PBXs. • Dial tone: choice of dial tone that DIAL-112 sends when the PBX commits one of his lines. It is possible to choose from 0 (no tone), 1 (alternate urban type), 2 (continuous tone), 3 (alternate / continuous) •...
-
Page 24: Gsm Configuration
Operator: code of the network to be used for the registration of the module. If you do not put anything in the form, DIAL-112 tries to sign up with your manager on the basis of the SIM and if not found (for lack of coverage) is in roaming with the operator, which has the strongest signal. -
Page 25: Prefix And Numbers
”33” while the second will be used for outgoing calls to numbers starting with “34”. If the compound is not part of prefixes, DIAL-112 indiscriminately use the first module available 8.3. - Page 26 3351234567 for mobile phones and 0658237920 for a user of Rome, etc. IMPORTANT NOTE: DIAL-112 considers the number entered as a PREFIX having length up to 6 digits. Otherwise, 7 digit numbers will be considered as phone numbers. These considerations are taken into account in the process of compiling the table.
-
Page 27: Alarms
(free or low cost calls) made available by the operator for outgoing calls (according to the choosen contract). DIAL-112, in this case, take account of minutes of use for each SIM card (regardless of the number called) to see if the total time of call exceeds your set. In this case you can decide whether to lock the device, continue to make calls (it is still shown the time of use of SIM), or send an SMS alert. - Page 28 The device is locked when at least one of two SIM card runs out of free credit (to avoid that when DIAL-112 is committed by an outgoing call, it can be used for a second call even if the credit for the second SIM card is full ), but the software makes sure that both the SIM being used to its maximum (always choosing the SIM which has greater residual traffic).
- Page 29 GSM module that will be used (DIAL-112 will be use the SIM card with normal contract if the one with free minutes is in use, and will use the SIM card with free minutes, even if exhausted, if the one with normal contract is in use).
-
Page 30: Printing And Saving System Configuration
You will received a text file that is saved in the specified location and the name chosen above. This file resides in the PC physically connected to the device and not in the DIAL-112 itself! This file is clearly readable with a normal text editor program. -
Page 31: Remote Programming
For example, if the parameter is 1 digit long, DIAL-112 verify the value introduced after receiving a single digit DTMF, if the parameter is 3 digits long and you will enter only 2 DIAL-112 will confirm the release after 3 seconds entering the second by the user. Inserting 3 digits DIAL-112 will confirm the release immediately after receipt of the third digit to warn that the area is full speed and the same programming parameters will be introduced as valid. -
Page 32: Remote Programming
Programming via GSM in the same way as described above, only that we need to wait for the response to the downstream device: dial the number of GSM SIM module of DIAL-112, wait for the answer of the downstream or the response of GSM (if DISA mode programmed), and enter the sequence “###“... -
Page 33: Mas-Dial112-Rev06En
RX voice volume level reception to the ISDN 203 # RX voice level internal. Range: from 1 to 12 Enables incoming calls on DIAL-112 (the answer is subject to anonymous calls Incoming calls 204 # acceptance and to the incoming calls block... -
Page 34: Relay Drive For Remote Control
GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL Field Description Field max Enter Your Parameter Name Default Number Range = possibile values length (digits) Settings Lock modes end of prepaid credit 0=never 407 # Block mode 1=immediately 2=at the end of the call... -
Page 35: Mas-Dial112-Rev06En
GSM Gateway Interface DIAL-112 TEMA TELECOMUNICAZIONI SRL Examples: 1111!<3351234567! Remove the specified number. 1111!>3351234567!Test!11000!111! Inserts the specified number, with incoming and outgoing calls enabled, the incoming call will be sent to 111 extension. 1111!>3351234567!!11001!! Inserts the specified number without description, with incoming and outgoing calls enabled.
