Summary of Contents for SK telecom Air Cube SN-100T
- Page 1 SN-100T / SN-100C Please carefully read the safety instructions to prevent any unintentional injuries. The pictures in this manual may differ from the actual product.
- Page 2 [What’s included] • Air Cube • Micro USB Calbe • Quick Guide...
-
Page 3: Power Button
[Air Cube Overview] Power/Charging LED When charging battery, red LED lights up. It will turn to green when the bat- tery has been completely charged. Power Button Pressing the power button more than one second will turn on/off the power. When an alarm goes off, press the button to turn off the alarm. - Page 4 [Turn Power On/Off] [On] Press the power button for more than one second. All the LED lights will blink three times simultaneously. Then the Bluetooth LED will blink turning into standby pairing mode. Once it’s paired up with a smartphone, whenever the power turns on, the Air Cube will automatically start to measure once every fif- teen(15) seconds.
- Page 5 [LED Display Measurements] Dangerous Warning Average Normal Very Good Discomfort Index Fine dust Air Quality (ppm) (DI) µg/m Very Good ~ 67 ~ 450 ~ 30 Normal 68 ~ 74 451 ~ 700 31 ~ 80 Average 75 ~ 79 701 ~ 1000 81 ~ 120 Warning...
- Page 6 [Air Cube Application] Using the Air Cube app, you can check the air quality conditions measured by Air Cube in real time. In addi- tion, the Air Cube app provides action guide in accord- ance with each air quality level. You can easily download the mobile application from our Air Cube website (www.aircube.io).
- Page 7 [Bluetooth Pairing (connection)] 1. Press the power button more than one second. 2. Bluetooth LED will turn to blue and blink, turning into standby pairing mode. 3. When running the air check application, you can ac- tivate the smartphone’s Bluetooth simply by following the instructions.
- Page 8 [Charging] You can charge the device with a micro 5-pin smartphone charger or micro USB cable. The power LED will turn red while charging and it turns green when it is complete. If the battery LED flashes, it means that the battery has less than 10% power.
-
Page 9: Safety Instructions
[Safety Instructions] ※ These safety precautions is to prevent any damage, malfunction or injuries. Failure to follow these instructions could result in fire, electric shock, injury or even death Do not place the Air Cube on an unstable surface. The product may be damaged if dropped. - Page 10 Please do not place the device in a vehicle under direct sunlight, on an electric blanket or on a rug. Also, avoid placing it in hot and humid environment such as sauna for a long time. (Panel disfigu- ration or it may cause malfunction.) Caution : Failure to follow these instructions may result in injury or product damage.
- Page 11 [When Air Cube doesn’t work properly] Please refer to the following actions for different symptoms that may occur and also refer to the user manual enclosed before reporting a device failure. Symptoms Action Make sure to press the power button more than one second.
- Page 12 [Product Specification] System Specification Battery Capacity Rechargeable Li-Ion 3.7V, 600mAh 24 Hours (may vary depending on the operating Operating time environment) Charging time 3 Hours Power Micro USB Adapter Interface Bluetooth 4.0 Low Energy(BLE) Dimensions 52(W) x 52(L) x 52(H) Sensor Specification Particulate Matters 0 ~ 500µg/m...
- Page 13 [Product warranty] Check if there are anything that’s not listed on a prescribed topic warranty Please suggest the warranty to your dealer or Customer Service when failure occurs (the warranty period is one year from the date of purchase, but the warranty of the battery is six months).
- Page 14 If the date of purchase is not checked, the warranty period is calculated from manufacturing date. Details that are not specified is subject to the ‘consumer dispute resolution criteria’ of the Korea Fair Trade Commission. Customer Service: SK Telecom Inc. Services : www.aircube.io / help@aircube.io...
- Page 15 MSIP-CMS-SK4-SN-100C Caveator ‘s name : Specific low power wireless devices (Wireless device for wireless data communication system) FCC ID : 2ADMB-AIRCUBE-BT Business Name : SK Telecom Inc. Manufacturer/Country : NBREDS Inc. / South Korea Rated Voltage : DC 3.7V ,600mAh * This wireless device may be affected or interfere with wave propaga- tion during operation.
