Saturn Titan-X 225mm Assembly Manual
PB3D Creations | Created 10-1-2016
With everyone getting their hands on their Titan-X 225 we figured an assembly log is much
needed. This read will take you through the steps of assembling the full frame with all 3D
Accessories.
*Please note, this is not a build log for electronics setup and layout but we will recommend where
components are best placed within the design.
Hardware
Aluminum
4X – 35mm Aluminum Standoffs
•
4X – 10mm Aluminum Screws
•
Stainless Steel
4X – M3 Stainless Steel Nuts
•
4X – M3 Stainless Steel Nyloc Nuts
•
4X – 14mm Stainless Steel Screws
•
8X – 12mm Stainless Steel Screws
•
2X – M2 Steel Camera Screws (Pre-Placed in FPV Mount)
•
Nylon (Separate Packaging)
4X – 6mm Nylon Female to Male Spacers
•
4X – M3 Nylon Nuts
•
4X – M3 Nylon Spacers
•
3D Accessories
Locking FPV Camera Mount
•
RX / VTX Antenna Flexible Mount
•
Glue-on Edge protection / Feet
•
**If you are missing any of the hardware or 3D Prints listed above please contact us and we will be
sure to send out the necessary parts. 3D Accessories such as recording camera mounts, and FPV
Protection are sold separately.
PARTS LIST
Page 1 of 7
