Edison DAM060 Operating Manual

Auto range digital multimeter - usb interface

Hide thumbs

Table Of Contents

Quick Links

5163440K_Instructions.qxd

Auto Range Digital

Multimeter - USB Interface

OPERATING MANUAL

Functions:

USB interface & software

for the PC

Electrical testing.

Temperature testing from

-5 to +1000° ° C.

18/09/2009

10:31

ORDER CODE: EDI-516-3440K

Page 1

MODEL DAM060

Table of Contents

Need help?

Do you have a question about the DAM060 and is the answer not in the manual?

Questions and answers

Summary of Contents for Edison DAM060

Page 1 5163440K_Instructions.qxd 18/09/2009 10:31 Page 1 ORDER CODE: EDI-516-3440K MODEL DAM060 Auto Range Digital Multimeter - USB Interface OPERATING MANUAL Functions: USB interface & software for the PC Electrical testing. Temperature testing from -5 to +1000° ° C.
Page 2: Table Of Contents
5163440K_Instructions.qxd 18/09/2009 10:31 Page 2 CONTENT 1. GENERAL INSTRUCTIONS ..................2 2. DESCRIPTION ......................6 3. FUNCTIONS DESCRIPTION ..................9 4. PC SOFTWARE OPERATION ..................16 5. TECHNICAL SPECIFICATION ..................17 6. MAINTENANCE ......................21 7. PACK CONTENT ....................22...
Page 3: General Instructions
5163440K_Instructions.qxd 18/09/2009 10:31 Page 3 Auto Range Digital Multimeter - USB Interface 1. G E N E R A L I N S T R U C T I O N S This multimeter has been designed according to IEC1010 standards for electronic measuring instruments with an over-voltage category (CAT II 1000V, CAT III 600V) and pollution level 2.
Page 4 5163440K_Instructions.qxd 18/09/2009 10:31 Page 4 • Disconnect circuits power and discharge all high-voltage capacitors before testing Resistance, Continuity, Diodes, or Capacitance. • NEVER perform resistance or continuity measurements on live circuits. • Before measuring current, check the meters fuse and turn off power to the circuit before connecting the meter to the circuit.
Page 5 5163440K_Instructions.qxd 18/09/2009 10:31 Page 5 Auto Range Digital Multimeter - USB Interface 1.2 Maintenance • DO NOT attempt to adjust or repair the meter by removing the rear case while voltage is being applied. Please allow a fully qualified technician to investigate any problems.
Page 6: Description
5163440K_Instructions.qxd 18/09/2009 10:31 Page 6 2. D E S C R I P T I O N S 2.1 Instrument Familiarisation 1. LCD display 2. Keypad 3. Rotary switch 4. Terminals 5. USB adaptor port...
Page 7 5163440K_Instructions.qxd 18/09/2009 10:31 Page 7 Auto Range Digital Multimeter - USB Interface 2.2 LCD Display 1. Indicates that A A C C voltage or current range is active for testing. 2. Indicates negative readings. 3. Indicates that D D C C voltage or current range is active for testing.
Page 8 5163440K_Instructions.qxd 18/09/2009 10:31 Page 8 2.3 Keypad SELECT • In Ω Ω position you can switch between Resistance measurement, Diode test and Continuity check. • In A A , , m m A A , , µ µ A A position you can switch between DC and AC current. •...
Page 9: Functions Description
5163440K_Instructions.qxd 18/09/2009 10:31 Page 9 Auto Range Digital Multimeter - USB Interface 3. F U N C T I O N D E S C R I P T I O N S 3.1 General Functions HOLD mode • HOLD mode makes the meter stop updating the display. •...
Page 10 5163440K_Instructions.qxd 18/09/2009 10:31 Page 10 Relative measurement mode The meter will display relative measurement in all functions except Frequency. To enter and exit the relative measurement mode: 1. With the meter in the desired function, touch the test leads to the circuit on which you want future measurement to be based.
Page 11 5163440K_Instructions.qxd 18/09/2009 10:31 Page 11 Auto Range Digital Multimeter - USB Interface Resistance measurement To avoid electrical shock and/or damage to the instrument, disconnect circuit power and discharge all high-voltage capacitors before measuring resistance. The meters resistance ranges are 600.0Ω, 6.000kΩ, 60.00kΩ, 600.0kΩ, 6.000MΩ...
Page 12 5163440K_Instructions.qxd 18/09/2009 10:32 Page 12 Diode Test To avoid electrical shock and/or damage to the instrument, disconnect circuit power and discharge all high-voltage capacitors before testing diodes. To test a diode out of a circuit: 1. Set the dial to Ω Ω range.
Page 13 5163440K_Instructions.qxd 18/09/2009 10:32 Page 13 Auto Range Digital Multimeter - USB Interface Capacitance measurement To avoid electrical shock and/or damage to the instrument, disconnect circuit power and discharge all high-voltage capacitors before measuring capacitance. Use the DC voltage function to confirm that the capacitor is discharged.
Page 14 5163440K_Instructions.qxd 18/09/2009 10:32 Page 14 8. At frequency measuring status, press Hz/DUTY one time then meter enters duty cycle measuring status, press it again then return to frequency measuring status. 9. Read the result directly from the display. N N O O T T E E : : In noisy environment, it is preferable to use shield cable for measuring small signal.
Page 15 5163440K_Instructions.qxd 18/09/2009 10:32 Page 15 Auto Range Digital Multimeter - USB Interface Current measurement To avoid damage to the meter or injury if the fuse blows, never attempt an in-circuit current measurement where the open-circuit potential to earth is greater than 250V. To avoid damage to the meter, check the meters fuse before proceeding.
Page 16: Pc Software Operation
5163440K_Instructions.qxd 18/09/2009 10:32 Page 16 4. P C - L I N K S O F T O P E R A T I O N 1. First install the PC-LINK software from the CD provided onto your computer. 2. Once the software has finished installing connect the USB driver lead into both the PC and multimeter.
Page 17: Technical Specification
5163440K_Instructions.qxd 18/09/2009 10:32 Page 17 Auto Range Digital Multimeter - USB Interface 5. T E C H N I C A L S P E C I F I C A T I O N S 5.1 General specifications • Environment Conditions:1000V CAT. II and 600V CAT. III •...
Page 18 5163440K_Instructions.qxd 18/09/2009 10:32 Page 18 A A C C V V RANGE RESOLUTION ACCURACY ± (3.0% of rdg + 3 digits) 600mV 0.1mV Manual Range only 10mV ± (1.0% of rdg + 3 digits) 600V 100mV 700V ±(1.5% of rdg + 3 digits) 1.
Page 19 5163440K_Instructions.qxd 18/09/2009 10:32 Page 19 Auto Range Digital Multimeter - USB Interface DIODE TEST RANGE RESOLUTION ACCURACY 0.001V 1.0% uncertainty • Test condition: Forward DC current approximately 1mA. Reversed DC voltage approximately 1.5V. • Overload Protection: 250V dc or 250V ac rms CONTINUITY CHECK RANGE RESOLUTION...
Page 20 5163440K_Instructions.qxd 18/09/2009 10:32 Page 20 CURRENT D D C C A A RANGE RESOLUTION ACCURACY 600µA 0.1µA ± (1.8% of rdg + 5 digits) 6000µA 1µA 60mA 0.01mA ± (2.0% of rdg + 8 digits) 600mA 0.1mA ±(3.0% of rdg + 8 digits) 10mA A A C C A A RANGE...
Page 21: Maintenance
5163440K_Instructions.qxd 18/09/2009 10:32 Page 21 Auto Range Digital Multimeter - USB Interface 6. M A I N T E N A N C E This section provides basic maintenance information, including fuse and battery replacement instructions. Do not attempt to repair or service your Meter unless you are qualified to do so and have the relevant calibration, performance test, and service information.
Page 22: Pack Content
5163440K_Instructions.qxd 18/09/2009 10:32 Page 22 Before replacing the battery and fuses, disconnect test leads from any circuit under test, turn the multimeter 'OFF' and remove test leads from the input terminals. To prevent damage to the meter or personal injury, always replace the battery or fuse with specified rating.
Page 23 5163440K_Instructions.qxd 18/09/2009 10:32 Page 23 Auto Range Digital Multimeter - USB Interface...
