Fiio W1T1 User Manual

FiiO
Read this instruction carefully before using the product
Introduction to FiiO W1T1——Wireless Audio Transmitter
Brief introduction
W1T1 is an all-in-one machine which with multifunction of audio decoder and 2.4G
wireless transmitter. It can decode digital audio for inputs of optical, coaxial and
USB, outputs via optical port (Digital signal) and RCA port (Analog signal), while
transmits through 2.4G so as to receive by the receiver in agreement. In the same
way, it can input analog signal via RCA port and transmits by 2.4G as well.

Specifications

●Analog output range:
●Analog output THD:
●Frequency response:
●Signal To Noise Ratio:
●RF Frequency:
●RF Power：
●Sample rate:
●Power Voltage：
●Size:
●Weight:
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio frequency energyand, if not
W1T1 User Manual
1.3Vrms（0dB Fs）
0.006%（-3dB ）
20Hz-20 KHz
2404-2479MHz
＜10dBm
24Bit 192 KHz Max.（Optical/Coaxial）
16Bit 44.1/48 KHz Max.（USB）
DC-5.0V
141mmx82.7mmx23.2mm
175g
