  • Page 1 SquellCooler Operating manual...
  • Page 2 SquellCooler 1 2 3...
  • Page 3 SquellCooler...
  • Page 4 SquellCooler...

  • Page 5: Table Of Contents

    SquellCooler Please read this manual carefully before starting up and store it in a safe place. If you pass on the device to another person, hand over this instruction manual along with it. Table of contents Explanation of symbols ........6 Safety instructions .

  • Page 6: Explanation Of Symbols

    Explanation of symbols SquellCooler Explanation of symbols DANGER! Safety instruction: Failure to observe this instruction will cause fatal or serious injury. WARNING! Safety instruction: Failure to observe this instruction can cause fatal or serious injury. CAUTION! Safety instruction: Failure to observe this instruction can lead to injury.
  • Page 7 SquellCooler Safety instructions General safety DANGER!  On boats: If the appliance is powered by the mains, ensure that the power supply has a residual current circuit breaker. WARNING!  Do not operate the device if it is visibly damaged. ...
  • Page 8 Safety instructions SquellCooler Operating the device safely CAUTION!  Before starting the device, ensure that the power supply line and the plug are dry. NOTICE!  Do not use electrical devices inside the cooling device unless they are recommended by the manufacturer for that purpose. ...

  • Page 9: Scope Of Delivery

    SquellCooler Scope of delivery Scope of delivery Quantity Designation Cooler Drip tray and drip plate 230 Vwconnection cable Adjustable feet with lock nut Operating manual Description of device Item no. in: fig. 1, page 2 Item Description Lock LED display Window for inserting graphics Push-button tap Door...

  • Page 10: Function Description

    Function description SquellCooler Function description The appliance is a compact tabletop device. Bag-in-Box cartons and cartridg- es can be cooled to a temperature of +3°C to +20°C. The device is designed to operate with 220 to 240 Voltw/50 Hz. A mainte- nance-free refrigerant circuit with compressor provides the cooling.
  • Page 11 SquellCooler Operation ➤ Screw in the adjustable feet and fasten these with the nut (fig. 3, page 2). ➤ Adjust the device so that it is level. Using the device NOTE  Cool the Bag-in-Box cartons beforehand to ensure a constant cool temperature for the liquids being dispensed.
  • Page 12 Operation SquellCooler Setting display brightness (menu item 2) (fig. 4, page 2) ➤ Open the door of the device. ➤ Press menu button (2) twice. ✓ There is a “2” on the left of the menu item and the current setting is on the right.
  • Page 13 SquellCooler Operation ➤ Insert the carton or the cassette (fig. 7, page 3). ➤ Raise the tapping unit so that it latches into place (fig. 8, page 3). ➤ Insert the valve into the valve holder and carefully move the lever on the tapping unit forwards until it latches into place (fig.

  • Page 14: Cleaning And Maintenance

    Cleaning and maintenance SquellCooler Cleaning and maintenance WARNING! Danger of electrocution! Before cleaning and maintenance, disconnect the device from the mains network and take out all the Bag-in-Box cartons. NOTICE! Beware of damage!  The following materials damage the coating and the plastics and must not be used to clean the device: Hot water, thinner, benzene, alcohols, kerosene, washing powder, detergent, ac- ids, chemical wipes.

  • Page 15: Troubleshooting

    SquellCooler Troubleshooting Troubleshooting Fault Possible cause Suggested remedy The device does not The device is not prop- Check whether the connection cable and work. erly connected. any extension cables are correctly plugged in. If you are using an extension cable, check it and replace if defective.

  • Page 16: Disposal

    Refrigerant and gases must be disposed of in a suit- able manner. Make sure that the refrigerant circuit pipes are protected from damage until the device is properly disposed of. Technical data Squell Cooler Item no.: S1100300 Voltage: 220–240 Vw /50 Hz...
  • Page 20 Squell Produktion und Handel GmbH Altwingertweg 14 D-68766 Hockenheim  +49 (6205) 305 187-0 ·  +49 (6205) 305 187-77 Mail: info@squell.com · Internet: www.squell.com Made in Germany...
