Multimic M-800P Instruction Manual

Dc in ac clamp meter
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
DC in AC CLAMP METER
M - 8 0 0 P
INSTRUCTION MANUAL
Thank you very much for selecting our model 800P
DC in AC Clamp Meter.
Before use the instrument, read this instruction manual
completely and familiarize yourself thoroughly with all
functions.
Keep this instruction manual carefully to take out
whenever you need.
MULTI MEASURING INSTRUMENTS CO.,LTD.
Akihabara Murai Bldg. 7F, 1-26 Kanda Sakuma-cho,
Chiyoda-ku, Tokyo, 101-0025 Japan
TEL : +81-3-3251-7016 FAX : +81-3-3253-4278
Home Page :
http://www.mutimic.com/
E-mail :
multi@multimic.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M-800P and is the answer not in the manual?

Questions and answers

Summary of Contents for Multimic M-800P

  • Page 1 Keep this instruction manual carefully to take out whenever you need. MULTI MEASURING INSTRUMENTS CO.,LTD. Akihabara Murai Bldg. 7F, 1-26 Kanda Sakuma-cho, Chiyoda-ku, Tokyo, 101-0025 Japan TEL : +81-3-3251-7016 FAX : +81-3-3253-4278 Home Page : http://www.mutimic.com/ E-mail : multi@multimic.com...

  • Page 2: Safety Summary

    SAFETY SUMMARY observe by all means ● To use this instrument safely, read this "SAFETY SUMMARY" carefully and apply the instrument correctly. ● The CAUTIONs and WARNINGs which appear on the following pages are stated to prevent the operator & other people from the dangers and their properties from the damages beforehand.
  • Page 3 GENERAL This “DC in AC CLAMP METER (M-800P)” is the world-first clamp meter, which can measure not only AC & DC current but also can detect small DC current in AC and can display its percentage. SPECIFICATIONS （1） Measuring Function ：ACA、DCA、DC％...
  • Page 4 ACCURACY Tolerance：23℃±5℃、less than 80％RH、Conductor to be measured at the center of CT Range Auto Range Min. Resolution Measuring Range 確度 0.01 0.00～15.00A ±1.0％rdg±5dgt 150A 15.0～150.0A ±2.0％rdg±5dgt 0.01 0.00～15.00A ±1.0％rdg±5dgt 150A 15.0～150.0A ±2.0％rdg±8dgt 150V 0.0～150.0V ±1.0％rdg±5dgt 600V 150～600V ±1.0％rdg±5dgt 150V 0.0～150.0V ±1.0％rdg±5dgt 600V 150～600V...
  • Page 5 ⑥ Zero Set Switch ：Apply this switch at range switch「DCA」. By pressing Zero Set Switch, 「△」mark on LCD. (It will take approx. 5 – 6 seconds for zero set). ⑦ LCD Display ：Digital display for measured value, unit symbol and battery condition. ⑧...
  • Page 6 ●DC Voltage（V）Measurement 1）Set range switch ③ from OFF to V position. 2）Set AC/DC switch ④ to DC side. 3）Insert voltage probe to voltage input terminal ⑩.（Red：＋、 Black：－） 4）Apply voltage input leads to the object to be measured. 5）Read the displayed value. 6）In the place where the display can hardly read, use data ＋side hold switch ⑤.
  • Page 7 REPLACEMENT OF BATTERIES WARNING △ ！ POSSIBLE ELECTRICAL SHOCK OR ACCIDENT ● Do not replace the batteries under the conditions of measuring current or voltage ● Do not operate the instrument with battery cover off. CAUTION △ ！ When not using the instrument for a long period, remove the batteries and keep separately.

  • Page 8: Repair Service

    4. REPAIR SERVICE When requesting for repair service, please bring the instrument directly to the dealer where you bought. When mailing the instrument, always pack it in its original or equivalent packing materials to avoid any damage during the transportation and also put together with documents showing your name, address, phone number and defect point.
