ATS NASA 2001 Operation Manual

System Operation of ATS NASA 2001™
ATS NASA 2001 is an advanced car security system which provides three unique functions:
(1) Anti-theft Alarm
(2) Anti-carjacking
(3) Remote Control via Paging System
Security System with Local Remote Control for Model PA2001-SRC
1. Remote Arming
Pressing the key-chain transmitter button #1 (left hand-sided button) once momentarily will arm the system. The
alarm system will confirm it with 1 siren chirp. Also the parking lights will flash once. The LED will flash once
every three seconds.
2. Remote Disarming
Pressing the key chain transmitter button #1 once again momentarily will disarm the system. The system will
confirm it with 2 siren chirps. Also the parking lights will flash twice. The LED will go off.
3. Emergency Override Switch
In the case that the remote key-chain transmitter is lost or broken, you can disarm the system by using the
Emergency Override Switch with the following procedures:
(1). Open the door; the alarm will be activated and the horn will sound;
(2). Insert the ignition key and turn to the ignition "ON" position; and,
(3). Press the Valet/ Override button switch momentarily. The alarm will be disabled and the LED will be
turned off. The starter-disabled feature will be deactivated. This will allow you to start your car again.
After completing the procedures above, you have made the system enter into the RESET mode; the system will
return to passive Arming & Disarming mode. In other words, when the driver turns the ignition key to "OFF"
position, or removes the car key, the alarm system will automatically arm itself in the amount of EXIT time
previously selected in the "Programming Instructions" section of Installation Manual.
4. Valet Mode

SYSTEM OPERATION
