Installation Instructions &
ELECTRIC HEATER WITH REMOTE CONTROL
READ AND SAVE THESE INSTRUCTIONS
READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR
MAINTAIN THE PRODUCT DESCRIBED.
PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION.
FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY
AND/OR PROPERTY DAMAGE.
WARNING! To reduce the risk of fire, electric shock, or personal
injury, read all the instructions before using this heater.
Homeowner's
Operating Manual
For EF42-45C Range
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Richen EF42C
Summary of Contents for Richen EF42C
- Page 1 Homeowner’s Installation Instructions & Operating Manual ELECTRIC HEATER WITH REMOTE CONTROL For EF42-45C Range READ AND SAVE THESE INSTRUCTIONS READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED. PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE.
- Page 2 IMPORTANT INSTRUCTIONS When using electrical appliances basic precautions should always be followed to reduce the risk of fire， electrical shock and injury to persons including the following： CAUTION- High temperature, keep electrical cords, drapery, and other furnishings at least 3 feet (0.9m) from the front of the heater and away from the side and rear.
- Page 3 A. Fireplace insert for rear attachment units:mm/Inch Mantel opening size Width Height Depth Mantel Minimum Depth Model Width Height （W） （H） （D） （RD） （OW） （OH） EF42C 580/22.8 520/20.5 220/8.7 584/23.0 523/20.6 230/9.0 EF43C 660/26.0 600/23.6 220/8.7 664/26.0 603/23.7 230/9.0 EF44C 760/30.0 600/23.6 220/8.7 764/30.0 603/23.7...
- Page 4 B. Fireplace insert for front attachment： units:mm/Inch Mantel opening size Width Height Depth Mantel Minimum Depth Width Height Model （W） （H） （D） （RD） （OW） （OH） 580-610 510-540 EF42C 630/24.8 545/21.5 220/8.7 205/8 /22.8-24 /20-21.3 660-690 590-620 EF43C 710/28.0 625/24.6 220/8.7 205/8 /26-27 /23-24 760-790 590-620 EF44C 810/31.9...
- Page 5 Step 2. Install insert Use 2pcs M6×16 screws to attach one side Attach another side using same method; of the insert B. Front attachment: Install insert: ！ ！ ！ When inserting the heating unit into mantel; Do not let the bottom of the insert touch the mantel to avoid scratching it.
- Page 6 ELECTRICAL CONNECTION A 8.7AMP, 220-240 Volt, The unit comes standard with 6 feet (1.8 m) three wire cord and plug, exiting from the rear of the fireplace. Plan the installation to avoid the use of an extension cord. Preferably, the fireplace will be on a dedicated circuit as other appliances on the same circuit may cause the circuit breaker to trip or the fuse to blow when the heater is in operation.
- Page 7 There are 3 levels you can cycle through including the OFF setting. Thermostat control 1-9 Step，room temperature is around 9-34℃. If room temperature is too high, please turn the thermostat knob in a counter-clockwise direction; if you need to turn on the heater, you can turn the thermostat knob in a clockwise direction.
- Page 8 Store heater in a clean dry place when not in use. Warning: Any other servicing needed must be performed by an authorized service representative. Do not attempt to service the unit yourself. Ningbo Richen Electrical Appliance Co., Ltd. No. 639 Jiulong Road, Luotuo Town, Zhenhai, Ningbo, Zhejiang 315202, P.R. China...
