Pro-Nets Technology WR760R User Manual

11n wireless, 3g broadband router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
11n Wireless
3G Broadband Router
User's Manual
January 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WR760R and is the answer not in the manual?

Questions and answers

Summary of Contents for Pro-Nets Technology WR760R

  • Page 1 11n Wireless 3G Broadband Router User’s Manual January 2011...
  • Page 2 FCC Warning    This  equipment  has  been  tested  and  found  to  comply  with  the  limits  for  a  Class  B  digital  device,  pursuant  to  part  15  of  the  FCC  Rules.  These  limits  are  designed  to  provide  reasonable  protection  against  harmful  interference  in  a  residential  installation.  This  equipment  generates,  uses,  and  can  radiate radio frequency energy and, if not installed and used in accordance with the instructions, may ...
  • Page 3 Copyright    2011 All Rights Reserved.  No part of this document can be copied or reproduced in any form without written consent from the  company.  Trademarks:  All trade names and trademarks are the properties of their respective companies.  Revision History  Revision                                                                        History  V1 ...

  • Page 4: Table Of Contents

    Table of Contents 1. Introduction........................5 1.1 Features ......................5 1.2 Specifications ..................... 6 1.3 Package Contents ....................7 1.4 System Requirements..................7 1.5 LEDs Indication & Connectors of Wireless Router ..........8 1.6 Installation Instruction ..................9 2. PC Configuration ......................9 2.1 TCP/IP Networking Setup ...................
  • Page 5 3.6.3 MAC Filtering ..................... 50 3.6.4 Port Forwarding..................51 3.6.5 URL Filter....................52 3.6.6 DMZ ......................53 3.6.7 VLAN......................53 3.7 QoS ........................54 3.8 Route Setup ..................... 56 3.9 Management....................57 3.9.1 Status......................57 3.9.2 Statistics ..................... 59 3.9.3 DDNS ......................60 3.9.4 Time Zone Setting ..................

  • Page 6: Introduction

    1. Introduction This Wireless Broadband Router complies with IEEE 802.11n, and provides faster and farther range than 802.11g while being backward compatible with 802.11g and 802.11b mode. This router uses advanced broadband router chipset and wireless LAN chipset solution to let you enjoy high speed Wired and Wireless connection.

  • Page 7: Specifications

    1.2 Specifications  150 Mbps (802.11n mode)  Data Transfer Rates  54Mbps (802.11g mode)  11Mbps (802.11b mode)  IEEE 802.11b / 802.11g / 802.11n (Wireless)  Standard  IEEE  802.3,  IEEE  802.3u,  IEEE  802.3x  Full  Duplex  Flow  Control  (Wired)  Operating Radius  100M Indoor, 300M Outdoor  Connect  to  Broadband  (Cable  or  xDSL)  modem  or  Ethernet  Internet Access  backbone for Internet Surfing  WAN Connection  Dynamic IP, Static IP, PPPoE, PPTP, L2TP  NAT (Network Address Translation)  NAPT (Network Address and Port Translation)  DHCP (Dynamic Host Configuration Protocol) Server/Client    Support VPN pass through – IPSec, PPTP, L2TP    Support Virtual server / Port Trigger  Support Virtual DMZ host ...

  • Page 8: Package Contents

    Support Configuration setting Backup/Restore/Reset Default  Interface  LAN x 4, WAN x 1, USB2.0  LED Indicators    POWER, STATUS, LAN x 4, WAN x 1, WLAN x 1  Antenna  1 Antennas  Wireless Frequency    2.4000~2.4835GHz  802.11b mode: 16.10 dBm; 802.11g mode: 20.24 dBm; Output Power  802.11n 20 MHz mode: 19.50 dBm; 802.11n 40 MHz mode: 18.58 dBm IEEE  802.11b  :  ‐88  dBm  (Typical),  IEEE  802.11g  :  ‐70dBm  (Typical) ...

  • Page 9: Leds Indication & Connectors Of Wireless Router

    1.5 LEDs Indication & Connectors of Wireless Router Front Panel LEDs Indication Light Status Description Wireless Router is powered on. Wireless Router is powered off. WLAN Slow Blinking WLAN is successfully connected. Blinking Data is being sent or received. WAN port is successfully connected Blinking Data is being sent or received.

  • Page 10: Installation Instruction

    1.6 Installation Instruction 1) Power off 802.11n AP Router and DSL/Cable modem. 2) Connect computer to the LAN port on the Wireless Router with Ethernet cable. 3) Connect the DSL or Cable modem to the WAN port on the Wireless Router with Ethernet cable.
  • Page 11 Click “Properties”, the window below will appear and then click “IP Address” tab, If you decide to use DHCP, select “Obtain an IP address automatically”, then click “OK” to confirm your settings. Once you restart your system, Wireless Router will obtain an IP address for this system.
  • Page 12 If you decide to use fixed IP address for your system, select “Specify an IP address”, and make sure that IP Address and Subnet Mask are correct. Select “Gateway” tab and enter correct gateway address in “New gateway” field, then click “Add”, Select “DNS Configuration”...
  • Page 13 Checking TCI/IP Setting for Windows NT4.0 Select “Control Panel Æ Network”, window below will appear, click “Protocols” tab then select “TCP/IP protocol”, Click “Properties”, window below will appear.
  • Page 14 Select the network card on your system from “Adapter” field. If you decide to use IP address from Wireless Router, select “Obtain an IP address from a DHCP server”. If you decide to use the IP address you are desired, select “Specify an IP address”.
  • Page 15 Select the “Internet Protocol (TCP/IP)” for the network card on your system, then click “Properties”, window below will appear.
  • Page 16 If you decide to use IP address from Wireless Router, select “Obtain an IP address automatically”. If you decide to use the IP address you are desired, select “Use the following IP address”. Make sure enter correct addresses in “IP Address” and “Subnet Mask”...
  • Page 17 If you decide to use IP address from Wireless Router, select “Obtain an IP address automatically”. If you decide to use the IP address you are desired, select “Use the following IP address”. Make sure enter correct addresses in “IP Address” and “Subnet Mask”...
  • Page 18 Select “Internet Protocol (TCP/IP)” then click “Properties”, window below will appear. If you decide to use IP address from Wireless Router, select “Obtain an IP address automatically”.
  • Page 19 If you decide to use the IP address you are desired, select “Use the following IP address”. Make sure enter correct addresses in “IP Address” and “Subnet Mask” fields. You must set Wireless Router’s IP address as “Default Gateway”. If the DNS Server fields are empty, select “Use the following DNS server addresses”...
  • Page 20 Configure IP Address Manually: Select “Use the following IP address” and “Use the following DNS server addresses”. IP address: Fill in IP address 192.168.1.x (x is a number between 2 to 254).
  • Page 21 Subnet mask: Default value is 255.255.255.0. Default gateway: Default value is 192.168.1.1. Preferred DNS server: Fill in preferred DNS server IP address. Alternate DNS server: Fill in alternate DNS server IP address. If you decide to use IP address from Wireless Router, select “Obtain an IP address automatically”.

  • Page 22: Configure Wireless Router Via Web Based Utility

    3. Configure Wireless Router via Web Based Utility The Wireless Router implements a Web server allowing user configure this device via the web based Utility. This Utility provides comprehensive system management scheme, including system configuration, performance monitoring, system maintenance and administration.

  • Page 23: Setup Wizard

    3.2 Setup Wizard This page guides you to configure wireless broadband router for first time.

  • Page 24: Operation Mode

    3.2.1 Operation Mode This page followed by Setup Wizard page to define the operation mode. 3.2.2 Time Zone Setting This page is used to enable and configure NTP client.

  • Page 25: Lan Interface Setup

    3.2.3 LAN Interface Setup This page is used to configure local area network IP address and subnet mask. 3.2.4 WAN Interface Setup This page is used to configure WAN access type...

  • Page 26: Wireless Basic Settings

    3.2.5 Wireless Basic Settings This page is used to configure basic wireless parameters like Band, Mode, Network Type SSID, Channel Number, Enable Mac Clone(Single Ethernet Client). 3.2.6 Wireless Security Setup This page is used to configure wireless security.

  • Page 27: Operation Mode

    3.3 Operation Mode This page is used to configure which mode wireless broadband router acts. Gateway: Traditional gateway configuration. It always connects internet via ADSL/Cable Modem. LAN interface, WAN interface, Wireless interface, NAT and Firewall modules are applied to this mode. Bridge: Each interface (LAN, WAN and Wireless) regards as bridge.
  • Page 28 Disable Wireless LAN Interface: Click on to disable the wireless LAN data transmission. Band: This is the range of frequencies the gateway will use to communicate with your wireless devices. As you’re looking for products in stores or on the Internet, you might notice that you can choose equipment that supports six different wireless networking technologies: 2.4 GHz(B), 2.4 GHz(G), 2.4 GHz(B+G), 2.4 GHz(N), 2.4 GHz(G+N), and 2.4 GHz(B+G+N).

  • Page 29: Advanced Settings

    you must use the make up your own name and use it on each computer. The name can be up to 32 characters long and contain letters and numbers. Channel Width: There have 2 options – 20MHZ and 40 MHZ [N band only].
  • Page 30 Fragment Threshold: Fragmentation Threshold sets the frame size of incoming messages (ranging from 256 to 2346 bytes) used as fragmentation boundary. If the frame size is too big, the heavy interference affects transmission reliability. If the frame size is too small, it decreases transmission efficiency.

  • Page 31: Security

    Short GI: Using a short (400ns) guard interval can increase throughput. However, it can also increase error rate in some installations, due to increased sensitivity to radio frequency reflections WLAN Partition: Click to enable or disable the WLAN Partition function. STBC: Click to enable or disable the STBC function.

  • Page 32: Access Control

    Key Format: Select the WEP shared secret key format from pull down menu. The format can be chose between plant text (ASCII) and hexadecimal (HEX) code. Encryption Key: Secret key of WEP security encryption function. WPA Authentication Mode: While Encryption is selected to be WPA. Click to select the WPA Authentication Mode with Enterprise (RADIUS) or Personal (Pre Shared Key).

  • Page 33: Wds Setting

    Wireless Access Control Mode: Click the Disabled, Allow Listed Deny Listed of drop down menu choose wireless access control mode. This is a security control function; only those clients registered in the access control list can link to this WLAN Broadband Router. MAC Address: Fill in the MAC address of client to register this WLAN Broadband Router access capability.

  • Page 34: Site Survey

    MAC Address: Fill in the MAC address of AP to register the wireless distribution system access capability. Data Rate: Select the transmission data rate from pull down menu. Data rate: can be auto select, 1M to 54Mbps or MCS. Comment: Fill in the comment tag for the registered AP. Apply Changes: Click the Apply Changes button to complete the new configuration setting.

  • Page 35: Wps

    SSID: It shows the SSID of AP. BSSID: It shows BSSID of AP. Channel: It show the current channel of AP occupied. Type: It show which type AP acts. Encrypt: It shows the encryption status. Signal: It shows the power level of current AP. Refresh: Click the Refresh button to re scan site survey on the screen.

  • Page 36: Schedule

    Apply Changes: Click the Apply Changes button to complete the new configuration setting. Reset: Click the Reset button to abort change and recover the previous configuration setting. Current Key Info: Authentication It shows the Authentication is opened or closed. Encryption It shows the Encryption mode.
  • Page 37 IP Address: Fill in the IP address of LAN interfaces of this WLAN Access Point. Subnet Mask: Fill in the subnet mask of LAN interfaces of this WLAN Access Point. Default Gateway: Fill in the default gateway for LAN interfaces out going data packets. DHCP: Click to select Disabled, Client Server...

  • Page 38: Static Dhcp Setup

    3.5.1.1 Static DHCP Setup This page allows you reserve IP address and assign the same IP address to the network device with the specified MAC address any time it requests an IP address. This is almost the same as when a device has a static IP address except that the device must still request an IP address from the DHCP server.
  • Page 39 [Static IP] Static IP: Click to select Static IP support on WAN interface. There are IP address, subnet mask and default gateway settings need to be done. IP Address: If you select the Static IP support on WAN interface, fill in the IP address for it. Subnet Mask: If you select the Static IP support on WAN interface, fill in the subnet mask for Default Gateway: If you select the Static IP support on WAN interface, fill in the default gateway for WAN interface out going data packets.
  • Page 40 WAN side. Enable IPsec pass through on VPN connection: Click the checkbox to enable IPSec packet pass through. Enable PPTP pass through on VPN connection: Click the checkbox to enable PPTP packet pass through. Enable L2TP pass through on VPN connection: Click the checkbox to enable L2TP packet pass through.
  • Page 41 MTU Size: Fill in the mtu size of MTU Size. The default value is 1400. Attain DNS Automatically: Click to select getting DNS address for DHCP support. Please select Set DNS Manually if the DHCP support is selected. Set DNS Manually: Click to select getting DNS address for DHCP support. DNS 1: Fill in the IP address of Domain Name Server 1.
  • Page 42 packets out through the WAN interface; there are a watchdog implemented to close the PPPoE connection while there are no data sent out longer than the idle time set. „ Manual connection type means to setup the connection through the PPPoE protocol by clicking the Connect button manually, and clicking the Disconnect button manually.
  • Page 43 [PPTP] PPTP: Allow user to make a tunnel with remote site directly to secure the data transmission among the connection. User can use embedded PPTP client supported by this router to make a VPN connection. Get the WAN IP Automatically: Click to select PPTP Dynamic support on WAN interface for IP address assigned automatically from a PPTP server.
  • Page 44 Server IP Address : Enter the IP address of the PPTP Server. Server Domain Name: Assign Domain Name and dispatch to PPTP servers. It is optional field. User Name: If you select the PPTP support on WAN interface, fill in the user name and password to login the PPTP server.
  • Page 45 DNS 1: Fill in the IP address of Domain Name Server 1. DNS 2: Fill in the IP address of Domain Name Server 2. DNS 3: Fill in the IP address of Domain Name Server 3. Clone MAC Address: Fill in the MAC address that is the MAC address to be cloned. Enable uPNP: Click the checkbox to enable uPNP function.
  • Page 46 MTU Size: Fill in the MTU size of MTU Size. The default value is 1400. Request MPPE Encryption: Click the checkbox to enable request MPPE encryption. Attain DNS Automatically: Click to select getting DNS address for L2TP support. Please select Set DNS Manually if the L2TP support is selected.
  • Page 47 Enable Ping Access on WAN: Click the checkbox to enable WAN ICMP response. Enable Web Server Access on WAN: Click the checkbox to enable web configuration from WAN side. Enable IPsec pass through on VPN connection: Click the checkbox to enable IPSec packet pass through.
  • Page 48 Set DNS Manually: Click to select getting DNS address for DHCP support. DNS 1: Fill in the IP address of Domain Name Server 1. DNS 2: Fill in the IP address of Domain Name Server 2. DNS 3: Fill in the IP address of Domain Name Server 3. Clone MAC Address: Fill in the MAC address that is the MAC address to be cloned.

  • Page 49: Firewall

    3.6 Firewall 3.6.1 Port Filtering Entries in this table are used to restrict certain types of data packets from your local network to Internet through the Gateway. Use of such filters can be helpful in securing or restricting your local network.

  • Page 50: Ip Filtering

    Enable Port Filtering: Click to enable the port filtering security function. Port Range/Protocol/Comments: To restrict data transmission from the local network on certain ports, fill in the range of start port and end port, and the protocol, also put your comments on it.

  • Page 51: Mac Filtering

    Enable IP Filtering: Click to enable the IP filtering security function. Local IP Address/Protocol/Comments: To restrict data transmission from local network on certain IP addresses, fill in the IP address and the protocol; also put your comments on it. The Protocol can be TCP, UDP or Both. Comments let you know about whys to restrict data from the IP address.

  • Page 52: Port Forwarding

    Enable MAC Filtering: Click to enable the MAC filtering security function. MAC Address/Comments: To restrict data transmission from local network on certain MAC addresses, fill in the MAC address and your comments on it. Comments let you know about whys to restrict data from the MAC address. 3.6.4 Port Forwarding Entries in this table allow you to automatically redirect common network services to a specific machine behind the NAT firewall.

  • Page 53: Url Filter

    Enable Port Forwarding: Click to enable the Port Forwarding security function. Local IP Address/Protocol/Port Range/Comment: To forward data packets coming from WAN to a specific IP address that hosted in local network behind the NAT firewall, fill in the IP address, protocol, port range and your comments. The Protocol can be TCP, UDP or Both. The Port Range is for data transmission.

  • Page 54: Dmz

    Enable URL Filtering: Click to enable the URL Filtering function. URL Address: Add one URL address. 3.6.6 DMZ A Demilitarized Zone is used to provide Internet services without sacrificing unauthorized access to its local private network. Typically, the DMZ host contains devices accessible to Internet traffic, such as Web (HTTP) servers, FTP servers, SMTP (e mail) servers and DNS servers.

  • Page 55: Qos

    3.7 QoS Entries in this table improve your online gaming experience by ensuring that your game traffic is prioritized over other network traffic, such as FTP or Web.
  • Page 56 How to setup your QoS: 1. In QoS Setup Section, Enable QoS feature. 2. Choose Uplink & Downlink Speed: “Automatic” or “Manual” 3. Select Address Type: “IP” or “Address” 4. Configure QoS Rules – Mode(“Guaranteed Minimum bandwidth” & “Restricted Maximum bandwidth”), Uplink/Downlink Bandwidth, Comment. 5.

  • Page 57: Route Setup

    3.8 Route Setup This page is used to setup dynamic routing protocol or edit static route entry. [Dynamic Route] Dynamic routing is a technique developed to automatically adjust routing tables in the event of network failures. The most common dynamic routing protocols is RIP (Routing Information Protocol), which is very common on small networks.

  • Page 58: Management

    3.9 Management 3.9.1 Status This page shows the current status and some basic settings of the device, includes system, wireless, Ethernet LAN and WAN configuration information. [System] Uptime: It shows the duration since WLAN AP Router is powered on. Firmware version: It shows the firmware version of WLAN AP Router. [Wireless configuration] Mode: It shows wireless operation mode Band: It shows the current wireless operating frequency.
  • Page 59 Channel Number: It shows the wireless channel connected currently. Encryption: It shows the status of encryption function. Associated Clients: It shows the number of connected clients (or stations, PCs). BSSID: It shows the BSSID address of the WLAN AP Router BSSID is a six byte address. [LAN configuration] IP Address: It shows the IP address of LAN interfaces of WLAN AP Router.

  • Page 60: Statistics

    3.9.2 Statistics This page shows the packet counters for transmission and reception regarding to wireless, Ethernet LAN and Ethernet WAN networks. [Wireless LAN] Sent Packets: It shows the statistic count of sent packets on the wireless LAN interface. Received Packets: It shows the statistic count of received packets on the wireless LAN interface.

  • Page 61: Ddns

    3.9.3 DDNS This page is used to configure Dynamic DNS service to have DNS with dynamic IP address. Enable DDNS: Click the checkbox to enable DDNS service. Service Provider: Click the drop down menu to pickup the right provider. Domain Name: To configure the Domain Name. User Name/Email: Configure User Name, Email.

  • Page 62: Denial Of Service

    Current Time: It shows the current time. Time Zone Select: Click the time zone in your country. Enable NTP client update: Click the checkbox to enable NTP client update. NTP Server: Click select default or input NTP server IP address. Apply Change: Click the Apply Changes button to save and enable NTP client service.

  • Page 63: Log

    3.9.6 Log This page is used to configure the remote log server and shown the current log. Enable Log: Click the checkbox to enable log. System all: Show all log of wireless broadband router. Wireless: Only show wireless log DoS: Only show Denial of Service log Enable Remote Log: Click the checkbox to enable remote log service.

  • Page 64: Upgrade Firmware

    3.9.7 Upgrade Firmware This page allows you upgrade the Access Point firmware to new version. Please note, do not power off the device during the upload because it may crash the system.

  • Page 65: Save/Reload Setting

    Select File: Click the Browse button to select the new version of web firmware image file. Upload: Click the Upload button to update the selected web firmware image to the WLAN Broadband Router. Reset: Click the Reset button to abort change and recover the previous configuration setting.

  • Page 66: Password

    Save Settings to File: Click the Save button to download the configuration parameters to your personal computer. Load Settings from File: Click the Browse button to select the configuration files then click the Upload button to update the selected configuration to the WLAN Broadband Router. Reset Settings to Default: Click the Reset button to reset the configuration parameter to factory defaults.
  • Page 67 User Name: Fill in the user name for web management login control. New Password: Fill in the password for web management login control. Confirmed Password: Because of the password input is invisible, fill in the password again for confirming purpose. Apply Changes: Clear the User Name and Password fields to empty, means to apply no web management login control.
