Mazi PB-13V User Manual

Video intercom vandal-resistant door station
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Video Intercom Vandal-Resistant

Door Station

User Manual
1.1.1.1.1.1.1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PB-13V and is the answer not in the manual?

Questions and answers

Related Manuals for Mazi PB-13V

Summary of Contents for Mazi PB-13V

  • Page 1: Door Station

    Video Intercom Vandal-Resistant Door Station User Manual 1.1.1.1.1.1.1.1...

  • Page 2: User Manual

    Video Intercom Vandal-Resistant Door Station·User Manual User Manual This user manual is intended for users of the vandal-resistant door station. It includes instructions on how to use the Product. The software embodied in the Product is governed by the user license agreement covering that product. Disclaimer REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.

  • Page 3: Regulatory Information

    Video Intercom Vandal-Resistant Door Station·User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 Video Intercom Vandal-Resistant Door Station·User Manual 2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted municipal waste in the European Union. See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg).
  • Page 5 Video Intercom Vandal-Resistant Door Station·User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into Warnings and Cautions: Warnings: Neglecting any of the warnings may cause serious injury or death. Cautions: Neglecting any of the cautions may cause injury or equipment damage.
  • Page 6 Video Intercom Vandal-Resistant Door Station·User Manual  Exposing the equipment to direct sun light, low ventilation or heat source such as heater or radiator is forbidden (ignorance can cause fire danger).  Do not aim the device at the sun or extra bright places. A blooming or smear may occur otherwise (which is not a malfunction however), and affecting the endurance of sensor at the same time.

  • Page 7: Table Of Contents

    Video Intercom Vandal-Resistant Door Station·User Manual Table of Contents 1 Overview ...................... 1 1.1 Introduction ......................1 1.2 Main Features ......................1 1.3 Typical Application ....................3 2 Appearance ....................4 3 Terminals and Wiring ................... 5 3.1 Terminals and Interfaces Description............... 5 3.2 Wiring Description ....................
  • Page 8 Video Intercom Vandal-Resistant Door Station·User Manual 8.2.1 Adding Online Device ..................47 8.2.2 Adding by IP Address ..................48 8.2.3 Adding by IP Segment ..................48 8.3 Configuring Devices Remotely ................49 8.3.1 System ......................49 8.3.2 Video Intercom ....................54 8.3.3 Network ......................62 8.3.4 Video Display ....................67 8.4 Video Intercom Device Set-up Tool ...............

  • Page 9: Overview

    Video Intercom Vandal-Resistant Door Station·User Manual 1 Overview 1.1 Introduction The vandal- resistant door station has passed IK 9 (Impact Protection Level). Featuring in the vandal- resistant design, convenient installation, and easy operation, it supports the video intercom function, access control function, door magnetic alarm, motion detection, and so on.
  • Page 10 Video Intercom Vandal-Resistant Door Station·User Manual  Noise suppression and echo cancellation  H.264 video compression standard  Low illumination Alarm Functions  Supports door magnetic alarm  Auto-uploads alarm messages to the master station or the client software Remote Controls ...

  • Page 11: Typical Application

    Video Intercom Vandal-Resistant Door Station·User Manual 1.3 Typical Application Indoor Station Client Software Indoor Indoor Extension 1 Extension 2 Video/Audio Distributor Center Master Station (Master Station) Switch Resident 1 Estate LAN Master Station in Guard's Room Network Cable Optical Fiber Switch One Resident Outer Door Station...

  • Page 12: Appearance

    Video Intercom Vandal-Resistant Door Station·User Manual 2 Appearance Figure 2-1 Door Station Overview Table 2-1 Components Description Description Microphone Built-in Camera Low Illumination Supplement Light Call Button Loudspeaker Note:  Default settings of call button: when you press the call button, it calls the resident; and when you hold down the call button, it calls the center.

  • Page 13: Terminals And Wiring

    Video Intercom Vandal-Resistant Door Station·User Manual 3 Terminals and Wiring 3.1 Terminals and Interfaces Description Figure 3-1 Terminals and Interfaces Table 3-1 Terminals and Interfaces Description Name Interfaces Description Power 12 VDC 12 VDC Power Supply Input Supply Network Interface (PoE Supported) Alarm Input ALARM Grounding...

  • Page 14: Door Magnetic Wiring

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 3-2 Door Lock Wiring 3.2.2 Door Magnetic Wiring To connect door magnetic, it is required to set the output of terminal AI to be door status via Batch Configuration Tool or the client software or the web browser. Figure 3-3 Door Magnetic Wiring 3.2.3 Exit Button Wiring To connect exit button, it is required to set the output of terminal AI to be door status...

  • Page 15: Alarm Device Input Wiring

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 3-4 Exit Button Wiring 3.2.4 Alarm Device Input Wiring When you set the output of terminal AI to be custom via Batch Configuration Tool or the client software or the web browser, you can connect any alarm input device to the door station via the terminal AI.

  • Page 16: Installation

    Video Intercom Vandal-Resistant Door Station·User Manual 4 Installation Before you start:  Make sure the device in the package is in good condition and all the assembly parts are included.  The device supports two ways of power supply: 12 VDC, or PoE power supply. Please make sure your power supply matches your door station.
  • Page 17 Video Intercom Vandal-Resistant Door Station·User Manual Figure 4-2 Install the Plate 2. Insert terminal blocks into the interfaces of the door station body, and connect the network cable. Interfaces Network (Power, Alarm Interface In, Alarm Out) Network Cable Terminal Blocks Figure 4-3 Insert Terminals and Network Cable 3.
  • Page 18 Video Intercom Vandal-Resistant Door Station·User Manual Protective Shield Door Station Main Body Figure 4-4 Fix the Main Body to the Shield 4. Hook the door station to the wall mounting plate tightly. Figure 4-5 Hook the Door Station to the Plate 5.
  • Page 19 Video Intercom Vandal-Resistant Door Station·User Manual Figure 4-6 Secure the Door Station...

  • Page 20: Activating Door Station

    Video Intercom Vandal-Resistant Door Station·User Manual 5 Activating Door Station Purpose: You are required to activate the device first by setting a strong password for it before you can use the device. Activation via Batch Configuration Tool, Activation via Web Browser, and activation via the client software are supported.

  • Page 21: Activation Via Batch Configuration Tool

    Video Intercom Vandal-Resistant Door Station·User Manual 5.2 Activation via Batch Configuration Tool Steps: 1. Run the Batch Configuration Tool. Figure 5-2 Select Inactive Device 2. Select an inactivated device and click Activate. Figure 5-3 Activation Interface (Batch Configuration Tool) 3. Create a password, and confirm the password. STRONG PASSWORD RECOMMENDED–...

  • Page 22: Activation Via Client Software

    Video Intercom Vandal-Resistant Door Station·User Manual 5.3 Activation via Client Software Steps: 1. Run the the client software. Figure 5-4 Select Inactive Device 2. Select an inactivated device and click the Activate. Figure 5-5 Activation Interface (Client Software) 3. Create a password, and confirm the password. STRONG PASSWORD RECOMMENDED–...
  • Page 23 Video Intercom Vandal-Resistant Door Station·User Manual  You can hold the Ctrl or Shift key to select multiple devices in the online devices, and click Activate to activate devices in batch.

  • Page 24: Local Operation

    Video Intercom Vandal-Resistant Door Station·User Manual 6 Local Operation Before you start:  Make sure the door station has been activated.  Make sure the network cable is well-connected. Purpose: You can call the resident (the indoor station) or the center (the master station) via the door station by pressing or holding the call button.

  • Page 25: Remote Operation Via Web Browser

    Video Intercom Vandal-Resistant Door Station·User Manual 7 Remote Operation via Web Browser 7.1 Access to the Door Station System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: 32-bit Internet Explorer 8.0 to 11 Steps: 1.

  • Page 26: Live View

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-2 Download and Install Plug-in Note:  You may have to close the web browser to install the plug-in. Please reopen the web browser and log in again after installing the plug-in.  If the device is not activated, please activate the device first. ...

  • Page 27: Starting Live View

    Video Intercom Vandal-Resistant Door Station·User Manual Descriptions of the live view page: Figure 7-3 Live View Page Menu Bar: Click the tab to enter Live View, and Configuration page respectively. Live View Window: Display the live video on the display window of live view. Toolbar: Set the stream type, enable/disable the two-way audio, unlock the door, start/stop the live view, capture pictures, record the video files, and adjust the audio volumes.

  • Page 28: Recording And Capturing Pictures Manually

    Video Intercom Vandal-Resistant Door Station·User Manual Table 7-1 Descriptions of Live View Icons Icon Description Set the stream type as main stream or sub stream Enable/disable the two-way audio. Unlock the door. Start/stop the live view. Capture pictures manually. Start/stop recording. Audio on and adjust the audio volume.

  • Page 29: Configuring System Settings

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-4 Local Configuration 2. Configure the image file settings and the record file settings. Image File Settings: Set the saving path of the captured pictures. It is valid for the captured pictures you captured with the web browser. •...
  • Page 30 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-5 Device Basic Information Time and DST Settings Purpose: You can follow the instructions in this section to configure the time synchronization and DST settings.  Time Settings Steps: 1. Enter the Time Settings interface: Configuration > System > System Settings > Time Settings.
  • Page 31 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-6 Time Settings 2. Select the time zone of your location from the drop-down list. 3. Synchronize the time. • Synchronizing Time by NTP Server 1) Check the NTP item to enable the NTP function. 2) Configure the following settings: Server Address: IP address of NTP server.
  • Page 32 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-7 Time Sycn. Manually 4) (Optional) You can check the checkbox of Sync. with computer time to synchronize the time of the device with that of the local PC that runs the web browser.
  • Page 33 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-8 DST Settings Upgrade and Maintenance Purpose: On Upgrade & Maintenance interface, you can reboot the door station, restore door station parameters, export/import configuration parameters, and upgrade firmware. Enter the Upgrade and Maintenance interface: Configuration >...
  • Page 34 Video Intercom Vandal-Resistant Door Station·User Manual Click Restore All to restore all parameters of device and reset the device to inactive status. Note:  By clicking Restore, all default settings, excluding network parameters and user information, will be restored.  By clicking Restore All, all default settings, including network parameters and user information, will be restored.
  • Page 35 Video Intercom Vandal-Resistant Door Station·User Manual 2. Set the log search conditions to specify the search, including the major type, minor type, start time and end time. 3. Click Search to search log files. The matched log files will be displayed on the Log interface.

  • Page 36: Configuring Video Intercom Parameters

    Video Intercom Vandal-Resistant Door Station·User Manual Note: Only password can be changed. 7.3.3 Configuring Video Intercom Parameters Door Station No. Purpose: To call the door station via the client software or to call indoor stations/the client software/the master station via the door station successfully, you should number the door station first.
  • Page 37 Video Intercom Vandal-Resistant Door Station·User Manual  If the device No. is set to 0, the door station works as the main door station.  If the device No. is larger than 0, the door station works as the sub door station. The device No.
  • Page 38 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-15 Set the Access Control Parameters 2. Set the door No., and the door-unlocked duration. Note:  The door-unlocked duration varies from 1s to 255s.  The door station, instead of the doorphone, supports configuring the access control parameters.
  • Page 39 Video Intercom Vandal-Resistant Door Station·User Manual Door Status: The AI terminal supports connecting to the door magnetic. Custom: It is reserved. 3. Set the output mode: Disabled, Electric Lock, Custom. Disabled: The function of the NO/NC/COM terminal is disabled. Electric Lock: The NO/NC/COM terminal supports connecting to the electric lock (electric strike, and magnetic lock).

  • Page 40: Configuring Network Settings

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-18 Set the Supplement Light 2. Select the working mode for the door station: Video Intercom Device, Front-end Device. If you select the Video Intercom Device, the door station functions as a video intercom device, while if you select the Front-end Device, the door station functions as a camera only.
  • Page 41 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-19 Set the TCP/IP 2. Set the basic network settings, including IPv4 address, IPv4 subnet mask, and IPv4 default gateway. 3. Set the DNS server. Input the preferred DNS server, and the alternate DNS server. 4.
  • Page 42 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-20 Set the Linked Network 2. Set the SIP server address, the center IP address, and the center port. 3. Click Save to save the settings. Port Settings Purpose: You can set the port No. of the door station, e.g. HTTP port, HTTPS port, and server port. Steps: 1.
  • Page 43 Video Intercom Vandal-Resistant Door Station·User Manual A reboot is required for the settings to take effect. FTP Settings Purpose: You can configure the FTP server related information to enable the uploading of the captured pictures to the FTP server. Steps: 1.
  • Page 44 Video Intercom Vandal-Resistant Door Station·User Manual Directory: In the directory structure, you can select the root directory, parent directory and child directory. Anonymous Access to the FTP Server (The user name and password won’t be required.): Check the checkbox of Anonymous to enable the anonymous access to the FTP server.
  • Page 45 Video Intercom Vandal-Resistant Door Station·User Manual 3. Configure the following settings: Sender: The name of the email sender. Sender’s Address: The email address of the sender. SMTP Server: IP address or host name (e.g., smtp.263xmail.com) of the SMTP Server. SMTP Port: The SMTP port. The default TCP/IP port for SMTP is 25 (not secured). E-mail Encryption: None and SSL are selectable.

  • Page 46: Configuring Video/Audio Settings

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-24 HTTPS Settings 2. Check the checkbox of Enable to enable the function. 3. Click Save to save the settings. 7.3.5 Configuring Video/Audio Settings Video Settings Steps: 1. Enter the video settings interface: Configuration > Video/Audio > Video. Figure 7-25 Video Settings (Main Stream) 2.

  • Page 47: Configuring Image Parameters

    Video Intercom Vandal-Resistant Door Station·User Manual 3. Set the following parameters for the selected main stream or sub-stream. Video Type: Select the stream type to video stream, or video & audio composite stream. The audio signal will be recorded only when the Video Type is Video & Audio.
  • Page 48 Video Intercom Vandal-Resistant Door Station·User Manual You can set the image quality of the door station, including brightness, contrast, saturation, sharpness, etc. Steps: 1. Enter the display settings interface: Configuration > Image> Display Settings Figure 7-27 Display Settings 2. Set the image parameters of the door station. ...

  • Page 49: Configuring Event Settings

    Video Intercom Vandal-Resistant Door Station·User Manual 1. Enter the OSD Settings interface: Configuration > Image > OSD Settings. Figure 7-28 OSD Settings 2. Check the corresponding checkbox to select the display of camera name, date or week if required. 3. Edit the camera name in the text field of Camera Name. 4.
  • Page 50 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-29 Motion Detection Settings 2. Check the checkbox of Enable Motion Detection. 3. Click Draw Area. Drag the mouse on the live video to draw a motion detection area. Click Stop Drawing to finish drawing one area. 4.
  • Page 51 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-30 Arming Schedule Setting 2. Click on the time bar and drag the mouse to select the time period. Note: Click on the selected time period, you can adjust the time period to the desired time by either moving the time bar or input the exact time period.
  • Page 52 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-32 Linkage Method Settings Notify Surveillance Center: Send an exception or alarm signal to remote management software when an event occurs. Send Email: Send an email with alarm information to a user or users when an event occurs.
  • Page 53 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-33 Alarm Uploading Settings 2. Check the checkbox of Delayed Door Alarm. 3. Click Save to save the settings.

  • Page 54: Remote Operation Via Batch Configuration Tool

    Video Intercom Vandal-Resistant Door Station·User Manual 8 Remote Operation via Batch Configuration Tool Purpose: You can operate configure the device remotely via the Batch Configuration Tool. Before operating and configuring the device via the Batch Configuration Tool, you should activate the device first. For detail information about activation, please refer to 5 Activating Door Station.

  • Page 55: Adding Device

    Video Intercom Vandal-Resistant Door Station·User Manual Note:  The default port No. is 8000.  After editing the network parameters of device, you should add the devices to the device list again. 8.2 Adding Device Before you start: Make sure the device to be added has been activated. Purpose: To configure the activated device via batch configuration tool and the client software remotely, you should add the device to the tool or the software firstly.

  • Page 56: Adding By Ip Address

    Video Intercom Vandal-Resistant Door Station·User Manual 3. Input the user name and password. 4. Click OK to save the settings. Note:  Only devices successfully logged in will be added to the device list for configuration.  If you add devices in batch, please make sure selected devices have the same user name and password.

  • Page 57: Configuring Devices Remotely

    Video Intercom Vandal-Resistant Door Station·User Manual You can add many devices at once whose IP addresses are among the IP segment. Steps: 1. Click to pop up the adding devices dialog box. Figure 8-7 Adding Button 2. Select IP Segment in the adding mode drop-down list. 3.
  • Page 58 Video Intercom Vandal-Resistant Door Station·User Manual Device Information Click System –> Device Information to enter device basic information interface. You can view basic information (the device type, and serial No.), and version information of the device. Figure 8-10 Device Information General Click System –>...
  • Page 59 Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-12 Time Settings 2. Select Time Zone or Enable NTP.  Time Zone Select a time zone from the drop-down list menu. Click the Synchronization button.  Check the checkbox of Enable NTP to enable NTP. Input the server address, NTP port, and synchronization interval.
  • Page 60 Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-13 System Maintenance 5. Click Reboot and the system reboot dialog box pops up. Click Yes to reboot the system. 6. Click Restore Default Settings to restore the default parameters. 7. Click Restore All to restore all parameters of device and reset the device to inactive status.
  • Page 61 Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-15 Export File 10. Click to select the upgrade file and click Upgrade to remote upgrade the device. The process of remote upgrade will be displayed in the process bar. Figure 8-16 Remote Upgrade Note: ...

  • Page 62: Video Intercom

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-17 Select User Name 2. Select the user to edit and click Modify to enter the user parameter interface. Figure 8-18 Modify User Information 3. Input the new password, and confirm it. 4. Click Save to realize the editing of password. Note: ...

  • Page 63: Time Parameters

    Video Intercom Vandal-Resistant Door Station·User Manual ID Configuration Purpose: To call the door station via the client software or to call indoor stations/the client software/the master station via the door station successfully, you should number the door station first. You should set the community No., the building No., the unit No., and the floor No.
  • Page 64 Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-20 Time Parameters Note: For door station, maximum speaking time and maximum message time should be configured. Maximum speaking time varies from 90s to 120s, and maximum message time varies from 30s to 60s. Access Control and Elevator Steps: 1.
  • Page 65 Video Intercom Vandal-Resistant Door Station·User Manual Note: This function only applies to door stations, except for the doorphone. IO Input and Output IO input/output refers to the Alarm In terminal and the Alarm Out terminal. You can connect external devices to the door station via these terminals. The door station has 1 Alarm In terminal (AI), and 1 Alarm Out terminal (NO/COM/NC).
  • Page 66 Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-23 Volume Configuration 2. Slide the slider to adjust the volume input and volume output. 3. Click Save to enable the settings. Call Button Steps: 1. Click Video Intercom -> Call Button to enter the call button settings interface. Figure 7-1 Call Button Settings Interface 2.
  • Page 67 Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-2 Motion Detection Settings Interface 2. Check the checkbox of Enable Motion Detection. 3. Click and drag the mouse on the live video to draw motion detection area. 4. (Optional) Click , then the whole live video screen belongs to the draw motion detection area.
  • Page 68 Video Intercom Vandal-Resistant Door Station·User Manual 2. Edit a template and save it. Note: Up to 9 templates are supported to be set manually. 1) Select a template, e.g., Template 01, and click Edit on the upper right corner to the template editing interface.
  • Page 69 Video Intercom Vandal-Resistant Door Station·User Manual Weekday Template: The motion detection area is armed during the working time period of each day. The working time period here is from 8 am to 8 pm. 4. (Optional) If you select Custom, you should manually set the time period. The way is same with the settings of template 1.

  • Page 70: Network

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 7-7 Supplement Light Mode Settings Interface 2. Select the supplement light mode: Auto, Schedule. Auto: The camera of the door station switches between the day mode and the night mode according to the illumination automatically. Schedule: The camera of the door station switches between the day mode and the night mode according to the configured time period.
  • Page 71 Video Intercom Vandal-Resistant Door Station·User Manual  After editing the local network parameters of device, you should add the devices to the device list again. Linked Devices Network Configuration Purpose: In the linked devices network configuration interface, you can configure the network parameters of master stations, SIP servers and management centers of the same LAN.
  • Page 72 Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-27 FTP Configuration 2. Check the checkbox of Enable Main FTP. 3. Select IP address from the drop-down list of server mode. 4. Input the FTP server address, and port No.. 5. Check the checkbox to enable the anonymity (optional). 6.
  • Page 73 Video Intercom Vandal-Resistant Door Station·User Manual 2. Set the DNS server address in the Advanced Settings interface. 3. Click Network -> Email to enter the email settings interface. Figure 8-28 Email Configuration 4. Input the user name, password, and confirm the password. 5.
  • Page 74 Video Intercom Vandal-Resistant Door Station·User Manual For your privacy and to better protect your system against security risks, we strongly recommend the use of strong passwords for all functions and network devices. The password should be something of your own choosing (using a minimum of 8 characters, including at least three of the following categories: upper case letters, lower case letters, numbers and special characters) in order to increase the security of your product.

  • Page 75: Video Display

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-31 DNS Server Settings Interface 2. Set the DNS server address 1 and the DNS server address 2. 3. Click Save to save the settings. Video Display 8.3.4 Video Parameters Steps: 1. Click Video Display -> Video Parameters to enter the video parameters interface. Figure 8-32 Video Display 2.
  • Page 76 Video Intercom Vandal-Resistant Door Station·User Manual Click Restore Default Settings to restore all parameters, excluding network parameters and user information, to the factory settings. Video Display (OSD Settings) Purpose: On the video display interface, you can set OSD (On-screen Display) parameters, including the camera name, time/date format, and display mode on the live view.

  • Page 77: Video Intercom Device Set-Up Tool

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-34 Video/Audio Settings (Main Stream) 2. Select the stream type of the door station to main stream or sub-stream. The main stream is usually for the live view with good bandwidth, and the sub-stream can be used for the live view when the bandwidth is limited.

  • Page 78: Setting A Community Structure

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-35 Video Device Set-up Tool Setting a Community Structure 8.4.1 Set a community structure in the video intercom device set-up tool first, based on the real community situation, and then assign devices to the community accordingly. Figure 8-36 Setting a Community Structure Setting Main/Sub Door Station 8.4.2...
  • Page 79 Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-37 Set a Main Door Station 2. Select the door station type from the drop-down list menu: Door Station for Unit, or Door Station for Villa. 3. Input the main door station start IP address, set the main door station floor No., and then click Calculate to generate the main door station end IP address and main door station No.
  • Page 80 Video Intercom Vandal-Resistant Door Station·User Manual Setting Sub Door Stations Steps: 1. Select the community, and press the Sub Door Station tab to switch to the sub door station configuration interface. Figure 8-38 Set Sub Door Stations 2. Select the door station type from the drop-down list menu: Door Station for Unit, or Door Station for Villa.

  • Page 81: Batch Upgrading

    Video Intercom Vandal-Resistant Door Station·User Manual  For the login password, if the sub door station has been activated, input the activation password here. If the sub door station is not activated, create a login password here, and the sub door station will be activated simultaneously. ...
  • Page 82 Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-40 Login 2. Select a device, input the user name and password, and click Login Device. 3. Click Add Device, and the device is added to the batch upgrading tool. Figure 8-41 Online Devices...

  • Page 83: Upgrading Devices

    Video Intercom Vandal-Resistant Door Station·User Manual Adding by IP Address/IP Segment Steps: 1. Click Manual to open the device adding window. 2. Input the corresponding information (IP address, user name, password, start IP address, end IP address). 3. Click Add. Figure 8-42 Adding by IP Address/IP Segment Upgrading Devices 8.5.2...
  • Page 84 Video Intercom Vandal-Resistant Door Station·User Manual Figure 8-43 Upgrade by File 3. Open the upgrading file, and click Upgrade. Online Upgrading Online Upgrading: The batch upgrading tool will search the latest upgrading file for the device automatically. You upgrade the device or devices via the local upgrade files. Steps: 1.

  • Page 85: Remote Operation Via Client Software

    Video Intercom Vandal-Resistant Door Station·User Manual 9 Remote Operation via Client Software The Video Intercom module provides remote control and configuration on video intercom products via the client software. Before remote configure and control the video intercom, you are required to add the device to the software first.

  • Page 86: Device Management

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-1 System Configuration Interface 9.2 Device Management Purpose: Device management includes device activation, adding device, editing device, and deleting device, and so on. After running the client software, video intercom devices should be added to the client software for remote configuration and management.
  • Page 87 Video Intercom Vandal-Resistant Door Station·User Manual 1. Click the icon on the control panel, or click Tools->Device Management to open the Device Management page. 2. Click the Server tab. To add indoor station or master station: Click Add New Device Type to enter add new device type interface. Select Indoor Station/Master Station and click OK.
  • Page 88 Video Intercom Vandal-Resistant Door Station·User Manual 6. Input the required information. Nickname: Edit a name for the device as you want. Address: Input the device’s IP address. The IP address of the device is obtained automatically in this adding mode. Port: Input the device port No..

  • Page 89: Modifying Network Information

    Video Intercom Vandal-Resistant Door Station·User Manual If you want to add all the online devices to the client software, click Add All and click OK in the pop-up message box. Then input the user name and password for the devices to be added.
  • Page 90 Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-4 Reset Password (Option 1) 1. Click Export to save the device file on your computer. 2. Send the file to our technical engineers. 3. Our technical engineer will send you a file to you. After receiving a file from the technical engineer, select Import File from Key Importing Mode drop-down list and click to import the file.

  • Page 91: Configuring Devices Remotely Via Client Software

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-5 Reset Password (Option 2) 1. Click Export to save the device file on your computer. 2. Send the file to our technical engineers. 3. Click Import and select the file received from the technical engineer. 4.

  • Page 92: Adding Storage Server

    Video Intercom Vandal-Resistant Door Station·User Manual Note:  This function is only available to door stations.  You are required to add storage server to the client software, and format the HDDs first before uploading and storing captured pictures. 9.4.1 Adding Storage Server Before you start: The storage server application software needs to be installed and it is packed in the the software package.

  • Page 93: Formatting The Hdds

    Video Intercom Vandal-Resistant Door Station·User Manual 9.4.2 Formatting the HDDs The HDDs of the storage server need to be formatted for the captured picture storage. Steps: 1. Select the added storage server from the list and click Remote Config. 2. Click Storage->General to enter the HDD Formatting interface. 3.
  • Page 94 Video Intercom Vandal-Resistant Door Station·User Manual 1. Open the Record Schedule page. 2. Select the camera from the Camera Group list. 3. Select the storage server from the Storage Server drop-down list. Note: You can click Storage Server Management to add, edit or delete the storage server.

  • Page 95: Live View

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-9 Setting Quota Example: If you set the picture quota as 60%, then the 60% of the storage space can be used for storing the captured pictures. 6. Click Save to save the settings. 9.5 Live View Purpose: The live view page allows you to view the real-time video, capture images, and unlock...
  • Page 96 Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-3 Live View of Doo Station 2. Right click on the live view interface to display the menu and select Unlock to remote unlock the door. Figure 9-4 Menu of Live View Interface...

  • Page 97: Video Intercom Configuration

    Video Intercom Vandal-Resistant Door Station·User Manual 9.6 Video Intercom Configuration Click the icon on the control panel of the client software or click View -> Video Intercom to open the Video Intercom page. On the Video Intercom page, you can control video intercom devices remotely.

  • Page 98: Group Management

    Video Intercom Vandal-Resistant Door Station·User Manual 9.6.1 Group Management Purpose: You can add groups to community, outer door station, or other, and assign devices to each group. Click Control Panel -> Video Intercom -> Group Management to add, edit, and delete groups.
  • Page 99 Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-12 Adding Community  Select Outer Door Station as group type, and then input the outer door station No. (Range: 1 to 9) to set the outer door station, as shown in the figure below.
  • Page 100 Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-14 Adding Other For example: You can name the group as administrator, entrance guard and cleaning staff, etc. Note: When selecting Other as the group type, you can set different groups for staff other than residents, such as administrator, security guard and cleaning staff, etc., and you can assign cards to these staff and configure different permissions to them.
  • Page 101 Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-15 Adding Resident 2. Check the checkbox of device. Indoor Station: set a Room No. for the indoor station. Door Station: set a No. for the door station. 3. Click OK to save the settings. Assigning Analog Devices to Group When assigning analog devices to group, only analog indoor stations are supported.
  • Page 102 Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-16 Adding Devices in Batch Note: Room Numbers here refers to the room numbers in each floor.  Adding Devices Singlly: Input the room No.. Figure 9-17 Adding Device Singly Note: The room No. format is like 101. 2.

  • Page 103: Video Intercom

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-18 Modifying Device Information 3. Click OK to complete the device modifying operation. Deleting Device 1. Select an added device. 2. Click Remove to pop up a dialog box. Figure 9-19 Information 3. Click OK to complete the group deleting operation. 9.6.2 Video Intercom Receiving Call from Door Station Purpose:...
  • Page 104 Video Intercom Vandal-Resistant Door Station·User Manual  Make sure the SIP server IP address of the door station is not configured (or abnormal). Steps: Press Calling Center key on the door station. Figure 9-20 Calling from Door Station Note:  When the SIP server IP of the door station is configured, press Calling Center key on the door station to call the master station instead of the client software.

  • Page 105: Notice Management

    Video Intercom Vandal-Resistant Door Station·User Manual 9.6.3 Notice Management Querying Call Logs Steps: 1. Click Query Call Logs to enter the call log querying page. 2. Select the calling status, device type, and set the start time and end time, and click Query to search the call log.

  • Page 106: Device Arming Control

    Video Intercom Vandal-Resistant Door Station·User Manual Figure 9-22 Unlocking Log Interface 3. Click Export to export the unlocking logs as an excel file. 9.7 Device Arming Control Steps: 1. Select Tool->Device Arming Control to pop up device arming control window. Figure 9-23 Tool Bar...
  • Page 107 Video Intercom Vandal-Resistant Door Station·User Manual 2. Set the arming status of the device as armed, and the alarm information will be auto uploaded to the client software when alarm occurs. Figure 9-24 Device Arming Control Figure 9-25 Alarm Events Note: After adding the device to the client software, it will be armed automatically.

  • Page 108: Appendix

    Video Intercom Vandal-Resistant Door Station·User Manual Appendix Installation Notice While installing the door station, please make sure that the distance between any two devices is far as possible to avoid the howling and echo. The distance between two devices is recommended to be longer than 10 meters. Devices here refer to indoor station, door station, doorphone and master station.
