Max Control ASX-8 User Manual

Programmable audio switcher
Hide thumbs

Advertisement

Table of Contents

ASX-8
Programmable Audio Switcher
User Manual
Version 1.0
May 2012
Max Control

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASX-8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Max Control ASX-8

  • Page 1 ASX-8 Programmable Audio Switcher User Manual Version 1.0 May 2012 Max Control...

  • Page 2: Table Of Contents

    Index DESCRIPTION ............................3 OPERATION............................3 PRODUCT CARE ..........................5 SPECIFICATIONS ..........................6 MIDI IMPLEMENTATION CHART ....................7 WARRANTY ............................8 CONTACT .............................. 8...

  • Page 4: Description

    This switcher is built with high quality parts in order to bring you the best performance. Description Max Control ASX-8 is a programmable MIDI audio switcher with 8 relay-operated true bypass audio loops, an A/B output selector, LCD display, and an intuitive user interface.
  • Page 5 Cancel to discard the changes. To control the ASX-8, any standard MIDI foot controller can be used. There are 1024 presets organized in 8 banks of 128. Use control change 0 with values from 0 to 7 to select bank, then program change to recall a preset.

  • Page 6: Product Care

    Product Care Try to avoid cleaning the device with solvent or abrasive products. Keep the device dry and away from dust. Don’t connect power loads like lamps or loudspeakers to the audio loop. Keep ventilated.

  • Page 7: Specifications

    Specifications • Fully programmable. • 8 relays-operated true bypass audio loops. • A/B output selector • Responds to control change and program change MIDI messages. • 8 loop status LEDs. • MIDI IN and OUT/THRU connectors. • 1024 user presets. •...

  • Page 8: Midi Implementation Chart

    MIDI Implementation Chart Function... Transmitted Recognized Remarks Basic Default Channel Changed 1 - 16 Note Number Control 0-127 Change Prog 0- 127 Change System Exclusive Notes O = Yes x = Not implemented...

  • Page 9: Warranty

    (2) Any damage resulting from physical abuse or failure to follow the operating instructions. Max Control’ liability to the owner and under this warranty is limited only to the repair or replacement of the defective product. Call or write to Max Control prior to shipping the product for repair.
