Summary of Contents for RF Window ICS-F0837
-
Page 1: User Manual
FCC ID : X4O-ICS-F0837 ATTACHMENT E. - USER MANUAL - HCT CO., LTD. SAN 136-1, AMI-RI, BUBAL-EUP, ICHEON-SI, KYOUNGKI-DO, 467-701, KOREA TEL:+82 31 639 8517 FAX:+82 31 639 8525 www.hct.co.kr Report No. : HCTR1002FR09... - Page 2 ICS-F0837 User Manual <Interference Cancellation System for WCDMA or CDMA 5 Watt> 2010. 1...
-
Page 3: Table Of Contents
5.1. ICM (Interference Cancellation Module) .............. 24 5.1.1. ICM 24 5.2. Filter ........................25 5.2.1. Donor & Service Duplexer................25 5.3. Dual HPA ......................26 5.3.1. Dual HPA......................26 RF Window Co., Ltd. | 2 ICS-F0837 User manual/Confidential & Proprietary... - Page 4 6.4. Auto Recovery ..................... 36 6.4.1. Objective ......................36 6.4.2. Procedure......................36 6.5. Up Link Auto Shutdown Mode................36 6.5.1. Objective ......................36 6.5.2. Procedure......................36 6.6. NMS Operation ....................37 RF Window Co., Ltd. | 3 ICS-F0837 User manual/Confidential & Proprietary...
- Page 5 8.1.1. Configuration....................38 8.1.2. Installation ....................... 38 8.1.3. Check List before operation ................39 8.1.4. RF Monitor Port....................39 8.2. Process of ICS Repeater setup and installation ..........40 RF Window Co., Ltd. | 4 ICS-F0837 User manual/Confidential & Proprietary...
-
Page 6: Rf Window Co., Ltd
ICS Repeater ICS-W0837B User Manual 8.3. Fault / Alarm Handling..................41 8.3.1. Down Link / Up Link ALARM Handling............41 8.3.2. Environment Alarm..................42 Manufacturer Information..................43 RF Window Co., Ltd. | 5 ICS-F0837 User manual/Confidential & Proprietary... - Page 7 [FIGURE - 20] GUI DOWN LINK SETUP STATUS 오류! 책갈피가 정의되어 있지 않습니다. [FIGURE - 21] GUI UP LINK SETTING STATUS .. 오류! 책갈피가 정의되어 있지 않습니다. [FIGURE - 22] GUI WCDMA(3G) CONTROL WINDOW 오류! 책갈피가 정의되어 있지 않습 RF Window Co., Ltd. | 6 ICS-F0837 User manual/Confidential & Proprietary...
- Page 8 [FIGURE - 24] GUI DEBUG WINDOW ....오류! 책갈피가 정의되어 있지 않습니다. [FIGURE - 25] SIGNAL STATUS WINDOW ..오류! 책갈피가 정의되어 있지 않습니다. [FIGURE - 26] PROCESS OF ICS REPEATER SETUP AND INSTALLATION ....40 RF Window Co., Ltd. | 7 ICS-F0837 User manual/Confidential & Proprietary...
- Page 9 [TABLE - 19] UP LINK CONTROL ITEM ....오류! 책갈피가 정의되어 있지 않습니다. [TABLE - 20] SYSTEM CONFIGURATION................38 [TABLE - 21] AC CONNECTOR PIN ASSIGN ..............38 [TABLE - 22] SYSTEM CONNECTION PORT..............39 [TABLE - 23] RF MONITOR PORT..................39 RF Window Co., Ltd. | 8 ICS-F0837 User manual/Confidential & Proprietary...
- Page 10 ICS Repeater ICS-W0837B User Manual [TABLE - 24] DOWN LINK / UP LINK ALARM HANDLING ..........42 [TABLE - 25] ENVIRONMENT ALARM................42 RF Window Co., Ltd. | 9 ICS-F0837 User manual/Confidential & Proprietary...
-
Page 11: System Overview
ICS-F0837 is a digital repeater that provides optimized service with ICS (Interference Cancellation System) to make the most efficient way to enhance WCDMA network. ICS-F0837 consists of the same construction as normal RF repeater except DSP (Digital Signal Processing) part and it can overcome oscillation problem caused by lack of the isolation level between donor and coverage antennas. -
Page 12: System Network Configuration
ICS Repeater ICS-W0837B User Manual 2. System Network Configuration 2.1. Service for Network ICS-F0837 can provides Cell Coverage to a Node-B with using PAU and it is for expansion of WCDMA Cell Coverage. The System Network Configuration of ICS-F0837 is shown as below... -
Page 13: Nms Network
ICS Repeater ICS-W0837B User Manual Input level of ICS-F0837 is air interfaced with RF signal of WCDMA transferred from Node-B and mobile through Donor and Service Antenna. The system consists of ICM that cancels feedback signals, RF signal amplifier, monitoring and control processor, and modem to operate with NMS (Optional). -
Page 14: System Specification
VSWR < 1.5 : 1 TX/RX Isolation > 110dBc Noise Figure < 7dB @Max. Gain ≥ 45dBc @Fc±5MHz Out-Band ACLR ≥ 50dBc @Fc±10MHz 2nd Harmonics > 80dBc Impedance 50ohm RF Window Co., Ltd. | 13 ICS-F0837 User manual/Confidential & Proprietary... - Page 15 EVM : < 12.5% General G = I + 10dB Gain Variation : < ±2dB Operating EVM : < 12.5% G = I 10Hz Fast Fading Gain Variation : < ±2dB RF Window Co., Ltd. | 14 ICS-F0837 User manual/Confidential & Proprietary...
- Page 16 TX/RX Isolation > 110dBc Noise Figure < 7dB @Max. Gain Fo±750kHz: 45dBc Fo±1.98MHz: 60dBc Spurious Emissions Fo±3.125MHz: -13dBm/100KHz 2nd Harmonics > 80dBc Impedance 50ohm a) ICS General Performance Specification RF Window Co., Ltd. | 15 ICS-F0837 User manual/Confidential & Proprietary...
-
Page 17: [Table - 1] Rf System Specification
G = I + 10dB Static No Fading Gain Variation : < ±2dB Rho>0.97 General G = I Gain Variation : < ±2dB Operating [Table - 1] RF System Specification RF Window Co., Ltd. | 16 ICS-F0837 User manual/Confidential & Proprietary... -
Page 18: System Configuration
CORE Section4.1.2 NEBS GR-63- Include Monitoring-Control-Alarm CORESection4.1.1 Box panel for security of Proportional repeater Local/Remote Control USB Port at local, Modem(Option) Optional (Mute be) Remote Access Software Setting Under Windows RF Window Co., Ltd. | 17 ICS-F0837 User manual/Confidential & Proprietary... -
Page 19: Environment Specification
305(W) X 565(H) X 194(D) Weight Under 30Kg Convection type Natural convection Mounting Wall & poll (modified based on user request) Cabinet type Outdoor (compliant with IP 65) [Table - 4] Mechanical Specification RF Window Co., Ltd. | 18 ICS-F0837 User manual/Confidential & Proprietary... -
Page 20: Housing
ICS Repeater ICS-W0837B User Manual 4. Housing 4.1. Housing Configuration 4.1.1. System [Figure - 4] Front and Side View RF Window Co., Ltd. | 19 ICS-F0837 User manual/Confidential & Proprietary... -
Page 21: [Figure - 5] Rear View
ICS Repeater ICS-W0837B User Manual [Figure - 5] Rear View RF Window Co., Ltd. | 20 ICS-F0837 User manual/Confidential & Proprietary... -
Page 22: System Block Plan
System Block Plan ② ① ⑤ ④ ③ [Figure - 6] System Block Plan Module Name INTERFACE (with Modem) DUPLEXER (TOP) DUAL HPA (BOTTOM) UPS Interface [Table - 5] Modules RF Window Co., Ltd. | 21 ICS-F0837 User manual/Confidential & Proprietary... -
Page 23: System External Connector Plan
① ③ ④ ② [Figure - 7] System External Connectors Name AC Input Port Bluetooth Modem port Donor Antenna Port Service Antenna Port [Table - 6] System External Connectors RF Window Co., Ltd. | 22 ICS-F0837 User manual/Confidential & Proprietary... -
Page 24: [Table - 7] Mechanical Specification
2. Connector Type : SMA Type Ground M5 2Hole 1. Water proof : outdoor type Environmental 2. ∆T : within 20℃ Condition 3.Vibration : 1G, 10~150Hz, 0.1oct/min, XYZ [Table - 7] Mechanical Specification RF Window Co., Ltd. | 23 ICS-F0837 User manual/Confidential & Proprietary... -
Page 25: Main Module Configuration
DSP to frequency. It is also operated the function of Remote Control Unit through INTERFACE. 5.1.1. ICM [Figure - 8] Down Link/Up Link ICM RF Window Co., Ltd. | 24 ICS-F0837 User manual/Confidential & Proprietary... -
Page 26: Filter
30dB Coupler to monitor Input power. Hence it can enable to measure the signal level and to observe its specification. 5.2.1. Donor & Service Duplexer [Figure - 9] Donor & Service Duplexer RF Window Co., Ltd. | 25 ICS-F0837 User manual/Confidential & Proprietary... -
Page 27: Dual Hpa
VSWR. It has the same mount hole which can be applied for the same specification and configuration according to output power amount (8W/1W) and HPA manufacturer. 5.3.1. Dual HPA [Figure - 10] Down Link PAU RF Window Co., Ltd. | 26 ICS-F0837 User manual/Confidential & Proprietary... -
Page 28: Power Supply
It also has Back-Up Battery terminals so that the service can be provided even if there is power shortage. 5.4.1. Power Supply [Figure - 11] Power Supply RF Window Co., Ltd. | 27 ICS-F0837 User manual/Confidential & Proprietary... -
Page 29: Interface
Debug port is designed based on USB connection 5.5.1. INTERFACE UPS Alarm INTERFACE POWER INTERFACE INTERFACE KEY-PAD MODEM ANTENNA PORT BLUETOOTH ANTENNA PORT INTERFACE UPS Alarm INTERFACE [Figure - 12] INTERFACE RF Window Co., Ltd. | 28 ICS-F0837 User manual/Confidential & Proprietary... -
Page 30: Vfd
ICM, INTERFACE, reverse Dual HPA power PSU Status Status information of Power Supply Unit ICM, Dual HPA, Modem Module Interface Power supply/ Data Interface [Table - 8] INTERFACE Features RF Window Co., Ltd. | 29 ICS-F0837 User manual/Confidential & Proprietary... - Page 31 : 000dB” “ Rvs Status “ Up Link GAIN Setup Mode “ GAINMODE : [GAIN]dB>” [OFF]/[GAIN]/[BAL] “ Rvs Status “ Up Link GAIN Setup Mode “ GAIN : 000dB>” RF Window Co., Ltd. | 31 ICS-F0837 User manual/Confidential & Proprietary...
- Page 32 Battery Use Setup Mode “ BATT : [NOTUSE]>” (Unistall, 29V embedded) “ Environment ” FA Mode Setup Mode “ FAMODE : [MANUAL]>” Manual (FA1~FA4), Auto “ Environment ” “ FAN : [MANUAL]>” RF Window Co., Ltd. | 32 ICS-F0837 User manual/Confidential & Proprietary...
-
Page 33: Key-Pad
Move to P#02 P#02 switch over to MoPe on setting menu Setting Value P#00 P#01 Move to P#00 P#02 Move to P#01 Cancel setiting [Table - 10] Key Feature RF Window Co., Ltd. | 33 ICS-F0837 User manual/Confidential & Proprietary... -
Page 34: Main Features Of System Operation And Monitoring Program
Attenuator is set up to Maximum in order to protect the system 3. Gain Balance Mode 1) Up Link Gain is set up automatically as low as “Gain Balance set-up value compared to Down Link current Gain RF Window Co., Ltd. | 34 ICS-F0837 User manual/Confidential & Proprietary... -
Page 35: Others
1 dB Step from 3 dB less than “max. output power set-up value” 5. Total Power Limit Restoration Attenuator operation: restore Attenuator. up to the value of “max. output power set-up value: 2” 6. Restore preferentially the changed Attenuator. value RF Window Co., Ltd. | 35 ICS-F0837 User manual/Confidential & Proprietary... -
Page 36: Auto Recovery
3. When Up Link output power is OFF, it executes Amp Off alarm and reports Reason 4. If Down Link output power is ON by Auto Recovery feature, then Up Link output power is ON as well RF Window Co., Ltd. | 36 ICS-F0837 User manual/Confidential & Proprietary... -
Page 37: Nms Operation
3. UL ICM LED : Green LED is on when Up Link ICM alarm occurred (Normal : Green) 4. RF LED : Red LED is on when RF module alarm occurred (Normal: Green) 5. Green LED is on when all is normal RF Window Co., Ltd. | 37 ICS-F0837 User manual/Confidential & Proprietary... -
Page 38: System Installation And Setup
Supply the Electrical Power (AC100~260V) Verify if Main Power LED if the connection is correct (Extension code can be used if necessary, not included) Port Connection to Repeater is as follows Item Function RF Window Co., Ltd. | 38 ICS-F0837 User manual/Confidential & Proprietary... -
Page 39: Check List Before Operation
7.1.4. RF Monitor Port Donor Antenna Service Antenna TX(To BTS) RX(from BTS) TX(To Mobile) RX(From Mobile) 15 dB Coupling 30 dB Coupling 40 dB Coupling [Table - 14] RF Monitor Port RF Window Co., Ltd. | 39 ICS-F0837 User manual/Confidential & Proprietary... -
Page 40: Fault / Alarm Handling
Normal : Green Replace the defected Part RF Device Alarm : Red Verify if the Module defected Device ( DL / UL ) Normal : Green Replace the Module RF Window Co., Ltd. | 41 ICS-F0837 User manual/Confidential & Proprietary... -
Page 41: Environment Alarm
Verify if PSU output is 27V DC Alarm Normal : Green Replace PSU Housing Verify Housing Temp. Alarm : Red Temp Normal : Green Alarm [Table - 16] Environment Alarm RF Window Co., Ltd. | 42 ICS-F0837 User manual/Confidential & Proprietary... -
Page 42: Manufacturer Information
ICS Repeater ICS-W0837B User Manual 8. Manufacturer Information RF Window co. ltd. Maker : RF Window Co., Ltd Address: 14F, Daerung Posttower3, 182-4, Guro-3dong, Guro- gu, Seoul, 152-847, South Korea TEL: +82 –2- 2082-1250 RF Window Co., Ltd. | 43...
