Multi Touch Screen/ Interactive Flat

Panel Display

User Manual

TL18.201401202

Please kinly keep this manual for future inquiries.

This manual is used as the LCD all in one tpuch TV manual, the actual product may be slightly different with description.

Table of Contents

Need help?

Do you have a question about the ONESCREEN1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clary-Icon ONESCREEN1

Page 1: User Manual
Multi Touch Screen/ Interactive Flat Panel Display User Manual TL18.201401202 Please kinly keep this manual for future inquiries. This manual is used as the LCD all in one tpuch TV manual, the actual product may be slightly different with description.
Page 2: Table Of Contents
Content Matters Needing Attention......................... 3 Installing Requirement........................5 Carrying capacity.........................5 Abstract heat..........................5 Summary............................. 6 Characteristics..........................6 Basic Operation........................... 7 Turn on............................7 Turn off............................7 Introduction of OSD ..........................8 How To Choose Analog Channel ....................8 How To Choose Application ......................8 Introduction Of “Set ........................9 How To Use TV...........................12 Network Setting........................
Page 3: Safety Considerations
Safety Considerations warning Do not place containers with liquid on or near this product. Use only dry cloth to clean. Do not block any ventilation holes. Install this product according to manufacturer’s User Manual. A distance of at least 16cm must be kept from this product and other objects and/or walls. Do not install this product near heat sources.
Page 4: Installing Requirement
Installing Requirement Carrying capacity Better use the wall mount brackets supplied together with the product, if not, please make sure the carrying capacity is not less than 4 times the actual load weight and make sure the machine can be placed on it stably. Be sure the mounting surface is not less than 4 times the actual load weight.
Page 5: Summary
*Ref to the standard of CAS 132-2006 Summary The interactive tablet is the interactive products based on independent R&D, and a multi-functional teaching equipment set the interactive teaching, multimedia presentation, digital speech, touch operation, handwriting input as a whole. From design to production, we give full consideration to the application characteristics of the field of education.
Page 6: Basic Operation
characteristics of high compression, distortion etc.. variety of selection on pen type,line width,color .  Powerful screen editing function, support real-time editing.  A variety of background selection, support user-defined background, has the image  insertion function for any graphics or picture , . Intelligent identification function of geometric graphics, has various kinds of graphics ...
Page 7: Introduction Of Osd
swith in the middle of the bottm on the machine (near the power interface side) or unplug the power plug.  If the machine has built-in PC, please shut down PC first, and then cut off the power.  Turn on the machine by the power switch, we can see Android characters shows on the right bottom of screen display , which means the Android system is starting and please do not cut off the power supply at this time, only can we cut off the power supply after the Android system finish booting loading.
Page 8: How To Choose Application
1.3 Press “Source”on the front panel or remote control to choose. 2. It will showed as follows after choosing the “Source” 3. When “Source”showed as above, there are three ways to enter it： 3.1 Directly click. 3.2 Select "source" and then automatically enter it. 3.3 Press “▲▼”to select the signal channel wanted and then press "OK"...
Page 9 1.2 Enter from the "Menu" on the remote control . 1.3 Enter from the "Menu" on the front panel . 2. Operate on “Set” through the following two ways: 2.1 Directly click on the icon to choose. ▲▼ 2.2 Press " "...
Page 10 1.1 Directly click on the icon to choose. 1.2 Press“ ▲▼”to select. Press " ◄► " to confirm the submenu and adjust the value. Press " ◄► " to move to the wanted submenu(purple color lights means be selected) *Tuner 1.1 Press “Adjust”to select the submenu.
Page 11 1.3 Press “Adjust”to select the submenu. 1.4 Press“ ▲▼”to select. Press " ◄► " to confirm the submenu and adjust the value. Press " ◄► " to move to the wanted submenu(purple color lights means be selected) *Function 1.1 This button is only for the TV which has 3D function. Press the “Function” to select. 1.2 Press“...
Page 12: How To Use Tv
How To Use TV: Network Setting Choose the net connecting mode and set the right number. Press “main page” to enter the main menu, press " ▲▼◄► " button to select [system setting] and press “enter”to enter the submenu. Press " ▲▼ " button so select “Net Settings”and press“enter”...
Page 13 2) Press "◄► " to select [Search] to enter the network setting, press " ▲▼ " to select the WI-FI network from the list, press " ▲▼ " to select [Next ] and press enter 3) Password: Input the WI-FI password, press “Enter”and then press " ▲▼◄► " to select [Finish] and press“Enter”, then press "...
Page 14: Network Status Lookup
Network Status Lookup Check the connection status of the current network and the detailed information. Remote control...
Page 15 Remote control A 1） Standby: turn on or turn off the machine 2） Mute: mute or restore the sound 3） 0-9 numeric key: selection or input numbers 4） DIS: display the screen 5） CHLISI: program list under TV ,can be edited,deleted or skipped etc 6）...
Page 16 Remote control B 1） Standby: turn on or turn off the machine 2） Indicator: indicator lights if press any button 3） Image mode: select image mode as standard, soft etc 4） Sound Mode: select sound mode as: standard, music, theater etc 5）...
Page 17: Control Panel
33) 3D: turn on and turn off 2D/3D function Attention: Shortcut keys for computer on the remote control work normally when touch TV works normally Control Panel Buttons on front panel  A-Turn On/Off B-Source Input C-Menu D-Volume+ E-Volume- F- Channel+ G-Channel-(Menu item+/-) H- PC turn on/off I- TV USB(input)
Page 18 Buttons on rear panel *When HDMI1/HDMI2/HDMI3 connects to the HDMI of computer or DVD etc When select HDMI1 on “Source”menu, HDMI1 and TOUCHPORT are connected,HDMI2 、 HDMI3 is disconnected. When select HDMI2 on “Source”menu, HDMI2 and TOUCHPORT are connected,HDMI1 、 HDMI3 is disconnected.
Page 19: Switchover Among Three Signals
* AV1-IN、AV2-IN: Connect to the AV output of the DVD * AV-OUT: Connect to the AV-IN of another TV * RF-IN: Input terminal of TV signal * USB1、USB2、USB3.0: Connect to USB Disk * SD CARD: Insert SD CARD * RJ45: Wired internet port Switchover Among Three Signals *When select HDMI1 on “Source”menu, HDMI1 and TOUCHPORT are connected,HDMI2 、...
Page 20  Press the buttons directly with your hand or touch pen  Press EXIT to exit from the full touch interface...
Page 21: Specification Of Pc Mode（Vga Input
Specification Of PC Mode (VGA Input): Horizontal/Ver Horizontal Vertical tical Standar Refresh Resolution Frequency Frequenc synchronizatio Rate(Hz) (Khz) y（Hz） unipolarity （TTL） VESA 640X480 31.5 VESA 640X480 37.9 VESA 640X480 37.5 VESA 800X600 35.1 VESA 800X600 37.9 VESA 800X600 48.1 VESA 800X600 46.9 VESA...
Page 22: Maintaining Guide
Explanation Maintaining Guide Bellowing situation is not production faulty: 1. if there is a little tiny red, blue, green spots on the TV screen (Highlights spots), or dark spot (scotoma) under some picture, it’s not production faulty. because the manufacture of LCD panel requires very sophisticated production technology, it may produce very few pixels too bright or too dark .
Page 23 Self-checking Please check bellowing question accordingly before require a repair. Whether the power plug is properly connected? Whether there is a barrier between the monitor and remote control receiver? Can’t start the machine Don't press the switch too many times in very short time, because it designed a protection.
Page 24: Trouble Shooting
Trouble shooting Problem Causing Solution Touch Port is not connected or USB 1.Please use a new USB cable to test or inspect cable has problem 2. Check if the Touch Port is broken No touch Infrared tube is blocked Ensure the infrared tube is not blocked Need calibration every Infrared tube is blocked or equipped Reposition the serving program after turn off the PC...
Page 25: Fcc
Touch frame trouble shooting solutions Problem 1. Check whether the power cord is connected to the power socket, and whether the power is on 2. Check whether the switch of the screen is opened 3. Check whether the standby button of the panel is opened No sound or image 4.
