GM-8812
ELECTRONIC PIANO
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM-8812 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kaino GM-8812

  • Page 1 GM-8812 ELECTRONIC PIANO MANUAL...
  • Page 2 Welcome to use GME 8812 digital electronic piano Intelligent teaching system Intelligent teaching system can automatically help you learn to play step by step with high efficiency The player can play one or more melodies and at the same time the system play other melodies 88 teaching songs of many kinds in all Teaching songs can be customized so long as customers can...

  • Page 3: General Operation

    General operation 1. GENERAL OPERATION A. Demonstration of teaching songs 1). Turn the power switch to the "on" position. 2). Press the "Demo" button to play the main demonstration song 3). Press any key on the note keyboard and then press the "Demo" button to start a teaching song.
  • Page 4 General operation Example 2: Select NO. 118 timbre, double click "Timbre" button, the indicator display "1-", then press "1" and "8," The NO.118 will be displayed on the indicator, the desired timbre 118 has been reached. Press "+" button to increase timbre number and press "-" to decrease timbre number.
  • Page 5 Styles 2. STYLES A. Style selection The piano provides 100 styles numbered from 00 to 99. Press "Style" button first, and then select digits on the digital keyboard to select target style. Example: Select NO.86 style, press "Style" button, then "8" button and then "6"...
  • Page 6 Styles 3) Variation a. Press "Variation" button, variation light on, the style shifts to its variation melodies. Press "Variation" button again, variation light off, the style shifts to its basic melodies. b. When style being played, press "Synchro/Fill In2" button, the piano will play a fill_in and then shifts to its variation melodies.

  • Page 7: Auto Bass Chord

    Auto Bass Chord 3. AUTO BASS CHORD The piano provide "multi-finger bass chord", 'single-finger bass chord", "manual bass" function. A. Auto bass chord keyboard setting The partial keyboard used to play multi-finger chord, single-finger chord or bass is called "Auto Bass Chord Keyboard". The width of this keyboard can be set by player.
  • Page 8 Auto Bass Chord S i n g l e - f i n g e r c h o r d F#/G F#m/G F#7/G F#m7/G C#/D C#m/D C#7/D C#m7/D G#/A G#m/A G#7/A G#m7/A D#/E D#m/E D#7/E D#m7/E A#/B A#m/B A#7/B A#m7/B 2) Play multi-finger chord When use multi-finger mode to play, the player presses auto bass chord...
  • Page 9 Register C. Keyboard split Press "Split" button, the light turned on, the keyboard is split into two parts, the left keyboard and the right keyboard. The left keyboard keeps old timbre, and timbre selection serves the right keyboard. And the left keyboard note pitch is one octave up, the right keyboard note pitch is one octave down.

  • Page 10: Effect Control

    Effect Control 4. Effect Control A. Transpose Press "Transpose+" and "Transpose-" button to transpose the note keyboard. Press the two buttons together changes the note keyboard normal. B. Vibrato Use "Modulation+", "Modulation-" buttons to control vibrato range. Press "Modulation+" button to increase vibrato, and press "Modulation-" button to decrease vibrato.
  • Page 11 Intelligent Teaching System 5. Intelligent Teaching System The intelligent can help to guide the new player to learn playing in 3 steps. A. Appreciate teaching songs Press down any note on the keyboard, then press "Demo" button to appreciate inner 88 teaching songs. Teaching System LEFT RIGHT...

  • Page 12: Step 2. Follow Me

    Intelligent Teaching System C. Step 2. FOLLOW ME Press down any note on the keyboard, then press " STEP2 " button to start a teaching song ,the light of " STEP2 " turned on. The player can play the song on the keyboard, the piano will follow the player to play.

  • Page 13: Midi Interface

    MIDI Interface and Pedals 6. MIDI Interface Standard MIDI interface MIDI is abbreviation of "Musical Instrument Digital Interface", and is a world-standard communication interface that allows MIDI compatible with other instruments and computer to play, compose and edit music etc. MODEL DIGITAL ELECTRONIC KEYBOARD 512 TONE BANK...
  • Page 14 External Jacks 7、 External connection jacks The piano has several connection jacks used to connect other relative device. A. Headphone jack The headphone is located at the down left side of piano keyboard. It is used play the piano without disturbing others. Jack Headphone B.

  • Page 15: Specification

    Specification 8. Specification Keyboard Standard 88 keys piano keyboard Polyphony Keyboard Control Touch sensitive, transpose Instruments 128, General MIDI Styles Style Control Start, sync, stop, intro, fill in, ending, variation Auto Bass Chord Multi-finger, single-finger Teaching System Teaching system help to learn playing step by step with high efficiency Percussion 88 notes percussion...
  • Page 16 Instruments INSTRUMENTS General MIDI 128 Instruments PIANO 36 SLAP BAS 1 BAGPIPE 72 PICCOLO 37 SLAP BAS 2 FIDDLE 73 FLUTE 00 PIANO GRD 38 SYN BASS 1 SHANAI 74 RECORDER 01 PIANO BRITE 39 SYN BASS 2 75 PAN FLUTE 02 PIANO ELEC PERCUSSIVE 76 BOTTLE BLOWN...
  • Page 17 Styles STYLES 100 popular styles ETHNIC 29 BEAT 1 57 DISCO QUEEN MARCH 30 BEAT 2 58 HIP-HOP 1 00 DANGDUT 84 POLKA 1 31 BLALLAD 59 HIP-HOP 2 01 KERONCONG 85 POLKA 2 32 RK BALLAD 02 NEW SAIDI 86 BAROQUE 33 BIG BALLAD ROCK...
  • Page 18 Percussions list PERCUSSIONS LIST MIDI making use Prog 1 Prog 2 Prog 3 Prog 8 Standard set 1 Standard set 2 Standard set 3 Chinese set Syn Sound < < < Slap < < < Scratch 1 < < < Scratch 2 <...
  • Page 19 Percussions list Prog 9 Prog 10 Prog 11 Prog 17 Prog 18 Room set 1 Power set 2 Room set 2 Room set 3 Power set 1 < < < < < < < < < < < < < <...
  • Page 20 Percussions list Prog 26 Prog 24 Prog 25 Prog 27 Synth set Electri set 1 Electri set 2 Dance set < < < < < < < < < < < < < < < < < < < < <...
  • Page 21 Percussions list Prog 33 Prog 41 Prog 49 Prog 57 Prog 128 Jazz set Brush set Orchestra set EFX set Effect set < Brush Low Tom 2 Timpani F Scratch 1 Low Tom 2 < < Timpani F# Closed Hi-Hat Scratch 2 <...
  • Page 22 WARNINGS Take good care of your piano, it will keep in excellent condition. a. Make sure the AC power is 220V or 110V 10%, which is labeled over the power hole on the back b. Before connect the piano with other device, power off them first c.
