Page 2: Thank You
NOTICES TO THE USER Government law prohibits the operation of unlicensed radio transmitters. Illegal operation is punishable by fine or imprisonment Of both. To avoid problem caused by electromagnetic interference and electromagnetic compatibility, please turn off the transceiver at the sites where you are required, such as hospital, airplane etc. In the vehicle equipped with air bag safety, don't put the transceiver within the scope of the air bag inflation. - Page 3 User Safety, Training, and General Information READ THIS IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION BEFORE USING YOUR QUANTUN PORTABLE TWO-WAY RADIO. Compliance with RF Energy Exposure Standards Your Quantun two-way radio is designed and tested to comply with a number of national and international standards and guidelines (listed below) regarding human exposure to radio frequency electromagnetic energy.
- Page 4 Operational Instructions and Training Guidelines To ensure optimal performance and compliance with the occupational/controlled environment RF energy exposure limits in the above standards and guidelines, users should transmit no more than 50% of the time and always adhere to the following procedures: Transmit and Receive To transmit (talk), push the Push-To-Talk (PTT) button;...
-
Page 5: Fcc Compliance
FCC Compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 6: Table Of Contents
CONTENTS Features Unpacking and Checking Equipment Supplied Accessories Channel Annunciation Key function programmable Battery Pack information Squelch Tail Elimination Charging Notices Time-Out Timer [TOT] Charging Instructions Monitor Priority Scan Care and cleaning Wired Clone PC Programming Accessories Installation Selectable Squelch Level(0-9) Installing and Removing the Battery Pack Busy Channel Lockout[BCL] Installing and Removing the Antenna... -
Page 7: Unpacking And Checking Equipment
Unpacking and Checking Equipment Battery Information Charging Notice Carefully unpack the transceiver. We recommend that you identify The battery is not charged at the factory, which can not reach its full the items listed in the following table before discarding the packing capacity for the first charging.After being charged and discharged material. -
Page 8: Charging Instructions
Care and Cleaning Charging Instruction Insert the battery or the radio with the battery into the charger, Do not carry your radio by the antenna or remot microrhone; and make sure than the battery connectors are in contact with Wipe the battery contacts with a lint-free cloth to re-move dirt, the charging terminals.The LED indicators glows red during grease,or other material that may prevent good electrical charging and green when the battery is fully charged. - Page 9 Accessory lnstallation Attaching the antenna 1. Align the threaded end of the antenna with the Radio’s antenna Attaching the Battey connector. 2. Turn the antenna clockswise to tighten.(See Figure 3) 1.Turn off the radio. 2.Insert the tabs at the bottom of the battery intothe slots at the Removing the antenna bottom of the radio chassis.
-
Page 10: Radio Overview
Radio Overview Removing the Belt Clip 1.Press the belt clip tab upwards until it releases. 2.Slide the belt clip upwards to remove it.(See Figure 5) Note: remove the battery pack prior to removing the belt clip. Figure 5 Attaching External Earphone(Optional) 1.Remove the cover of earphone jack. - Page 11 (1) Antenna (8) Speaker Used to transmit/receive signals. Used to output sounds. (2) LED Indicator (9) External Jack(for external earphone The radio LED glows red during transmission or radio programming) and green during reception; The LED flashes red when battery voltage is low. Rotate the jack cover and insert accessory plug (3) Channel Selector Knob or insert programming cable into the jack to...
-
Page 12: Basic Operation
Basic Operation Features Channel Annunciation 1. Turn on the radio: Turn the Power/Volume Control Knob clockwise until a "click" is heard. When you rotate the channel selector, the current channel number will be heard. 2. Adjust the volume:Turn the Power/Volume Control Knob to adjust the volume.When function key is programmed with monitor feature, Key function programmable turn the knobwhile holding down the function key to adjust thevolume... -
Page 13: Monitor
Monitor DTMF ANI This feature is enabled/disabled by your dealer.In receive mode, This feature is enabled /disabled by your dealer.DEMF ANI is encoded press the preprogrammed MONI key to monitor activities on the by PTT ID.Each radio is assigned with one ANI code consisting of current channel .This operation is especially useful for adjusting BOT ID (Beginning of Transmission) and EOT ID(End of Transmission). -
Page 14: Battery Save
Battery Save FREQUENCY LIST The Battery Save feature is automatically activated once no activity on the channel and no operation performed for 10 seconds, for Model No.: extended operation time. When a signal is received or an operation is performed, the Battery Save feature is automatically deactivated. Serial No.: Low battery Alert When the battery voltage goes below a preset value, the LED indicator... -
Page 15: Troubleshooting Guide
Troubleshooting Guide Warranty Card Mode Number: Trouble Solution Battery is low. Recharge or replace the battery. Serial Number: No power The battery may not be properly installed. Remove the battery and attach it again. Purchasing Date: Power doesn't Dealer: Telephone: last long even Battery has lost its capacity, replace it with a new one.
