SINOTEC
CRB-3368
PLL ALARM CLOCK RADIO
INSTRUCTION MANUAL
Thank you for purchasing a Sinotec product. Read this manual carefully to
get the best performance from this unit.
IMPORTANT
 Read these instructions carefully.
 Heed all warnings.
 Follow all instructions.
 Do not block any ventilation openings. Install in accordance with the

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CRB-3368 and is the answer not in the manual?

Questions and answers

Summary of Contents for Sinotec CRB-3368

  • Page 1 SINOTEC CRB-3368 PLL ALARM CLOCK RADIO INSTRUCTION MANUAL Thank you for purchasing a Sinotec product. Read this manual carefully to get the best performance from this unit. IMPORTANT  Read these instructions carefully.  Heed all warnings.  Follow all instructions.
  • Page 2 manufacturer’s instructions.  Do not install near any heat sources such as radiators, heat registers, stoves, or any other apparatus (including amplifiers) that produce heat.  Protect the power cord from being walked on or pinched, especially at the plugs, convenience receptacles, and the point where they exit from the clock radio.

  • Page 3: Location Of Control

    LOCATION OF CONTROL...

  • Page 4: Connect Power

    1. VOLUME +/ AL2 9. PM INDICATOR 2. VOLUME - / AL1 10. DIGITAL DISPLAY 3. SNOOZE/DIMMER/SLEEP/NAP 11. BLUETOOTH INDICATOR 4. MEMORY / TIME SET/ 12. AL2 INDICATOR 5. TUN-/ 13. FM ANTENNA WIRE 6. TUN+/ 14. DC INPUT /FUNCTION 15.
  • Page 5 BOTTOM OF SET Battery compartment for 1.5 volt (2X AA/ LR6/ UM-3) batteries 2pcs. (not included) for temporary time storage. SET TIME 1. Press and hold TIME SET for two seconds. 2. Press HOUR or MINUTE to select 12/24 hours and then press TIME SET again to confirm setting.

  • Page 6: Set Alarm Timer

    4. Turn on Bluetooth function at Bluetooth enable device / smart phone. 5. Scan CRB-3368 as device name. 6. Select CRB-3368 on device name list. 7. Bluetooth indicator flash slowly after pairing and connecting. 8. Playback music or multi-media audio source on the device/ smart phone.

  • Page 7: Adjust Volume

    1. Press / FUNCTION to Clock mode. 2. Press and hold AL1/AL2 for two seconds.  [0:00] Hour digit is blink. 3. Press “TUNNING -” and “TUNNING +” to change hours down or up. 4. Press “AL1/AL2”: minutes is blinking. 5.

  • Page 8: Battery Backup

    During standby mode, press and hold DIMMER for 2 seconds repeatedly to select high or low brightness levels. USB Charging Use the USB charging port to charge your smart phone or to power USB powered devices such as a USB type lamp or fan. To Connect your cell phone for charging : Use a USB cable (not included) to connect your cell phone to the USB connector of the unit.
  • Page 9 Power Source : AC230 V∽50Hz Tuner Range : FM 87.5-108.0MHz : ≤1W Power Consumption USB Charging power : DC 5V 1A ( standby mode ) Product information is subject to change without prior notice.
