Summary of Contents for TimeLink TS32M
- Page 1 TimeLink Technology Co., Ltd. (hereinafter referred to as “TimeLink”). The information specified in this document is possessed by TimeLink and protected by Intellectual Property in the People's Republic of China and international convention.
- Page 2 Exemption Clause According to scope permitted by the applicable laws, TimeLink provides the script of this document without undertaking any forms of warranty, including but not limited to any implied marketability, applicability with special purpose or non-invasiveness. TimeLink assumes no responsibilities for any direct or...
- Page 3 Contents 1. Introduction ....................1 2. Appearance ................... 4 MIC+AUDIO .................... 5...
- Page 4 1. Introduction 1.1 Brief Introduction Function description The main functions of this product includes: 1080P high-definition multi-touch display function, TV function Installation location This product is suitable for education , home, conference places. It can be installed in two modes: desktop and wall mount. Temperature range Storage temperature：...
-
Page 5: Specifications
1.2 Specifications 1.2.1 Monitor Specification Monitor Specification Model No. TS32M Display technology TFT-LED Display size 698.4 (H) x 392.85(V)MM Screen size 727.4(H ) x 429(V) MM Best resolution 1920*1080 RGB Brightness 350 cd/m2 Contrast rate 3000:1 Response time 6.5ms Display color 10 bit(FPC),1.07 Billion... - Page 6 energy-saving Smart USB interface Default without optional computer communications Sound coming out forward without blocking, Forward speaker better sound effect 1.2.2 Touch screen specification Touch screen specification Touch screen size 32 inch Touch technology Multi-touch surface light wave Touch pressure Zero-pressure Screen surface is riot optical glass, hardness of Surface hardness...
- Page 7 Power consumption <2.0W Life 60000 hours Finger, pen （Non-capacitors, electromagnetic Touch mode pen） Multi-touch 2, 4, 6, 10, 32, maximum 48points Response time 10ms Scanning frame rate 100 frames Minimum identification 3mm*3mm point size Minimum detection contacts motion Shape recognition support Touch 10% discontinuous damaged sensor can still...
- Page 8 1. Buttons and expansion interface description 2. TV Interface Description 3. External Computer Interface Description...
- Page 9 PS/2 USB*2 MIC+AUD On power Place the TV on the right place, plug one end of the power adapter into the wall AC power (input voltage :110-240VAC; Frequency: 47/63Hz) socket and the other end into the power socket on the TV, turn on the power switch, and you will see power indicator turns red when the TV is in standby mode, if you press the remote ON / OFF button or press the front-panel key switch, power indicator will turn green, wait a few seconds and pictures can be seen on the...
- Page 10 ● Disconnect the power Connect the external device before you to ensure that the input and output terminals are connected properly. § 15.19 Labelling requirements. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 11: Contact Information
Technical and service support Any technical and service support needed, please visit us Timelink website at www.timelink.cn Contact Information Address: 2nd Floor, B building, Digital Silicon Valley Industrial Zone, No.89, Hengping Road, Henggang Street, Longgang District, Shenzhen. E-mail: support@timelink.cn Tel: +86（755）82838577 Fax: +86（755）82838515...
