- Page 1 INSTALLATION AND OPERATION MANUAL Desktop Mixer Amplifier with MP3/FM/Bluetooth and recordable alarm Caution: Please read this manual carefully before operating Damage caused by misuse is not covered by the warranty...
-
Page 2: Safety Warnings
SAFETY WARNINGS! 1. Read and keep these instructions. Keep the manual in a good condition. 2. Heed all warnings and follow instructions. 3. Do not use this product near water 4. Do not block any ventilation openings. 5. Do not install near any heat sources. 6. - Page 3 INTRODUCTION: Thank you for purchasing our Magna Desktop or Rackmount Amplifier. This amplifier is the first 100V line amplifier with its own built in MP3 recorder and alarm trigger. The PA Mixer Amplifier is rated with power outputs from 30W, 60W to 120W, it is ideal for school, supermarkets, banks, background music for public areas and speech use.
-
Page 4: Front Panel
FRONT PANEL 1. MP3/FM/Bluetooth 6. Power Switch 12. Alarm MP3 Volume 2. Power LED 7. Mic 1 Volume 13. Bass 3. Protection LED 8. Mic 2 Volume 14. Treble 4. Clip LED 9. Mic 3 Volume 15. Master 5. DB Output level 10. -
Page 5: Speaker Terminals
AMPLIFIER OPERATION GUIDANCE 100V Line System Connect the rear IEC inlet to the mains using the supplied mains lead (or an equivalent approved type). Alternatively, the amplifier can be powered by a 24V battery, such as a lorry or boat battery, by connecting the “+”... -
Page 6: Wiring Diagrams
Wiring Diagrams Operation Steps When all connections to the amplifier are made, turn all the volume controls to the MIN position and then switch ON. The “ON” LED will illuminate. Turn BASS and TREBLE controls to the 12 o’clock position (pointing straight up) and turn MASTER rotary control up Quarter way for testing. Ensure a signal is being fed to one of the line inputs 1, 2, 3 or 4 and gradually increase the volume control for that channel until the output is heard through the speakers. -
Page 7: Alarm Trigger
FM Tuner Press the mode select button to switch to the FM tuner function. Use the Previous or Next buttons to select a stored channel Tuning and Storing stations Use the Forward/Reverse seek buttons to manually tune the frequency in steps of 0.05MHz. Alternatively, press and hold the Forward/Reverse seek buttons to auto search for available stations. -
Page 8: Connection Diagrams
CONNECTION DIAGRAMS REGULATIONS Electromagnetic Compatibility (EMC) This equipment generates radiated radio frequency energy, if not installed and used in accordance with the instructions, it may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is more of the following measures: Re-orient or relocate the receiving FM antenna. -
Page 9: Specification Sheet
If you have any problems please contact your supplier or visit www.magna- for more information. av.com SPECIFICATION SHEET Model Alert 30 Alert 60 inc Rackmount Alert 120 Alarm Volt free contact with 20 second record facility via USB Mini socket Rated Power Output...
