3. Do not place any heavy objects above the Switch. 4. Users can check more technical specifications from http://www.soarnex.com if necessary. LED Indicators PWR1 PWR1 PWR2 PWR2 PWR Fail PWR Fail IP120 / IP110 IS120 / IS110 Rev1.0 by 2016 Mar...
LED Per Solid Light Power feeding PoE Port Green Light off No Power feeding (IP120/IP110) Upper panel 1. Grounding screw 2. Power 1 input terminal block 3. Power 2 input terminal block 4. Power fault alarm(normal open, 1A@24VDC) DIP Switch 5.
12/24/48 Jumbo IP120 / IP110 IS120 / IS110 Hardware Installation DIN Rail Mounting 1. Insert the top of the DIN rail into the slot just below the stiff metal spring. Metal Spring DIN-Rail Rev1.0 by 2016 Mar...
Page 5
2. The DIN rail attachment unit will snap into place as shown below. Metal Spring DIN-Rail 3. To remove the DIN rail from the switch, simply reverse Steps 1 and 2. Metal Spring DIN-Rail Rev1.0 by 2016 Mar...
Page 6
Wall Mounting kit (optional) 1. Remove the DIN rail plate from the switch’s rear panel, and then attach the wall mount plates, as shown in the figure. Top Plate Bottom Plate 2. Once the screws are fixed in the wall, insert the four screw heads through the large parts of the keyhole-shaped apertures, and then slide the switch downwards, as indicated.
