Summary of Contents for RF Technologies Application Disruption Alarm
- Page 1 Application Disruption Alarm Installation and User Guide 0510-1084-C Released 08/21/13...
- Page 2 Copyright 2009, 2011, 2013 by RF Technologies, Inc. All Rights Reserved. No Part of this work may be reproduced or copied in any form or by any means without written permission from RF Technologies, Inc. Users must read this Guide before using the Product.
-
Page 3: Important Warnings
RF Technologies, Inc. for set up and use. Do not attempt to use extension cords or other equipment not supplied by RF Technologies, Inc. - Page 4 RF Technologies, Inc. representative. To arrange for a quarterly inspection by RF Technologies, Inc., call our Technical Support Department at (800)-669-9946 or (262) 790-1771. Failure to provide regular inspection of these products may result in equipment and/or system failure.
-
Page 5: Installation
Chapter 1 Installation and Operation Overview The Application Disruption Alarm monitors the operational status of a Server by requiring periodic communication in order to avoid annunciating a Trouble Condition. The Application Disruption Alarm provides the peace of mind you need by ensuring that your RF Technologies’ Server computer is operational. - Page 6 14. Store the Software CD in a safe place in case of future need. 15. If you desire, you may close the File Explorer application window. 16. Continue with the next section in order to correctly install the Application Disruption Alarm hardware. Page 2 of 6 Application Disruption Alarm...
-
Page 7: Install Hardware
Application Disruption Alarm will enter into a silent monitoring state. : The Application Disruption Alarm MUST be connected when the RF Technologies’ software initially starts up. If it is not, the software will not recognize it and the Application Disruption Alarm will alarm. -
Page 8: Operation
The Green LED on the face of the Application Disruption Alarm enclosure indicates proper operation of the Application Disruption Alarm. The Red LED on the face of the Application Disruption Alarm indicates a Trouble Condition when illuminated. The speaker in the face of the Application Disruption Alarm enclosure will sound its audible alarm when a Trouble Condition is present. -
Page 9: Troubleshooting And Specifications
CHAPTER 2 Troubleshooting and Specifications Troubleshooting If the Green LED on the face of the Application Disruption Alarm enclosure is not illuminated, the Application Disruption Alarm is not operating properly, most likely due to a lack of power. Ensure that the... -
Page 10: Specifications
4.5 x 3.1 x 1.8 inches Weight 5 ounces Power 5VDC @ 1A Enclosure Black ABS Operating 0-40 degrees Celsius, 32 to 104 degrees Temperature Fahrenheit Regulations FCC Part 15 Compliant, UL1069 Listed Page 6 of 6 Application Disruption Alarm 0510-1084-C...
