Summary of Contents for Glacier Start GLC-GS-CHR-T5
- Page 1 GLC-GS-CHR-T5 Installation Guide Dodge/Chrysler Regular Key...
- Page 2 GS-CHR-T5 1 and 2-way LED Remote Starter Page 1 VEHICLE FIT GUIDE VEHICLE CHRYSLER 2011-2012 300-300C 2005-2007 Aspen 2007-2009 Crossfire 2008 Cruiser 2008-2010 Sebring 2007 2008-2010 DODGE Avenger 2008-2012 Caliber 2007 2008-2012 Charger 2006-2007 Dakota 2007-2012 Durango 2007-2009 Magnum 2005-2008 Nitro 2007-2011 2006-2007...
- Page 3 GS-CHR-T5 1 and 2-way LED Remote Starter Page 2 WIRING DIAGRAM Ignition Barrel DO NOT CONNECT ON A JEEP WRANGLER Purple Wire Antenna Pink Hood Pin Ignition(+) Gray Hood Pin(-) Vehicle Brown/White Parking Lights(-) Valet Switch Cut Yellow Loop when installing on an automatic transmission Yellow...
- Page 4 GS-CHR-T5 1 and 2-way LED Remote Starter Page 3 WIRING DIAGRAM Ignition Barrel If the vehicle does not have a (+)Starter wire, use connection A. 2nd Ignition (+)Starter (+)12V + Polarity - Polarity 750 mA max 750 mA max Antenna Ensure Jumper on the front of the Glacier module is in the left(+) position.
- Page 5 GS-CHR-T5 1 and 2-way LED Remote Starter Page 4 Programming Programming the EVO-ALL The EVO-ALL must be programmed before the Glacier Start transmitters can be programmed. Step 1 Step 2 EVO-ALL EVO-ALL EVO-ALL EVO-ALL If the LED is not The LED will...
- Page 6 GS-CHR-T5 1 and 2-way LED Remote Starter Page 5 Programming Programming Remote Transmitter(s) The System can learn up to a maximum of 4 transmitters. A single transmitter can be stored in more than 1 memory slot. When a 5th transmitter is learned the 1st remote is erased. Place unit into Valet Mode before programming transmitters...
- Page 7 GS-CHR-T5 1 and 2-way LED Remote Starter Page 6 Programming Programming Options Options in BOLD RED are default settings. O F F I G N Press and hold valet Press and release the Press and release Press Lock(1), Unlock(2), switch until antenna valet switch 1-37 times Trunk(3), or Start(4) on a the brake pedal...
- Page 8 GS-CHR-T5 1 and 2-way LED Remote Starter Page 7 Programming Programming Options Continued Options in BOLD RED are default settings. Mode 1 Mode 2 Mode 3 Mode 4 Mode 5 Mode 6 Functions Button 1 Button 2 Button 3 Button 4 Button 1 &...
