Summary of Contents for Edgetech pulse 070
- Page 1 Installation and Operating Instructions pulse POOL PUMP Attention Installer This manual contains important information about the installation, operation and safe use of this product. Once the product has been installed this manual must be given to the owner/operator of this equipment.
-
Page 2: Table Of Contents
Table of Contents ……………………………… ENERAL NFORMATION ………………………………………..NSTALLATION …………………………..LECTRICAL ONNECTION – P ………………………………. PERATION RIMING – M …………..AIR AND AINTENANCE – M …………………………. ENERAL AINTENANCE …………………………. ROUBLE HOOTING UIDE ………………………….. ARRANTY NFORMATION ………………………………….. ULSE PECIFICATIONS ……………………………………………. PARE ARTS …………………………………………………….. -
Page 3: General Information
General The Pulse series pool pump has been specifically designed to operate todays swimming pools, its high performance and high head flow characteristics will ensure that the Pulse pool pump will operate with all your ancillary equipment including chlorinators, heaters, in floor cleaners and pool cleaners. -
Page 4: Electrical Connection
Electrical Connection 1. IMPORTANT! - The electrical installation must be performed by a licensed electrician and must conform to all national, state and local codes. Australian Wiring Rules AS3000 2. The PULSE pump must be supplied through a residual current device (RCD) with a rated residual operating current of 30mA. -
Page 5: Hair And Lint Pot - Maintenance
WARNING RISK OF SUCTION ENTRAPMENT HAZARD, WHICH, IF NOT AVIODED, CAN RESULT IN SERIOUS INJURY AND/OR DEATH. Do not block the pump suction, as this can cause severe injury and/or death. Do not use this pump for wading pools, shallow pools, or spas containing bottom drains, unless the pump is connected to at least two (2) functioning suction outlets. -
Page 6: General Maintenance
General Maintenance 1. On a monthly basis check the area around the pump motor to ensure that it is clear of debris, i.e. leaves, sand and dirt etc. Failure to keep this area clean may cause the pump fan cowl to become blocked and cause the pump to overheat. 2. -
Page 7: Trouble Shooting Guide
Trouble Shooting Guide Symptoms Possible Cause Remedy No water in the pump. Ensure that the hair and lint pot is full/Ensure water level is correct in the pool Air leak. Ensure that the water level is correct at the suction points. Tighten all barrel unions and fittings on the suction side of Pump will not prime. -
Page 8: Warranty Information
Pulse Series Pool Pump Warranty Edgetec Systems Pty Ltd warrants that this item sold hereunder shall be free from defects in material and workmanship for a period of two (2) years from the original purchase date and to the original purchaser and are not transferable to new owners. -
Page 9: Pulse Specifications
Current Width Height Length Model Voltage (watts) (amps) (mm) (mm) (mm) Pulse 070 230-240 Pulse 090 1.25 230-240 Pulse 110 230-240 1100 Electrical Approval SGS 538 Noise Rating 65 dB (1m) Head (kPa) pulse 070 090 110 Flow (LPM) Page 9... -
Page 10: Spare Parts
Pulse Pool Pump Spare Parts Listing Parts Listing Item # Description Part # Item # Description Part # Fan Cowl 10-0029 Impeller 1.5Hp 10-0001 9-2020 Diffuser 10-0009 Capacitor Cover 9-2024 Screws Diffuser (5) 10-0024 Capacitor Cover Gasket 9-2025 Diffuser Throat 10-0008 PCB Fuse Terminal 9-5128... -
Page 11: Notes
Notes Page 11 Pulse Pool Pump Installation & Operating Instructions – Part # 10-0030 Nov 2012... - Page 12 pulse 13 Lieber Grove Carrum Downs Victoria 3201 Australia Tel: (613) 9775 0882 Fax: (613) 9775 0881 Email: sales@pulsepumps.net Web: www.pulsepumps.net New Zealand Industrial Plastic Shapes Pty Ltd 95 Diana Dr Glenfield North Shore City 0745 Tel: +64 9 442 4051 Fax: +64 9 442 4053 Email: info@ipsnz.com Web:...
