Summary of Contents for uControl Key Fob
- Page 1 User Guide Key Fob Draft April, 2010...
- Page 2 © 2006, 2007, 2008, 2009, 2010 uControl, Inc. The uControl logo, uControl, Inc., and all other uControl products and technology names are trademarks or registered trademarks of uControl, Inc. All other products or services mentioned herein are trademarks of their respective companies.
- Page 3 Table of Contents ..................1 NDERSTANDING AND SING THE ........................ 5 DDING OBS TO YSTEM ......................8 ETTING A OB TO EFAULT DRAFT Page iii | August 10, 2010...
- Page 4 Understanding and Using the Key Fob A key fob is a mobile tool that lets you arm and disarm your system with the touch of a button. To use the key fob, press the button approximately 1.5 seconds until the LED flashes. See Table 1 for more information.
- Page 5 Table 1: Troubleshooting the Camera Installation Action Button LED Display Description Icon Arm System in Arm Stay Mode Flashes red once and then Used when everyone is leaving the lights red for three house. seconds Alarm trips immediately if a monitored Perimeter zone (non-entry/exit door or window) is opened.
- Page 6 Table 1: Troubleshooting the Camera Installation Action Button LED Display Description Icon Arm System in Arm Away Mode Flashes red once and then Used to arm the system when there lights red for three are still people in the premises. seconds Alarm trips immediately if a monitored Perimeter zone (non-entry/exit door or window) is opened.
- Page 7 Table 1: Troubleshooting the Camera Installation Action Button LED Display Description Icon System Status Flashes red once to Tells whether the system is armed or indicate that it has disarmed contacted the system then: Lights green for three seconds if the system is disarmed Lights red for three seconds if the system...
- Page 8 Adding Key Fobs to System When a uControl key fob is removed from the box, it is already defaulted and ready to add to the SMA system. To add (pair) a key fob to an SMA Gateway: After Activation: Log into the Settings widget using the Installer key pad code.
- Page 9 Img_1424.mov Figure 1: Double-click to View Example of How to Install the Battery The LED blinks several times every five seconds. This means that the key fob is in Search mode and can be paired with the SMA Gateway device.
- Page 10 Touch the icon of a key fob that needs configuring. A keyboard screen is displayed to type a name for zone of the selected key fob. Touch Done to enter the new name. The Configure Wireless Key Fobs screen is displayed again.
- Page 11 Replace battery while holding down the center button (‘*’), and one other button (recommended: Disarm button). The LED on the side of the PCB opposite of the battery flashes GREEN every five seconds. The key fob is in Search mode and ready to be paired (added) to an SMA Gateway.
- Page 12 Img_1424.mov Figure 3: Double-click to View an Example How to Default a Key Fob DRAFT Page 9 | August 10, 2010...
- Page 13 From the Installer Settings Menu, touch Key Fobs & Sirens → Delete Key Fob. The Delete a Key Fob screen is displayed with images representing the key fobs currently installed to the SMA system. Touch the image for the installed camera.
