1. Features

  2.4GHz Frequency Hopping Spread Spectrum (FHSS) radio transceiver module
  Operates in the unlicensed worldwide ISM band (2.4 GHz to 2.483.5GHz) band
  Fully integrated power regulation with a wide input unregulated operating range 3V to
10V.
  Fully integrated local oscillator and 12MHz 20ppm reference crystal
  200mA operating current
  Transmit power - 100mW EIRP
  Receive sensitivity up to -95dBm
  DSSS data rates up to 250kbps
  1 mile operating range
  Full packet assembling and disassembling
  Auto transaction sequencer
  Fully buffered digital interface with high voltage tolerant inputs

2. Pin description

Pin Number
Name
1
GND
2
VCE
3
VIN
4
P21
5
P33
6
P17
7
P32
8
GND
9
P30
10
XRES
11
P11
12
P10
X1TXP1UC 2.4GHz Module User Manual.
Description
Module Ground
Power control monitoring
Module DC Power
Baseband CPU digital port P2.1
Baseband CPU digital port P3.3
Baseband CPU digital port P1.7
Baseband CPU digital port P3.2
Module Ground
Baseband CPU digital port P3.0
Baseband CPU reset input
Baseband CPU digital port P1.1
Baseband CPU digital port P1.0
Page 1 of 4
Horizon Hobby, LLC
4105 Fieldstone Rd
Champaign, IL 61822
