Summary of Contents for Universal Remote Control MRZ-260
- Page 1 Order Number : GETEC-C1-09-088 FCC Part 15 subpart C Page 1 / 1 Test Report Number : GETEC-E3-09-039 APPENDIX H : USER’S MANUAL EUT Type: RF Base Station FCC ID.: OZ5URCMRZ260...
- Page 2 MRZ-260 Installation Manual...
- Page 3 Glidden of King of Prussia and Doylestown, PA. The information in this manual may be subject to change without prior notice. Complete Control is a registered trademark of Universal Remote Control, Inc. All other brand or product names are trademarks or registered trademarks of their respec- tive companies or organizations.
-
Page 4: Table Of Contents
ABLE ONTENTS Introduction Features and Benefits Parts Guide Installation Testing Front Blaster Overload Disabling the Front Blaster - Step by Step via PC Controlling Four Identical Components/Zones Identical Components/Zones - Step by Step via PC Programming For Multiple Equipment Locations USA Limited Warranty Statement Frequently Asked Questions Specifications... -
Page 5: Introduction
MRZ-260 B TATION Introduction The MRZ-260 base station has incorporated a new wireless technolo- gy referred to as Zigbee. This technology improves the range and reli- ability throughout a house and gives you the ability to control as many identical components as needed. In order to control a Zigbee base station an Zigbee remote is needed such as the MX-880Z. -
Page 6: Features And Benefits
Two Fixed IR Outputs with RFTX URC Lighting Control The MRZ-260 is equipped with two fixed IR line outputs with standard 3.5 mm jacks for standard and sleeved IR emitter/flashers. One Fixed IR Output has a dual role for URC Ligting Control via the RFTX transmitter Two Variable IR Outputs Match Rear Panel IR Inputs The MRZ-260 is equipped with two adjustable IR line outputs. -
Page 7: Installation
8. Click on the Browse button to automati- cally discover the MAC address of the MRZ-260 base or type in the 8 characters found on the MAC ID sticker located in the rear of the base. Note: If you receive a Not Connected message simply unplug then replug the USB cable and try again. - Page 8 NOTE: TiVo, Replay TV, other DVRs, Satellite Receivers and Cable Boxes are all extremely sensitive to IR overload or saturation. For this reason, it is recommended that you always connect the IR flashers for these types of component to the Variable IR Outputs of the MRZ-260. Page 4...
-
Page 9: Testing
Reprogram the remote control to send IR commands only via a specific (1- 4) Line Output, then readjust the IR Line Output level. Note: Remember, the MRZ-260 will NOT respond if you select IR line out- puts 5 or 6. The MRZ-260 has only four IR Line Outputs. - Page 10 MRZ-260 B TATION Integrating RFTX-1 to control URC Lighting Not only will you have greater control of your home theatre equipment with Zigbee, now you also have control of your URC Lighting. What better way to watch a movie and control your universe! Step 1: Simply use a sleeved emitter and plug into the rear of the RFTX-1 pink fixed port.
-
Page 11: Front Blaster Overload
Disable the Front Blaster. This will limit the num- ber of components your MRZ-260 can control to four. If you have more than four components you can purchase an additional MRZ-260 or upgrade to an MRF-350. -
Page 12: Controlling Four Identical Components/Zones
Controlling Four Identical Components/Zones There are several considerations to take into account when you are installing an MRZ-260 to control an array of identical components: 1. Each identical component must receive IR commands ONLY from a ded- icated Flasher affixed to its front panel or a rear panel direct IR input. - Page 13 MRZ-260 B TATION By looking at the Signal column, you can see that the factory default pro- gramming sets all of the devices to send both IR and RF commands. If you look at the column for Flashers, you can see that the default sends IR com- mands for all devices to ALL of the flashers.
-
Page 14: Programming For Multiple Equipment Locations
TATION In the figure below, each device is set to a specific flasher. Note: Remember, the MRZ-260 will only respond to selections 1 through 4. Step 5 - Close the RF window and Download to the Remote. Programming For Multiple Equipment Locations You can operate an unlimited amount of different equipment locations, each with an MRZ-260 assigned with a unique MAC Address. -
Page 15: Usa Limited Warranty Statement
MRZ-260 B TATION USA Limited Warranty Statement Your Universal Remote Control, when delivered to you in new condition, is warranted against defects in materials or work- manship as follows: UNIVERSAL REMOTE CONTROL, INC. warrants this product against defects in material or workman- ship for a period of one (1) year and as set forth below. -
Page 16: Frequently Asked Questions
Frequently Asked Questions Can I use flasher/emitters that I have already installed in the sys- tem to connect to the MRZ-260? Yes, the flashers are compatible if they use 3.5mm mono mini plugs with the same polarity (Tip is data, sleeve is ground). -
Page 17: Federal Communication Commission Interference Statement
MRZ-260 B TATION Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 18 500 Mamaroneck Avenue, Harrison, NY 10528 Phone: (914) 835-4484 Fax: (914) 835-4532 www.universalremote.com OCE-0056E Rev.01...
