PEBBLE WIRELESS
Before operating the unit, please read this manual
thoroughly and retain it for future reference
HD PROJECTOR
user manual
Model name:P2
FCC ID:PUZMP-328
Advertisement
Table of Contents
Summary of Contents for Foryou P2
-
Page 1: User Manual
PEBBLE WIRELESS HD PROJECTOR user manual Model name:P2 FCC ID:PUZMP-328 Before operating the unit, please read this manual Note thoroughly and retain it for future reference Note: Even in the absence of comment, company trademarks and products trademarks of their respective companies get stern treatment. - Page 2 Caution about safety in use Note Thank you for purchasing this series of digital projectors. Please read through the “manual" in order to properly use the product. After reading the manual, please keep it in a safe place for future reference. WARNING To reduce the risk of fire or electric shock, do not open the cabinet.
- Page 3 Introduction Pebble wireless HD projector integrated DLNA, miracast, airplay, MHL, HDMI, strive to build a smart phone, tablet entertainment and business partner. DLNA enables Android Smartphone or tablet itself or through third-party software applications to push music, video, pictures located in the device displayed by Pebble wireless HD projector.Equipment can push music, video, pictures easily through airplay to the projector and share it.
- Page 4 Checking Overview Lens Mini HDMI connector Power Vol down Vol up Front end unit WiFi dongle Focus wheel DLNA/Miracast switch MicroUSB Port (DC in) Intemal speaker Cooling fan MHL dongle MicroHDMI MicroUSB Port (DC in) (MHL in or HDIM in) - 3 -...
- Page 5 Quick setting up and debugging Setting up and debugging Setting up your projector Tripod connecting Tripod included in standard accessories. Note Focus adjusting Adjust focus by sliding the focus wheel on the right side of the body. Move the projector forward or backward if it is still not clear.
-
Page 6: Adjusting Projected Images
Quick setting up and debugging Setting up and debugging Adjusting projected images Checking horizontal or vertical setting of screen 1. Move the projector to the same side when the projected image is displaced leftward or rightward. (Align the center of the image with the center of LENS.) 2. -
Page 7: Connecting To Devices
Connecting projector Connecting to devices MHL dongle connecting Connect to Smartphone or Samsung Smartphone via MHL cable Smartphone Samsung Smartphone MHL dongle MHL-5Pin MHL-11Pin adaptor MHL-5Pin MHL cable MHL cable Note HDMI cable is NOT included in accessories. The projector support device with MHL/HDMI out function only. - Page 8 Connecting projector Connecting to devices WiFi dongle connecting Connect to Smartphone via WiFi WiFi dongle DLNA/Miracast switch key Smartphone Note Connecting to the projector, Smartphone must support DLNA or Miracast. - 7 -...
-
Page 9: Router Setting
Setting Router Setting phone or tablet , type in Default Passwords “12345678”. - 8 -... - Page 10 Setting Router Setting 2. After Success connected, Open the browser and type in “http://192.168.49.1”. 3. Click the icon. 4. Click “Scan” to scan the Wireless Router, choose the AP Enter Password. - 9 -...
- Page 11 Setting DLNA Usage 1. DLNA Local Sharing Google Play store) which used for DLNA sharing: (1) Select the SCREENCAST-xxxxx in the “DEVICES”. (2) Select the video, picture, music in the “PLAYLIST” or “LIBRARY”, the media will play on the TV. 2.
- Page 12 Setting AirPlay Usage 1. Connect IOS to “SCREENCAST-xxxxx”. Browsing the local video/music/picture, click the icon of airplay then choose the devices “SCREENCAST-xxxxx” for sharing on TV. - 11 -...
- Page 13 Setting Mode Switch DLNA and Miracast 1. Manually switch Poke the port In the Front of screencast. Open browser and type in “ http://192.168.49.1” Click the icon of Mode Switch in the Web. DLNA/Miracast switch key - 12 -...
- Page 14 Setting Miracast Usage SCREENCAST-xxxxx After connect successfully, the screen of the device can share on TV screen real-timely. SCREENCAST-xxxxx - 13 -...
- Page 15 Setting Miracast Usage NOTE: Various devices has different name and way to set Miracast, below for reference: LG Optimus G: Setting->More Setting-> Miracast. Sony: Setting->Xperia->Screen sync display. HTC: Setting->Media Output. Sharp: Settings -> Wireless Output. Nexus4: Settings-> Display -> Wireless display. XiaoMi2: Settings->...
- Page 16 Miracast Trouble shooting (1) Please check the LED? If not blue, make sure the Micro USB cable be fully connected to the power source. (2) Make sure the HDMI cable is securely connected firmly. (3) Make sure the correct HDMI port input is selected by the mode.
-
Page 17: Packing List
Checking accessories Packing list Projector MHL dongle Power adaptor MHL cable AC cable Tripod Stand MHL adaptor - 16 -... - Page 18 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
- Page 19 : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
