Summary of Contents for Indoor Sky Dayliter
- Page 1 NSTALLATION NSTRUCTIONS eries ayliter hade ** P lease read entire installation instructions before installing the Product uggeSted oolS rill evel encil crewdriver easure Williamsport, Pa 17701 www.indoor-sky.com 570.651.5105...
- Page 2 – Dayliter Shade is mounted to the face of the window frame or front of the window mullion ront ount – Dayliter Shade is mounted to the inside of the window frame, or mullion, using the side mount holes ount NOTE...
- Page 3 2. M ounting racket ocation – Mark the location of the holes to be drilled for the mounting brackets sing the eMPlate rovided – Using supplied hardware – Use level to ensure brackets are vertical before tightening ttach rackets Mportant –...
- Page 4 3. i nStall pper ightShelf and snap pin end into the hole on one side and then guide the other pin end into the opposite hole nstall wall brackets Provided Start with uppermost lightshelf and work down and will not hit the window frame or mullion nsure ightshelves oPen and close freely ight...
- Page 5 5. i nStall ightShelf onnectorS by inserting cable into End Stop, and locking the End Stop in position, then insert pin ttach onnector to both ends of uPPer lightshelf into Lightshelf and lock into postion with E-Clip nsure ightshelves oPen and close freely check that the Lightshelves are in a sing a level position parallel to the floor, and to each other...
- Page 6 6. i nStall oller hade – The pin end snaps into the hole on right side then the clutch slots are inserted on the left ith shade rolled all the way uP or vice versa, depending on clutch installation – The clutch should be installed on the side best suited to the room layout ( or user preference –...
- Page 7 8. f olding rank nStallation in the input shaft – connect using safety clip lide niversal nd of olding rank to jamb with screws provided so that crank will hang straight and snap into clip ttach olding rank etention 9. f aScia nStallation on brackets by inserting top edge and rotating bottom until it snaps in place...
- Page 8 ingle hade pplication ultiple hade pplication Williamsport, Pa 17701 www.indoor-sky.com 570.651.5105...
