Summary of Contents for Funke ATR833-II
-
Page 1: Control Unit
ATR - Remote Control Unit OLED/LCD P/N 600R01-(3xx)-(xxx) Operation and Installation (Dokument-Nr. 01.1313.010.71e) f.u.n.k.e. means – fabrication · utilities · network · know-how · engineering k.e. - Page 3 ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation Change History Revision Date Description of Change 1.00 15.11.2017 First release List of the Service Bulletins (SB) Services bulletins are to be inserted in the manual and to be put down in this table. Rev.
-
Page 4: Table Of Contents
ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation Contents GENERAL ..................4 Symbols .................. 4 Abbreviations ................4 Customer Support ..............5 Features .................. 5 OPERATION ..................6 INSTALLATION ................7 Advices and Tips ..............7 Scope of delivery ..............7 Unpacking and Inspecting the Equipment ....... -
Page 5: General
This manual contains information about the physical, mechanical and electrical characteristics as well as information about installation and operation of the ATR-Remote-Control Unit for the VHF Com transceivers ATR833-II/ATR833A-II. The ATR-Remote-Control Unit is available with LCD or OLED display. 1.1 Symbols... -
Page 6: Customer Support
Informations on software updates are available at f.u.n.k.e. AVIONICS GmbH. 1.4 Features Remote Control for controlling VHF COM transceivers o ATR833-II o ATR833A-II Ideal for tandem seated aircraft: o Automatic deactivation of remote control on deactivation of radio o Use of radio still possible without activation of remote control ... -
Page 7: Operation
Control Unit is identical to operation on the radio itself. The description of the controls, as well as the settings and configuration menu can be found in the manual for the ATR833-II radio (Doc. No. 01.143.010.71e) in Chapters 2 and 3. -
Page 8: Installation
The assigned installation company could perform wiring. For diagrams refer to section 3.5 Wiring. 3.2 Scope of delivery Part Number Description ATR-Remote-Control Remote Control Unit for ATR833-II and (ATR833RT-II) ATR833A-II in two-knob versions 2x solid an 2x hollow mounting screws – for ZUB4 panels up to 3mm... -
Page 9: Mounting
ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation 3.4 Mounting In cooperation with a maintenance shop, location and kind of the installation are specified. The maintenance shop can supply all cables. Suitable sets of cables are available from f.u.n.k.e. AVIONICS GmbH. ... -
Page 10: Connections Using
ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation 3.5.2 Connections Using Power Supply (Power, GND): AWG18 (0,96 mm²) Signals: AWG22 (0,38 mm²) The conductors must be approved for aircraft use. RX and TX should be shielded individually, or at least be pair-twisted and shielded together. -
Page 11: Wiring Diagram
Operation and Installation 3.5.4 Wiring Diagram The connection between the remote control and the 9-pin D-SUB connector of the ATR833-II cable can be realized by a standard 9-wire D-SUB cable. The connection between the 9-pin D-SUB remote connector and the radio (ATR833-II, ATR833A-II) is shown in the following figure. -
Page 12: Drawings
ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation 3.8 Drawings 3.8.1 Dimensions 37mm Remote Control 3.8.2 Mounting Advices For mounting in panels with a thickness of 3–5 mm longer screws are available (Order No. ZUB5: includes 2x solid und 2x hollow mounting screws): Dimensions in Dimensions of... -
Page 13: Appendix
ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation 4 APPENDIX 4.1 Frequency/Channel-Plan In the following table examples for operating and displayed frequencies in the range between 118.000 ... 118.100 MHz are given. This table can be continued to 136.975 MHz following the same scheme. Operating Channel Displayed... -
Page 14: Technical Data
ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation 4.2 Technical Data GENERAL COMPLIANCE JTSO-2C37e,ED-23B Class 4, 6 JTSO-2C38e,ED-23B Class C, E TSO-C37d, RTCA DO-186A Class 4, 6 TSO-C38d, RTCA DO-186A Class C, E LBA.O.10.911/115 JTSO Height: 65 mm (2,56 in) DIMENSIONS Width: 65 mm (2,56 in) Depth: 86 mm (3,27 in) behind the panel WEIGHT... -
Page 15: Environmental Conditions
ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation 4.3 Environmental Conditions Characteristic DO–160D Section Cat Condition Temperature / Altitude Low ground survival – 55°C 4.5.1 temperature – 20°C Low operating temperature 4.5.1 High ground survival 4.5.2 + 85°C Temperature High Short-time Operating 4.5.2 + 70°C Temperature... - Page 16 ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation Characteristic DO–160D Section Cat Condition Audio Frequency Conducted 18.0 Susceptibility Induced Signal Susceptibility 19.0 Radio Frequency 20.0 Susceptibility Emission of RF Energy 21.0 Lightning Induced Transient 22.0 Susceptibility Lightning Direct Effects 23.0 No test required Icing 24.0 No test required...
- Page 17 ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation Notes: Doc.-Nr. 01.1313.010.71e / Revision 1.00...
- Page 18 ATR-Remote-Control / P/N 600R01-(3xx)-(xxx) Operation and Installation Doc.-Nr. 01.1313.010.71e / Revision 1.00...
- Page 20 f.u.n.k.e. AVIONICS GmbH Heinz-Strachowitz-Str. 4 DE-86807 Buchloe Germany phone.: +49-8241 80066 0 fax.: +49-8241 80066 99 E-mail: service@funkeavionics.de www.funkeavionics.de f.u.n.k.e. means – fabrication · utilities · network · know-how · engineering k.e.
