Summary of Contents for SAFE-O-TRONIC LS 200
- Page 1 Annex no. 5 Functional Description / User Manual State: 2010-03-01 Vers. no.: 1.10 m. dudde hochfrequenz-technik Rottland 5a D-51429 Bergisch Gladbach/ Germany Tel. +49 2207-96890 Fax +49 2207 968920...
- Page 2 ® SAFE-O-TRONIC access Electronic Identification and Locking System DS 200, DS 300, DS 400 MANUAL Schulte-Schlagbaum AG...
- Page 3 SAFE-O-TRONIC access Manual Note Copyright 2011 by Schulte-Schlagbaum AG Nevigeser Straße 100-110 Postfach 101240 D-42512 Velbert Tel.: +49 2051 2086 / 0 FAX: +49 2051 2086 / 918 www.sag-schlagbaum.com Edition: 04/2011 V1.0 - Document number: SOT_DS_5020x_Manual.Doc This edition replaces all earlier editions.
- Page 4 SAFE-O-TRONIC access Manual 1. Description Electronic PIN-Code / RFID door locking system, with MIFARE-technology and other RFID- technologies according ISO 14443 A, with wide possibilities to individualize e. g. room, labelling or logo by exchangeable cover plates. Adaptable for right and left handed doors. The lock will be re- leased after entering a 4-6 digit code or using the RFID data medium.
- Page 5 SAFE-O-TRONIC access Manual 2. Technical data IP 43 Protection class according to DIN EN 60529 approx. 750 g Weight Temperature range 0 °C 60 °C in use -15 °C 60 °C in storage Relative air humidity 10 % (to) 90 % (without condensation)
- Page 6 SAFE-O-TRONIC access Manual 5. Dimensions Housing dimensions Fixing dimensions SAFE-O-TRONIC DS Page 5 of 5 SOT_DS_5020x_Manual.doc...
- Page 7 ® SAFE-O-TRONIC access Electronic Identification and Locking System LS100, LS 200, LS 300, LS 400 MANUAL Schulte-Schlagbaum AG...
- Page 8 SAFE-O-TRONIC access Manual Note Copyright 2011 by Schulte-Schlagbaum AG Nevigeser Straße 100-110 Postfach 101240 D-42512 Velbert Tel.: +49 2051 2086 / 0 FAX: +49 2051 2086 / 918 www.sag-schlagbaum.com Edition: 04/2011 V1.0 - Document number: SOT_LS_30084x_Manual.Doc This edition replaces all earlier editions.
- Page 9 SAFE-O-TRONIC access Manual 1. Description Electronic PIN-Code / RFID locking system for lockers, safe-deposit boxes and functional furniture, with MIFARE-technology and other RFID-technologies according ISO 14443 A, round rotary knob to operate the locking cam and wide possibilities to individualize e. g. locker numbers, writing or logo by exchangeable plates.
- Page 10 SAFE-O-TRONIC access Manual 2. Technical data IP 43 Protection class according to DIN EN 60529 approx. 300 g Weight Temperature range 0 °C 60 °C in use -15 °C 60 °C in storage 10 % (to) 90 % (without condensation)
- Page 11 SAFE-O-TRONIC access Manual 5. Dimensions Preparation of the door SAFE-O-TRONIC LS Page 5 of 6 SOT_LS_30084x_Manual.doc...
- Page 12 SAFE-O-TRONIC access Manual 6. System Delivery Contents 1 Lock 2 Nut for mounting the lock on the door 3 Grommet for setting the rotational direction of the rotary knob in order to lock 4 Locking lever (a cropped or hook-shaped locking lever can also be used depending on the...
