Mobitechplus MW-200 User Manual

Usb pc camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FCC Compliance and Advisory Statement
.
LABELLING REQUIREMENTS (Part15,Section15.19(a)(3))
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions : (1)this device may not cause harmful interference, and(2)this device must accept
.
any interference received, including interference that may cause undesired operations
INFORMATION TO THE USER (Part 15. Section15.105(b))
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one more
of the following measures:
1) Reorient or relocate the receiving antenna.
2) Increase the separation between the equipment and the receiver.
3) Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
4) Consult the dealer or an experienced radio/TV technician for help.
WARNING(Part 15, Section 15.21)
Any changes or modifications not expressly approved by the Jun telecom Inc. could void the
user`s authority to operate the equipment.
Where shielded interface cables have been provided with the product or specified additional
components or accessories elsewhere defined to be used with the installation of the product,
.
they must be used in order to ensure compliance with FCC regulations
Canadian DOC Statement
.
Suggested text for the notice indicating compliance with this Standard:
This Class B digital apparatus complies with Canadian ICES-003.
.
Cet appareil numerique de la classe B est conforme a la norme NMB-003 du Canada
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MW-200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mobitechplus MW-200

  • Page 1 FCC Compliance and Advisory Statement LABELLING REQUIREMENTS (Part15,Section15.19(a)(3)) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1)this device may not cause harmful interference, and(2)this device must accept any interference received, including interference that may cause undesired operations INFORMATION TO THE USER (Part 15.

  • Page 2: Declaration Of Conformity

    DECLARATION OF CONFORMITY Manufacturer`s Name MOBITECHPLUS INC. Manufacturer`s Address 32-5 Songwol-Dong Jongno-Gu, Seoul 110-101, Korea Declares, that the product Product Name USB PC CAMERA Model Name(Number) MW-200 Confirms to the following harmonized European standards have been applied: EMC : EN55022 : 1998 + A1: 2000 (Class B)

  • Page 3: Table Of Contents

    INDEX 1. Product introduction 1.1 Description 1.2 Required system conditions 1.3 Components 2. Precautions 2.1 Warnings at installation 2.2 safety instruction 3. CD Installation introduction 3.1 CD S/W Installation 3.2 Driver recognition on Windows 2000/XP 3.3 Driver recognition on Windows 98/98SE/ME 3.4 Remove software and driver 4.

  • Page 4: Product Introduction

    1. Product introduction 1.1 Description Item Description Remark Sensor VGA(640ⅹ480) 1/4 inche CMOS Sensor Pixels 320,000 Minimum 1.9Lux illumination F=2.8㎜, f=4.5㎜, 4 element Lens View angle 53° Focal range 2㎝ ~ ∞ VGA(640ⅹ480),CIF(352ⅹ288), Window size SIF(320ⅹ240),QCIF(176ⅹ144), QSIF(160ⅹ120) Format RGB24, I420 30FPS(QSIF), 30FPS(QCIF), 30FPS(SIF), Frame per second 30FPS(CIF), 15FPS(VGA)

  • Page 5: Components

    1.3 Components WebCAMeye Light Main Body 1 ea Installation CD 1 ea Magnetic panel for adhesion 1 ea...

  • Page 6: Precautions

    2. Precautions 2.1 Warning on installation • Must install driver before connect the PC camera to the computer. • Must install the PC camera on the plain surface firmly with magnetic panel order camera not to be come off. • Must dust humidity...

  • Page 7: Cd S/W Installation

    3. CD Installation instructions 3.1 CD S/W installation You should install the software of CD before you connect WebCAMeye Light to your computer. 1. The bottom menu will appear automatically when you insert the CD. ( In case that it does not appear automatically, you should operate Setup.exe on CD.) 2.
  • Page 8 3. Please click the “Next” button. 4. Please accept the use contract and click the “Next” button. 5. Please set up installation folder and click the “Next” button.
  • Page 9 6. Please click the “Install” button. 7. Please click the “Finish” button when the installation is completed and appear the bottom page. 8. Then the first page will be appeared as bottom.
  • Page 10 9. Please click the “Driver Install” button. 10. Please click the “Next” button. 11. Please click the “Continue Anyway” button when the buttom page appear while installation. (it will not always appear depending on the OS.) • Above “Windows logo test” warning normally appear when they didn’t request certifying to Microsoft but it has no relation to using our product.
  • Page 11 12. The bottom page will appear when the installation is fully completed. Please click the “Finish” to reboot. 13. You will find that the program is installed on Start Menu and on Desktop after rebooting. (WebCAMeye and 301P USB Camera will be added on Start Menu) •...

  • Page 12: Driver Recognition On Windows 2000/Xp

    3.2 Driver recognition on Windows 2000/XP 1. Connect the WebCAMeye Light to spare USB port of PC. The bottom page will appear on the recognition procedure. 2. Please install and click “Next” button. 3. In case that the bottom page can appear while installing, please click “Continue Anyway”...
  • Page 13 4. It will install continuously. 5. The bottom page will appear after the installation is completed. 6. Please click the “Finish” button. 7. When the above page is appear, please click “Yes” and reboot.
  • Page 14 8. Please check if the PC camera is recognized on Imaging Devices of Device Manager. • Introduction pages are all of Window XP but it will be installed in the same procedure on Window 2000 • Method of open Device Manager for Windows XP: Start Menu ⇒...

  • Page 15: Driver Recognition On Windows 98/98Se/Me

    3.3 Driver recognition on Windows 98/98SE/ME Connect WebCAMeye Light spare port Recognition procedure will be completed automatically. 2. Please check if the PC camera is recognized on Imaging Device of Device Manager. • Introduction pages are all of Window ME but it will be installed in the same procedure on Window 98/98SE •...

  • Page 16: Remove Software And Driver

    3.4 Remove software and Driver. 1. If you want to remove the software, select “Uninstall WebCAMeye Light Software” of WebCAMeye on Start Menu and click “Yes” button. 2. If you want to remove the driver, select “Uninstall” of 301P USB Camera on the Starting Menu and click “YES” button.

  • Page 17: Webcameye Light Usage

    4. WebCAMeye Light usage 4.1 Name Camera lens Iris Flexible wire (Free direction) Magnetic stand (Main body has magnetic built-in.)

  • Page 18: Focus Adjustment

    4.2 Focus adjustment. The image should be focused adjusting the Iris by hand for WebCAMeye Light. So the image can be out of focus because of the PC camera location. In that case, please adjust the focus as following instructions; A .

  • Page 19: Adhesion Of The Magnetic Panel

    4.3 Adhesion of the magnetic panel. WebCAMeye Light has magnetic panel built-in on its bottom. So you are supposed to place the WebCAMeye Light on normal computer metal case or place it on the enclosed magnetic panel that is placed at the desired spot.

  • Page 20: Set Up The Options

    4.4 Set up the options WebCAMeye Light setup page is as bottom; (Example : Camera Setup menu of WebCAMeye S/W setup button.) • Brightness Adjust Brightness. ( 1 ~ 40 Default : 20) • Contrast Adjust Contrast. ( 1 ~ 40 Default : 20) •...

  • Page 21: Webcameye Light S/W Usage

    5. WebCAMeye Light S/W Usage 5.1 WebCAMeye Usage instruction This software is developed mainly for PC camera and is valid for showing the present image taken by PC camera, saving function of the photos and the video image as well as sending the photos by e-mail and connecting the EyeImage and Eyechat.
  • Page 22 • Adjust the resolution. There are two ways to adjust the resolution. One is to press the right button of mouse placed on the screen and the other is to adjust it in the program setup dialog of set up button. •...
  • Page 23 • Full screen display. You can display the image data to through the full screen. It is useful to enlarge images or for surveillance monitor. • The full screen image will be quite unnatural at low resolution. • The image speed can be slow down since the full screen image requires higher system capacity.
  • Page 24 • Camera setup and Program environment setup. If you press “Setup” button, there are two menus; Camera setup and Program Setup. Camera setup Program setup • Please refer to the index 4.4 set up the options to set up the camera. •...
  • Page 25 B. Photographing function. If you press “Photo” button on WebCAMeye, small sub-window will appear as follows. • Photo: You can save the photo to BMP or JPG file. (It is possible to select at the program set up box.) • Edit: Connect the selected photo to the imaging program. (BMP file will be operated by EyeImage and JPG file follows the ordinary windows image program.) •...
  • Page 26 C. AVI file function. If you press “AVI” button on WebCAMeye, small sub-window will be appear. • Record: Save the video by AVI file. (If you want to stop the recording, press “Save” button.) • Play: Play the selected AVI file. •...
  • Page 27 D. Connecting related programs • Chat chat person-to-person operating EyeChat program without opening the start menu. ※ • Connect to EyeImage program You should click “Edit” button after you select thumb nail on photo sub-window or you should do double clicks the selected thumb nail.

  • Page 28: Eyeimage Usage Instruction

    5.2 EyeImage Usage instruction EyeImage is an image processing base tool. It’s function is similar to filter function of the Photoshop. It provides various functions like reversing images, adjusting image size and distorting colors. A. Applied functions. • RGB, HSI, YIQ, CMYK and etc. Conversion •...

  • Page 29: Eyechat Usage Instruction

    5.3 EyeChat Usage instruction Eyechat program that is developed for P2P video chatting is a chatting program for chatters to communicate watching each other using PC camera. It is regarded as total chatting software providing Text and file exchanges and vocal conversation at the same time. A.
  • Page 30 • Add new name on the list If you press “Connect” button on EyeChat, the below page will appear. a. Please enter conversation partner at Connect information. Name : Partner’s name IP address : Computer network parter’s IP address ※ Port No.
  • Page 31 B. Data Sending ※ • Video and audio Sending Video and audio check boxes should be checked to send your picture and vocal data. Likewise your conversation partner’s ones also should be checked for you to receive his picture and voice. •...
  • Page 32 • File Sending If you press “File Send” button, the below window will appear to select the file to send. When you select the file, the below window will appear on your partner’s side. The partner should press “Yes” button to receive the file •...
  • Page 33 Q What can I do if I don’t have Window CD even though it requires to insert window CD. A Window CD is necessary. You should prepare installed window CD like Windows 98, Windows 98SE or Windows ME to complete the installation properly.
  • Page 34 WebCAMeye Light camera driver. • A/S Company : Mobitechplus Inc. Address : #203, 32-5, Songwol-Dong, Jongno- Gu, Seoul, Korea Tel. : 82-2-730–3722 Fax. : 82-2-730-3726...
