High Performance
V.90/K56flex/V.34+/V.42bis
56000BPS
Plug & Play Internal
Data/Fax/Modem
User's Manual
Contents
Section One - Introduction ........................... 1
Section Two - Installation Guide .................. 1
Section Three - AT Command Set ............... 5
Section Four - S Registers........................10
Appendix A Specifications ........................ 10
Appendix B Installations ..........................11
F-1156IV/R9
Advertisement
Table of Contents
Summary of Contents for Acorp 56000BPS
-
Page 1: Table Of Contents
High Performance V.90/K56flex/V.34+/V.42bis 56000BPS Plug & Play Internal Data/Fax/Modem User's Manual Contents Section One - Introduction ......1 Section Two - Installation Guide ....1 Section Three - AT Command Set ....5 Section Four - S Registers......10 Appendix A Specifications ......10 Appendix B Installations ......11... - Page 2 The information contained in this manual has been validated at the time of this manual's production. The manufacturer reserves the right to make any changes and improvements in the product de- scribed in this manual at any time and without notice.
-
Page 3: Section One - Introduction
Section One - Introduction This 56 kbps* Plug and Play FAX/Data Modem connects your computer to all popular high speed mo- dems available today. Its incorporates "V.90/K56Flex" (56Kbps) technology to provide increased download speeds using regular telephone lines. The modem incor- porates Plug and Play for ease of installation. - Page 4 4.Select "Search for the best driver for your device" Option. Click Next and you should see: 5.Insert the CD-ROM that comes with your Modem into the CD-ROM drive. Make sure the CD-ROM drive check box is checked. Leave all other check boxes blank. Click Next and you should see:...
- Page 5 6.Click Next and you should see the following. 7.Wait until Windows 98 finishes copying all the required files.
- Page 6 8.When you see the above window, Windows 98 has already finished copying all the files. Click Finish and you should see the following window. 9.Your Modem is now installed in Windows 98.
-
Page 7: Section Three - At Command Set
Section Three - AT Command Set 3.1 Commands Commands are accepted by the modem while it is in Command Mode. Your modem is automatically in Com- mand Mode until you dial a number and establish a connection. Commands may be sent to your modem from a PC running communication software or any other terminal devices. - Page 8 flash return to Command Mode after dialing Commands are not echoed Commands are echoed Escape Characters Switch from Data Mode to Command Mode Force modem on-hook (hang up) Force modem off-hook (make busy) Reports product code Reports Pre-Computed checksum Internal memory test Firmware ID Reports data pump model and internal code revision...
-
Page 9: Extended At Commands
All responses and dial tone and busy signal detection Reset and retrieve active profile 0 3.4 Extended AT Commands &C_ &C0 Force Carrier Detect Signal High (ON) &C1 Turn on CD when remote carrier is present &D_ &D0 Modem ignores the DTR signal &D1 Modem returns to Command Mode after DTR toggle... - Page 10 direction. Parameter¡§e¡¨specifies the minimum connected direction.Parameter ¡§f¡¨specifies the maximum connected direction. 3.5 MNP/V.42/V.42bis Commands +ES? Displays the current Error Control and Sychronous Mode Selection settings. +ES=? Displays a list of supported Error control and Sychronous Mode Selection options. +ES=a,b,c Error Control and Sychronous Mode Selection where: a=1-4, b=0,2-4, c=1 ,2,4,5,6.
-
Page 11: Fax Class 1 Commands
+DS=? Displays a list of supported Data compression options. +DS=a,b,c,d Data Compressin. a,b,c,d default =3,0,2048,32.Paramerer¡§a¡¨specifies the desired dierction(s) of operation of operation of the data comperession function where:0=no compression, 3=both. Parameter ¡§b¡¨ specifies whether or not the modem should continue to operate if the desired result is not obtained where:0= Do not disconnect if V.42bis not negotiated by the remote modem as... -
Page 12: Section Four - S Registers
+FTS=n Stop transmission and wait Section Four - S Registers Your modem has 13 registers, designated S0 through S29. Table 3-1 shows the registers, their functions, and their default values. Some registers can have their values changed by commands. If you use a command to change a register value, the command remains in effect until you turn off or reset your modem. -
Page 13: Appendix B Installations
Error Correction: V.42/MNP2,3,4 Other Function: Plug and Play ,ACPI Power management compliantly . Host Interface: Plug and Play PCI bus interface. Transmit Level: -11dBm Receiver Sensitivity: -32dBm(V.34);-36dBm(all other protocols) DTE Speeds: 300-115200bps Operating Temperature: -0 - + 55 degrees C Storage Temperature: -50 - + 70 degrees C Appendix B - Specifications...
