16 CHANNEL
IR/RF REMOTE
INTERFACE
Ramsey Electronics Model No.
Turn your old TV remote into a controller for your next hobby
project. Gives a 4-bit output for each button press. Oh, the
possibilities!
•
IR Receiver module with sensitive element can receive your
remote control up to 11 meters away.
•
Outputs a 4 bit number for each button pushed giving you 16
possible codes.
•
Up to 16 buttons can be used.
•
Receives IR from a remote control or an RF signal from our
wireless IR remote repeater, the RRW1A.
•
5VDC (regulated!) operation.
•
Convenient LED indicator lets you know infrared and
programming status.
•
Mode jumper for various interfaces to microcontrollers or external
ICs
ICI16
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ramsey Electronics ICI16
Summary of Contents for Ramsey Electronics ICI16
- Page 1 16 CHANNEL IR/RF REMOTE INTERFACE Ramsey Electronics Model No. ICI16 Turn your old TV remote into a controller for your next hobby project. Gives a 4-bit output for each button press. Oh, the possibilities! • IR Receiver module with sensitive element can receive your remote control up to 11 meters away.
- Page 2 Ramsey Electronics publication No. ICI16 Revision 1.2 First printing: January 2004 DAR COPYRIGHT 2002 by Ramsey Electronics, Inc. 590 Fishers Station Drive, Victor, New York 14564. All rights reserved. No portion of this publication may be copied or duplicated without the written permission of Ramsey Electronics, Inc.
-
Page 3: Table Of Contents
Ramsey Publication No. ICI16 Price $5.00 KIT ASSEMBLY AND INSTRUCTION MANUAL FOR ICI16 IR/RF CONTROL INTERFACE KIT TABLE OF CONTENTS Introduction ...........4 Theory of Operation ......5 Learn As You Build .......8 Parts List ..........10 Parts Placement Diagram ....11 Assembly Steps........12 Testing and Programming....14... -
Page 4: Introduction
ICI16 INTRODUCTION Welcome to the ICI16 kit . In this manual we will try to help you understand IR remote controls and how they typically work, and also how this kit works, to help you understand what you are building. -
Page 5: Theory Of Operation
ICI16 THEORY OF OPERATION At first look the ICI16 may seem quite simple, but there is actually quite a bit to it on the “inside” of the components. Many items are inside the IR receiver part (U3/4) and if built up with discrete components it would never fit in this little kit. - Page 6 After the ICI16 locks on to the code it outputs it at J1 as a 4-bit number. The mode switch selects between two different methods of outputting data, and in fact only affects the “VALID”...
- Page 7 The following shows the progress of receiving five valid codes programmed for code 4 in mode 1 and mode 0. MODE1 DATA3 DATA2 DATA1 DATA0 VALID 0100b = 4 MODE0 DATA3 DATA2 DATA1 DATA0 VALID ICI16• 7...
-
Page 8: Learn As You Build
(1). The part is then soldered securely to the board (2-4), and the remaining lead length is clipped off (5). Notice how the solder joint looks on close up, clean and smooth with no holes or sharp points (6). ICI16• 8... - Page 9 If a problem does occur the manual will lead you through step by step in the troubleshooting guide until you find the problem and are able to correct it. ICI16• 9...
-
Page 10: Parts List
PARTS SUPPLIED WITH YOUR ICI16 KIT Capacitors 0.001 uF ceramic disc capacitors [marked 102] (C7) 0.01 uF ceramic disc capacitors [marked 103] (C1,C10) 0.1 µF ceramic capacitors [marked 104] (C2,C8,C12,C14) 10 pF ceramic capacitors [marked 10 or 10K] (C5,C6,C9,C11) 1 µF electrolytic capacitor (C4) 10 µF electrolytic capacitors (C3, C13) -
Page 11: Parts Placement Diagram
ICI16 PARTS LAYOUT DIAGRAM ICI16• 11... -
Page 12: Assembly Steps
MICRF001BN], to the left of C3. Line up the notch with the notch on the board drawing. This chip chews up RF and spews out yummy data. It comes into play when you use the ICI16 with our wireless IR remote repeater. -
Page 13: Data3
Orient both flat sides and leave the LED up off the PC board as far as you need to so that you can see it later when you’re programming. ICI16• 13... -
Page 14: Testing And Programming
IC’s. Remember that any problems you find now can save time and effort after the unit has been cased up and final assembled. TESTING AND PROGRAMMING YOUR ICI16 To begin testing the ICI16 we will need the following items: Regulated 5VDC power. An infrared remote control... - Page 15 Apply 5V DC to pins 1 and 2 on header J2. Pin 1 is denoted with a triangle symbol. Install included header jumper between pins 2 and 3 to select IR mode. You are now ready to program your ICI16. PROGRAMMING YOUR ICI16 Remember to install some fresh batteries in your remote control, and aim the infrared LED towards the photo sensor.
-
Page 16: Example Hookups
EXAMPLE HOOKUPS Below are a couple of ideas on how to use the ICI16 in an application. Since it is designed to be an add-on module you can use it in a variety of ways. The top example shows how you can activate relays using a 4-16 line decoder (74HC154). -
Page 17: Troubleshooting
TROUBLESHOOTING GUIDE If your ICI16 does not work at all, re-check the following: • correct orientation of ICs, Q1, Q2, and the electrolytic capacitors (see PC board layout diagram). • all solder connections PROBLEM: The green LED doesn’t blink when I aim my remote at it. - Page 18 It usually is something simple. Have your board revision handy to help our technicians find the proper schematic for your needs. You can email our tech support as well at the ramseykits.com website. Oh, please count to ten before calling taking some deep breaths first... ICI16• 18...
-
Page 19: Specifications
ICI16 INFRARED CONTROLLER INTERFACE SPECIFICATIONS Here are few of the commonly requested specifications for the ICI16: J5 Power Input - Input working voltage range: 5VDC regulated only. - Max ICI16 current draw is between 20-50mA. Miscellaneous Information - PCB Dimensions: 4.45”x1.455”... -
Page 20: Ici16
These pages were intentionally left blank to provide plenty of room for notes! ICI16• 20... - Page 21 ICI16• 21...
-
Page 22: Schematic Diagram
ICI16• 22... -
Page 23: Warranty
'missing' 10 K parts ("Hum-m-m, I guess the 'red' band really does look orange!") Ramsey Electronics project kits are packed with pride in the USA. If you believe we packed an incorrect part or omitted a part clearly indicated in your assembly manual as supplied with the basic kit by Ramsey, please write or call us with information on the part you need and proof of kit purchase. - Page 24 ICI16 REMOTE INTERFACE KIT Quick Reference Page Guide Introduction ...........4 Theory of Operation ......5 Learn As You Build........8 Parts List ..........10 Parts Placement Diagram ....11 Specifications ........21 Schematic Diagram ......22 Warranty..........23 REQUIRED TOOLS • Soldering Iron Ramsey #RTS06 • Thin Rosin Core Solder Ramsey #RTS12 •...
