- Page 1 MD411-IR Tracker Gold Camera Mini Dome IP User’s Manual Ver. 1.1...
-
Page 2: Table Of Contents
Table of Contents Overview ..........................2 Features ........................2 Package Contents ....................... 3 Dimensions ........................5 Connectors (Indoor Only)..................... 6 Function Cables (Outdoor Only) .................. 7 Camera Cabling ........................8 Power Connection ....................... 8 Ethernet Cable Connection ..................8 Waterproof Cable Connector (Outdoor Only) ............... 9 System Requirements ...................... -
Page 3: Overview
Overview The Superior HDR Mini Dome IP Camera is a high-end surveillance solution with easy set up design. Supporting up to 4M real-time video and Quad Streams Codec (H.264 Baseline / Main / High Profile + MJPEG), the camera offers supreme image quality while keeping efficient bandwidth for storage management. -
Page 4: Package Contents
Package Contents Please check the package containing the following items listed below. Indoor Superior HDR 2-Pin Power Terminal Block Mini Dome IP Camera Self-Tapping Screw (x3) Plastic Screw Anchor (x3) Quick Guide (bundled software and documentation) NOTE: The supplied self-tapping screws are for soft substances / materials such as wood. - Page 5 Outdoor Superior HDR Mini Dome IP Camera Rubber Washer (x2) Security Torx Self-Tapping Screw (x3) Plastic Screw Anchor (x3) 2-Pin Power Terminal Block 4-Pin Alarm I/O Terminal Block Quick Guide (bundled software and documentation) NOTE: The supplied self-tapping screws are for soft substances / materials such as wood.
-
Page 6: Dimensions
Dimensions The dimensions of the camera are shown below. Indoor Outdoor... -
Page 7: Connectors (Indoor Only)
Connectors (Indoor Only) The diagram below shows the default button, microSD card slot and various connectors of the camera. Definition for each connector is given as follows. Connector Definition Remarks RJ-45 For network and PoE connections Power DC 12V 1 AC 24V 1 Power connection (DC 12V / AC 24V) -
Page 8: Function Cables (Outdoor Only)
Function Cables (Outdoor Only) Connector Definition Remarks RJ-45 For network and PoE connections Power DC 12V 1 AC 24V 1 Power (DC 12V / AC 24V) connection DC 12V 2 AC 24V 2 Pink Audio In Two-way audio Audio I/O* Green Audio Out transmission... -
Page 9: Camera Cabling
Camera Cabling Before users connect cables, make sure that all cables and the power adaptor are placed in dry and well-waterproofed environments, e.g. waterproof boxes. The purpose is to prevent moisture accumulation inside the camera and moisture penetration into cables, which might lead to camera breakdown. Follow the instructions below to complete camera connection. -
Page 10: Waterproof Cable Connector (Outdoor Only)
Waterproof Cable Connector (Outdoor Only) Follow the instruction below to waterproof the connectors of different types of cables. The supported cables are as shown below. RJ-45 Cable IP66 RJ-45 Cable RJ-45 Cable Follow the instruction below to waterproof the connector of the RJ-45 cable. Plug the Ethernet cable to the connector of the RJ-45 cable and coat the joint with silicone gel. - Page 11 Step 3: Fasten the RJ-45 IP66 plug to the connector of the IP66 RJ-45 cable. Lastly, tighten the thread-lock sealing nut to the plug.
-
Page 12: System Requirements
System Requirements To perform the IP camera via web browser, please ensure the PC is in good network connection, and meet the system requirements as described below. Items System Requirement ® ® 1. Intel Pentium M, 2.16 GHz or ® Personal Computer Intel Core... -
Page 13: Access Camera
Access Camera For initial access to the IP camera, users can search the camera through the installer program: DeviceSearch.exe, which can be found in “DeviceSearch” folder in the supplied CD. Accessing the Camera by Device Search Software Step 1: Double click on the program Device Search.exe. Step 2: After its window appears, click on the <Device Search>... - Page 14 Step 8: A prompt window requesting for default username and password will appear. Enter the default username and password shown below to login to the camera. Login ID Password admin admin NOTE: ID and password are case sensitive. NOTE: It is strongly advised that administrator’s password be altered for the security concerns.
- Page 15 Once the Viewer is successfully installed, the Home page of the IP camera will be shown as the figure below. Board Lens Models...
-
Page 16: Setup Video Resolution
Setup Video Resolution Users can setup video resolution on the Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming> Video Format. The default value of video resolution is as below. H.264- 2688 x 1512 (25/30 fps) + H.264- 720 x 576 (25 fps) / 720 x 480 (30 fps) For more details about the combinations of video resolution, please refer to the Superior HDR IP Camera Menu Tree in the supplied CD. -
Page 17: Configuration Files Export / Import
Configuration Files Export / Import To export / import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the camera. -
Page 18: Tech Support Information
Tech Support Information This chapter will introduce how to delete previously-installed Viewer in the PC and how to setup the Internet security. Delete the Existing Viewer For users who have installed the Viewer in the PC previously, please remove the existing Viewer from the PC before accessing to the IP camera. Deleting the Viewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>. -
Page 19: Setup Internet Security
Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE). Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>.
