BL-BKB76 Bluetooth Keyboard Manual
Packing Include:
1,A Bluetooth keyboard
2, A IPAD bag ( optional part )
3,A list of manual
4、USB charging cable （If "apple" 30PIN, charging interface don't need）
Product Features:
1, With Broadcom2042 as main control chip , with Bluetooth 2.0 interface .
2, Use industry-leading Bluetooth solution, WIDCOMM BTW Bluetooth software which is
specified software by Microsoft
official.
3, Specially design for IPAD, It will be more convenient to carry with IPAD bag .
4, Buit-in
power management software, It can automatically show the available capacity in the Microsoft Windows
5,
Silence design, It will not affect other people's rest
6,It is waterproof ,dustproof, anti-pollution, anti-acid, waterproof for silicone part
7, work with PC and commerical mobile, It will be convenient to work .
8, working temperaturer :-20℃-55℃ humidity:20%-50%
9.built-in lithium battery, you do not need to frequently change battery
Specifications
1, executive standard: Bluetooth V2.0
2 Working distance: 10 meters
3, modulation system: FHSS 2.4G
4, transmitting power: Class 2
5, operating voltage: 3.0-5.0
6, work current: <5.0MA
7, standby current: 2.5MA
8, sleeping current: <200UA
9, charging current:> 100MA
10, standby time: 100days
11, Theory of working Time: 25 days
12, uninterrupted working time: 90 hours
13, charging time: 4-4.5 hours
14, Li-ion battery Capacity: Minimum 430MAH
15, lithium battery life: 3 years
16, lithium battery Specifications: 4.5 * 24 * 47MM
17, key strength: 80 ± 10g
Advertisement
Table of Contents
Related Manuals for Paoluy BL-BKB76
Summary of Contents for Paoluy BL-BKB76
- Page 1 BL-BKB76 Bluetooth Keyboard Manual Packing Include: 1,A Bluetooth keyboard 2, A IPAD bag ( optional part ) 3,A list of manual 4、USB charging cable （If “apple” 30PIN, charging interface don’t need） Product Features: 1, With Broadcom2042 as main control chip , with Bluetooth 2.0 interface .
- Page 2 18, key life: 500 million 19, operating temperature: -20 - +55 ℃ 20, Storage temperature: -40 - +70 ℃ Note: When you switch on the keyboard, the power light and Bluetooth light will be on in three seconds , at this time the keyboard do not connnect with any device.,But the LED light will automatically be off if the keyboard still do not connected to any device after the Led keep lighting for 5 seconds.
- Page 3 Click setting in Ipad Click to open the Bluetooth Step 2: Enter the password and connect Ipad is in searching situation .It can search bluetooth keyboard . search for bluetooth keyboard and remind to enter password in the bluetooth keyboard Note There will not have any prompt , just click enter after your enter passwork in the Ipad screen ..It will be connected successfully.
- Page 4 Step 3: Connect successfully , The keyboard is in working situation Connect successfully the keyboard is in working situation Power light will keep lighting after it connect successfully , so the keyboard can work with IPAD successfully .The lighting power light to remind that you should turn off the keyboard when you do not use it . Charge The power light keep flashing in your working ,the keyboard is short of power .
- Page 5 Storage （1） 、 When you are finished using your keyboard or you will be required after the keyboard to carry , so don't forget to set aside the keyboard to switch the source OFF, turn off the keyboard's power to extend battery life (2)When you need a long time storage your keyboard, please don't forget to pack the battery power, about half of the filling , then store your keyboard, so can make your keyboard lithium life longer.
- Page 6 TIPS: When your battery is low, low-voltage lights on the keyboard will blink, and you should give your keyboard charging, so as not to affect your work. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device. Pursuant to Part 15 of the FCC Rules.
