Summary of Contents for True Systems MSA Lite
- Page 1 Portable Measurement Device MSA Lite Quick User’s Manual ver.0.92...
- Page 2 The cradle has a built in charging system for easy on counter powering. 1.1 Package contents The MSA Lite consists of a main unit, a 50XPL lens, a cradle, a USB cable, and power adapter (see image below). Before using the MSA Lite, please confirm all parts have been received.
- Page 3 2. How to use the MSA lite 2.1 Parts name Home screen 2.2 Power ON/OFF To power on the MSA Lite, press and hold the left button for about 2 seconds.
- Page 4 Please note the battery needs to be charge sufficiently for the device to operate properly. When the MSA Lite is on and you press and hold the left button for about 2 seconds, the power will turn off. The battery will charge automatically when put on the cradle. After 10 minutes on the cradle, the MSA Lite will turn off.
- Page 5 See the SYSTEM set up for more information. 2.5 Connection with PC via USB Stored data on the MSA Lite can be transferred to a computer by connecting the USB cable to the computer. The embedded software of the device can also be updated by connecting to computer using a USB interface.
-
Page 6: System Setup
2.6 SYSTEM Set up At the home screen, if the below keys are pressed in sequential order the System Setup screen will appear. Left button(mode button)->Front button(capture button)->Right button(freeze button) [Lens] : to change the magnification [USB] : to enable the USB mode to communicate with computer. - Page 7 3. MSA lite program 3.1 How to use embedded software The MSA lite has software for skin imaging and analysis. The home screen below will appear once the unit has been successfully booted and you can choose the [START] or [SCOPE] menu with the navigation switch.
- Page 8 The software measures seven parameters, which are all displayed in the measurement screen. Select any parameter icon you want to measure by clicking the center of ③ navigation switch. After selecting the icon, the software will automatically turn to the correct lighting mode.
- Page 9 For example, if you would like to measure and analyze skin texture, choose the [Skin Texture] icon. You can see a live image of the skin, capture the image by pressing the freeze button, and analyze the image by selecting the [Analysis] button. Once the image has been analyzed, go back to the parameter screen by pressing [Prev].
- Page 10 ▶ Pigmentation With the pigmentation measuring process, images are captured with the polarized lighting mode. Pigmentation Analyzed image ▶ Sebum In the sebum mode, the device measures and analyzes sebum by taking an image of the Sebutape, which is used by pressing the gray box on Sebum Analyzed image...
- Page 11 ▶ Keratin In the keratin mode, the device measures through an image of keratin tape, which is a black tape that is placed on the customer’s skin to remove Keratin Analyzed image dead skin cells. ▶ Pore For the pore mode, the device measures the pores of skin.
- Page 12 Wrinkle Analyzed image 3.4 Results The analyzed results of each parameter are displayed on two pages. If you choose the thumbnail image of any item by pressing the center of the navigation switch, you can check the original image. The Results section has two screens. One result screen has four results of items and the other has three results of items.
-
Page 13: Specification
Charged on cradle AC adaptor, 5V DC, 2A 2011 True Systems Co., Ltd. All rights reserved. All designs and other registered symbols are the property of True Systems. True Systems reserves the right to change the specification without notice. One year warranty.
