- Page 1 CROW LCD Keypad PW LCD KP-64 & PW LCD KPS-64 Operating & ProgrammingGuide Arrowhead Alarm Products Ltd VERSION 2.02...
-
Page 2: Table Of Contents
CONTENTS Page No. INTRODUCTION Introduction to the LCD Keypad KEYPAD SETUP Setting the keypad address Setting the panel type DESCRIPTION OF KEYPAD BUTTON OPERATION What each keypad button does LOCAL KEYPAD FUNCTIONS Adjusting the LCD backlighting Adjusting the keypad LED backlighting Adjusting the keypad buzzer tone (volume) Accessing the Alarm Event Memory Mode LOCAL EDIT PROGRAM MODE... -
Page 3: Introduction
Introduction Thank you for purchasing the CROW LCD (liquid crystal display) keypad. The LCD keypad uses two lines of 16 characters to display full alpha numeric text. This keypad has been designed to keep the day to day operation as simple as possible so that all users will feel comfortable using the alarm system. -
Page 4: Keypad Setup
Setting the Keypad Address & Panel Type Both the Keypad address and the panel type are changed in what is called LOCAL MODE. To Enter LOCAL MODE you must power up the keypad and then press the “CONTROL” button followed within 2 seconds with the “ARM” button at the same time. The keypad will display LOCAL MODE KP1 on the LCD. -
Page 5: Description Of Keypad Button Operation
Keypad Button Descriptions (Please refer to the keypad layout in figure 1, page 3, for the button positions on the keypad) This button is used to Arm the full alarm. This button is used do a partial “Stay Mode” arming. It is also used during STAY Program mode to move display text left. -
Page 6: Local Keypad Functions
Local Keypad Functions *Adjusting the Keypad Backlighting* The user can independently adjust the backlight level of the LCD display and the keypad buttons (LED) within a range of 16 steps from fully off to fully on. To increase the LCD backlight level Press “CONTROL” followed within 2 seconds by “STAY”. -
Page 7: Local Edit Program Mode
Local Edit Program Mode The Local Edit Program Mode allows the programming of a customized “System Name” (the name displayed during idle mode at the keypad), Customized “Zone Names” (the text that appears on the keypad when a zone is unsealed) and renaming of the Partitions e.g. the default Partition names are “A”... -
Page 8: Text Selection Chart
Once you have selected the desired font size you can now proceed to change the text for Zone 1. The following table shows the English Characters that can be selected by each numeric but- ton. ▼Button # 1st Press 2nd Press 3rd Press 4th Press * (‘) -
Page 9: Changing The Panel Name Displayed On The Lcd
*Changing the Keypad Panel Name* Name <A..Z> PowerWave 16D When in Local Edit Mode enter in [PROG]-[999]-[ENTER] the display will look like the exam- ple above (the actual name will depend on the settings of switches 4-7 as per the chart on page 4). -
Page 10: Copying Edited Text To Other Lcd Keypads
*Copying the text to other LCD keypads connected to the panel* If more than one LCD keypad is connected to the panel, it is possible to copy the edited Text from one LCD keypad to any other keypads connected to the same panel. While in “Local Edit Mode”... -
Page 11: Owners Details
OWNERS DETAILS INSTALLERS NAME: INSTALLERS CONTACT PH #: TEXT EDIT CHANGES Control Panel Name : AREA A Character (Default A) AREA B Character (Default B) AREA C Character (Default C) AREA D Character (Default D) ZONE DESCRIPTIONS: Zone # 1 Zone # 2 Zone # 3 Zone # 4... - Page 12 ARROWHEAD ALARM PRODUCTS 344B ROSEDALE RD, ALBANY, AUCKLAND, NEW ZEALAND PHONE: 09 414 0085 FAX: 09 414 0088 www.aap.co.nz...
