TMI PRODUCTS, INC.
OPERATING
INSTRUCTIONS
Headrest 7.0" 16:9 Color Display Monitor
Important Notice
It is unlawful in most jurisdictions for a person to drive a motor vehicle which is
equipped with a television or screen that is located in the motor vehicle at
any point forward of the back of the driver's seat, or that is visible directly
or indirectly to the driver while operating the vehicle.
CAUTION
1.
Do not expose to direct sunlight for extended periods of time.
2.
Do not drop the monitor or expose to strong impacts.
3.
Keep the monitor clean and dry.
4.
Do not operate the monitor at temperatures below -22°F (-30°C) or above 185°F (85°C).
Model No.AS700
9100768

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AS700 and is the answer not in the manual?

Questions and answers

Summary of Contents for TMI Products AS700

  • Page 1 TMI PRODUCTS, INC. OPERATING INSTRUCTIONS Headrest 7.0" 16:9 Color Display Monitor Model No.AS700 Important Notice It is unlawful in most jurisdictions for a person to drive a motor vehicle which is equipped with a television or screen that is located in the motor vehicle at any point forward of the back of the driver's seat, or that is visible directly or indirectly to the driver while operating the vehicle.
  • Page 2 Installation Guide: The kit includes a protective trim ring and an optional spacer ring for use when the mounting surface is uneven. 1. Select appropriate locations in your vehicle for the monitor . 2. Be sure there is sufficient depth for the trim ring. Add the spacer ring for shallow locations with uneven curved surfaces such as upholstery.

  • Page 3: Electrical Connections

    Electrical Connections: Passage side Drive side Black --- GND POWER CORD Red --- ACC Yellow ---Power Green --- Park Note: P leas e make s ure all cables are connected correctly, wrong connections will damage the monitor.

  • Page 4: Basic Operation

    Basic Operation: Front Control Panel: 1. IR Receive 2. LCD Panel 10. Earphone 3. POWER : ON / OFF / AUX Selection button 9. A / V AUX (press and hold the button will power off) 8. IR Transmitter 4. SOURCE : Select the internal AV1 / AV2 / AV3 (2 Input) player 5 MENU : Activation of Menu Indicator...

  • Page 5: On-Screen-Display Settings

    Basic Operation: Menu MENU MENU If the source unit selected has a Setup Menu, you can access it by pressing Source Menu. With the AV1 / AV2 / AV3, this button activates the screen Constrast / Brightness / Color / Tint / Shapness / Dimmer / Screen / Reset default feature.
  • Page 6 On-Screen-Display Settings: CONSTRAST: Press Menu button on remote or on control panel, OSD menu will show on LCD screen as below (left chart), press up/down button on remote or press and hold up/down button on control panel to select "CONSTRAST" setting, "CONSTRAST" setting will show as below (right chart). CONSTRAST BRIGHTNESS: Press Menu button on remote or on control panel, OSD menu will show on LCD screen as below...
  • Page 7 On-Screen-Display Settings: TINT: Press Menu button on remote or on control panel, OSD menu will show on LCD screen as below (left chart), press up/down button on remote or press and hold up/down button on control panel to select "TINT" setting. "TINT" setting will show as below (right chart).
  • Page 8 On-Screen-Display Settings: SCREEN: Press Menu button on remote or on control panel, OSD menu will show on LCD screen as below (left chart), press up/down button on remote or press and hold up/down button on control panel to select "SCREEN" setting. "SCREEN" setting will show as below (right chart).
  • Page 9 On-Screen-Display Settings: RESET DEFAULT Press Menu button on control panel, OSD menu will show on LCD screen as below (left chart), Press up/down button on control panel to select "RESET DEFAULT" setting. "RESET" setting will show as below (right chart). RESET DEFAULT BASIC FUNCTIONS : Press and hold Menu button about 5 seconds on control panel to select from the...

  • Page 10: Installation Notes

    Basic Functions : MENU MENU MENU IR CHANNEL CH A IR CHANNEL CH IR CHANNEL CH OFF AV SYSTEM AV1 / 2 / 3 AV SYSTEM AV1 / 2 / 3 AV SYSTEM AV1 / 2 / 3 MIRROR MIRROR MIRROR SCREEN SCREEN...

  • Page 11: A/V Input And Output

    Highlights: 7" Active TFT LCD AS700 with built-in FMM AS700 - Without FMM - Can be use for visor monitor Monitor can be turned ON when Parking is high or floating Monitor will shut down when parking is set to Low.
