Installation Manual Rev: 1.2 Last Revised: 3/22/16 SYSTEM OVERVIEW Gateway is an embedded computer that provides interfacing capability among a variety of wired and wireless networks. It implements WAN designs, with the additions of Bluetooth, WIFI, 433- MHz radio, and Satcom interfaces. PURPOSE This Installation Manual is intended to inform installers and users of the proper placement, configuration and distances between system components.
Installation Manual Rev: 1.2 Last Revised: 3/22/16 3.2. INSTALLATION INSTRUCTIONS OVERVIEW System installation is accomplished in the following steps: 1) Installation of Gateway into the tractor cab headliner a. Torque the antenna terminations to Gateway RF SMA connectors with a torque spec of 7-10 in-lbs +/- 0.5 in-lbs.
Installation Manual Rev: 1.2 Last Revised: 3/22/16 3.4. HARDWARE COMPONENTS BACKGROUND 3.4.1. Electrical Characteristics Input Power Requirements: 9-16 VDC Current Draw at 14VDC: 250mA (nominal) 3.4.2. Weight and Balance Information The total weight of the Garrison and antenna is listed below. Table 3 Weight and Balance Information Component Weight (oz)
Installation Manual Rev: 1.2 Last Revised: 3/22/16 To set the device to transmit in FCC Part 15.231(e) mode, use the API command string as indicated below in quotes (“ ”). “iLPD433.send(“MyMessage”,9, FCC_PERIODIC_15_231_E,suggestedRetryIntervalMS,100,actualSentPowerDBM);” Otherwise in the above command, replace the argument “FCC_PERIODIC_15_231_E” with “FCC_APERIODIC_15_231_AD”...
Installation Manual Rev: 1.2 Last Revised: 3/22/16 4.2. GATEWAY SYSTEM SEPARATION DISTANCE ILLUSTRATION Gateway and the following components must follow the distances in the following illustration to comply with FCC part 1.310. 40 cm (USA) 40 cm (USA) 60 cm (Canada) 60 cm (Canada) Operator 20 cm...
