SVOA Professional Manual

Hide thumbs

Table of Contents

Quick Links

Download this manual

Professional

MANUAL

Contents

Notices................................................................................................ A

Safety information.............................................................................. B

Specification summary....................................................................... C

About this guide................................................................................. D

Chapter 1: Product introduction

1.1 Central Processing Unit(CPU)..................................................... 1

1.1.1 Overview............................................................................ 1

1.1.2 Installing the CPU............................................................. 2

1.2 System memory............................................................................ 3

1.2.1 DIMM sockets location..................................................... 3

1.2.2 Memory configurations..................................................... 3

1.2.3 Installing a DIMM............................................................ 4

1.3 Expansion slots............................................................................. 5

1.3.1 PCI slots............................................................................ 5

1.3.2 AGP slot............................................................................ 5

1.4 Jumpers.......................................................................................... 6

1.5 Connectors..................................................................................... 8

1.5.1 Rear panel connectors....................................................... 8

1.5.2 Internal connectors............................................................ 9

Table of Contents

Need help?

Do you have a question about the Professional and is the answer not in the manual?

Questions and answers

Summary of Contents for SVOA Professional

Page 1: Table Of Contents
1.2.1 DIMM sockets location............. 3 1.2.2 Memory configurations............. 3 1.2.3 Installing a DIMM............4 1.3 Expansion slots................5 1.3.1 PCI slots................5 Professional 1.3.2 AGP slot................5 1.4 Jumpers..................6 1.5 Connectors..................8 1.5.1 Rear panel connectors............8 1.5.2 Internal connectors............9...
Page 2: Notices
This equipment generates, uses and can radiate • Seek professional assistance before using an adapter or extension radio frequency energy and, if not installed and used in accordance with cord. These devices could interrupt the grounding circuit.
Page 3: Specification Summary
specification summary* specification summary Socket 478 for Intel Pentium 4 Northwood/Willamette BIOS features 2Mb Flash EEPROM, DMI, features, SM BIOS 2.3, processor WfM 2.0, ASUS CrashFree BIOS, ASUS EZ Flash, and Intel Hyper-Threading technology ready ASUS C.P.U. (CPU Parameter Recall) New power design for next generation Intel Prescott CPU Industry standard PCI 2.2, USB 2.0/1.1...
Page 4: Central Processing Unit(Cpu)
1.1 Central Processing Unit (CPU) 1.1.1 Overview 1.1.2 Installing the CPU The Intel Pentium 4 processor has a gold triangular mark on one corner. This Follow these steps to install a CPU. Mark indicates the processor Pin 1 that should match a specific corner of the CPU socket Locate the 478-pin ZIF socket on the motherboard.
Page 5: System Memory
1.2 System memory Table 1 Qualified DDR400 vendors list 1.2.1 DIMM sockets location This table lists the memory modules that have been tested and qualified for use with this motherboard. The following figure illustrates the location of the DDR DIMM sockets. Size Vendor Part Number...
Page 6: Expansion Slots
Jumpers Expansion slots Clear RTC RAM (CLRTC1) PCI slots This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters The PCI slots support PCI cards such as a LAN card, SCSI card, USB card, and by erasing the CMOS RTC RAM data.
Page 7: Connectors
USB device wake-up (3-pin USBPW12, USBPW34, USBPW56) Connectors Set these jumpers to +5V to wake up the computer from S1 sleep mode (CPU stopped, DRAM refreshed, system running in low power mode) using the This section describes and illustrates the motherboard rear panel and internal connected USB devices.
Page 8: Internal Connectors
1.5.2 Internal connectors ATX power connectors (20-pin ATXPWR1, 4-pin ATX12V1) These connectors connect to an ATX 12V power supply. The plugs from the IDE connectors (40-1 pin PRI_IDE1, SEC_IDE1) power supply are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit.
Page 9 CPU and chassis fan connectors (3-pin CPU_FAN1, CHA_FAN1) Digital audio connector (4-1 pin SPDIF_OUT1) The fan connectors support cooling fans of 350mA~740mA (8.88W max.)or a In addition to the S/PDIF Out port on the rear panel, an S/PFIF Out connector is available for an S/PDIF audio module.
Page 10 Speaker out connector (4-pin SPEAK1) Power LED Lead (3-1 pin LED1) This connector connects to the case-mounted speaker and allows you to hear This 3-1 pin connector is for the system power LED. Connect the 3-pin power system beeps and warnings. LED cable from the system chassis to this connector.
Page 11 • Power Switch / Soft-Off Switch Lead (2-pin PWR_BTN) This connector connects a switch that controls the system power. Pressing the power switch turns the system between ON and SLEEP, or ON and SOFT OFF, depending on the BIOS or OS settings. Pressing the power switch while in the ON mode for more than 4 seconds turns the system OFF.
