NextTech 2218202 User Manual

Digital multimeter with voice readout
Hide thumbs

Advertisement

Table of Contents

Digital Multimeter With Voice Readout
2218202
User's Manual
Please Read before using this equipment.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2218202 and is the answer not in the manual?

Questions and answers

Summary of Contents for NextTech 2218202

  • Page 1 Digital Multimeter With Voice Readout 2218202 User’s Manual Please Read before using this equipment.

  • Page 2: A Word About Safety

    Digital Multimeter With Voice Readout 2218202 Features Your LCD Digital talking Multimeter is a portable, compact multimeter that is ideal for field, shop, and home applications.This Multimeter can display up to 4, 000 units. It measures AC voltage up to 750 V, DC voltage up to 1000 V, and resistance up to 40 M.

  • Page 3: Special Panel Markings

    Digital Multimeter With Voice Readout 2218202 • If the meter requires repair, do not try to adjust it yourself. Take it to your local electronics store. Special panel markings For your safety, we have added special markings to the meter’s panel to remind you of the measurement limitations.

  • Page 4: Specifications

    Digital Multimeter With Voice Readout 2218202 “Talking/Back Light” key: This key is on the RED test-lead. Pressing this key for less than 1.5 seconds and the meter will announce the result. If the key is held for more than 1.5 seconds, the meter will be lit for 30 seconds.
  • Page 5 Digital Multimeter With Voice Readout 2218202 4.000 Volts 3.999 Volts 1m Volts 1.8 % FS, ±5 Counts Resistance Range Max. Reading Resolution Accuracy 40.00 M Ω 39.99 M Ω 10 K Ω 1.0 % FS, ±5 Counts 1 4.000 M Ω...

  • Page 6: Installing The Battery

    Digital Multimeter With Voice Readout 2218202 PREPARATION Installing the battery Your meter requires 3 AA batteries (not included). • To avoid electrical shock, disconnect both of the meter’s test leads from any equipment before you install or remove the meter’s battery.

  • Page 7: Measuring Ac Voltage Riding On A Dc Source Bias

    Digital Multimeter With Voice Readout 2218202 voltage appears. 4. If you want the meter to announce the test result, press the switch on the red test lead for less than 1.5 seconds. If you want the meter to be alluminated press the switch on the red test lead for more than 1.5 seconds, and the meter will be lit for 30 seconds.

  • Page 8: Continuity Sound Test

    Digital Multimeter With Voice Readout 2218202 1. Position the selector switch on the OHM/DIODE/CONTINUE and press the “FUNCTION” key. to change the meter to the diode function. 2. Remove power from the circuit under test. 3. Connect the test leads across the circuit you want to measure, or remove one of the component’s leads you want to measure from its circuit and connect the test leads across the...
  • Page 9 Digital Multimeter With Voice Readout 2218202 warranty. If your meter is not performing as it should, take it to your local electronics store for assistance. Cleaning To keep the meter looking new, occasionally wipe it with a cloth slightly dampened with water. Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the meter.
