Page 2: Table Of Contents
Inhalt Introduction ....................4 Prerequisites ....................5 Individual Parts .................... 7 Assembly of the height adjustment ............9 4.1 Prepare the threaded rods ..............9 4.2 Insertion of threaded rods (1) .............. 9 4.2 Inserting the threaded rods (2) ............10 4.3 Attach the first stainless steel inlays .......... - Page 3 Montage Footboard (optional) ..............20 7.1 Insert vertical strut (conjunction) ............21 7.2 Insert side strut .................. 21 7.3 Adjusting the foot part ................ 22 7.4 Mounting of the foot ................23 Models for Children - Baby chair and Model M ........23 8.1 Baby chair ..................
-
Page 4: Introduction
Introduction Create with your TRAUMSCHWINGER (dream swing) a favorite place, a perso- nal Oasis in your home, in the garden, on the balcony or at your workplace. You will notice that ceilings, ceiling beams, loft beds, roof- and balcony projections, conservatories, pergolas, stable branches as well as wide doorframes diverse op- portunities to place the chair. -
Page 5: Prerequisites
SAFETY NOTICE Our TRAUMSCHWINGER - hanging chairs are resting as well as relaxing furniture. They are not to be used as trainers and/or play area. If you notice damage of the material (e.g. cracks), the product should not be used any- more. - Page 6 Wall distance Suspension height Net/ Model Load max. (min./ max.) min. 1,8 m / 4,0 m 65 cm Babyschwinger (als Kindermöbel 75 kg 1,2 m / 3m) Modell M 1,5 m / 3,0 m 75 kg 65 cm Modell L...
-
Page 7: Individual Parts
Individual Parts In the following two pictures as well as table you will see a summary of the delivery parts of TRAUMSCHWINGER Weaving net made of cotton Rope bag universal Wooden transverse strut Wooden side strut, 2 piece Only available in versions: „Set“ or „Set Plus“. For models XXL and XXL extra large all wooden struts are of the same length. - Page 8 All items shown on this page are only included when you buy a TRAUM- SCHWINGER in the version „Set“ or „Set plus“. For the others versions this can be purchased as an accessory item. 1) Wooden panel (x 2) 6) Stainless steel socket (x 2) 2) Stainless steel inserts (x 2) 7) Allen wrench 3) Carabiner...
-
Page 9: Assembly Of The Height Adjustment
Assembly of the height adjustment The first part for mounting your TRAUMSCHWINGER forms of assembling of the supplied height adjustment. For this you need the items from the box of height adjustment and the swivel. The required Tool (an Allen key) is enclosed. The mounting of the height adjustment can be most easily done, when sitting at a table. -
Page 10: Inserting The Threaded Rods (2)
4.2 Inserting the threaded rods (2) 4.3 Attach the first stainless steel inlays Now place your free hand on the Take one of the stainless steel inlays. three round nuts to prevent them A colored sticker marks the side of the from slipping and turn with your stainless steel inlays, which should be hand the wooden panel The side... -
Page 11: Attach The Stainless Steel Bushings
4.4 Attach the stainless steel 4.5 Inserting the steel pin into the bushings wooden wedge On the threaded rod into the top Now take the wooden wedge and the of the triangular wooden panel insert steel pen into your hand. Run the the stainless steel socket with a steel pin through the hole in the extent groove. -
Page 12: Placing The Wood Wedge Over The Stainless Steel
4.6 Placing the wood wedge over 4.7 Attach the second noble steel the stainless steel inlay inlay Place now the wooden wedge, Take the second stainless steel inlay which is inserted already with the in your hand. Grasp the stainless imported steel pin with smooth sides steel inlay so, that with the label on the already mounted stainless... -
Page 13: Attaching The Second Wooden Panel
4.8 Attaching the second wooden 4.9 Screw down and tighten the panel round nuts Take the second wooden panel. Now screw the three remaining With a colored sticker marked side round nuts with the three threaded of the wooden wedge must lie on rods, which are placed in the holes of the second stainless steel inlay with the second wooden panel. -
Page 14: Insertion Of The Carabiner
4.10 Insertion of the carabiner 4.11 Finished height adjustment Take the supplied carabiner and Please use both supplied Allen keys place it in the stainless steel bush to make sure that all metal parts are with the groove (on the upper side of properly tightened. -
Page 15: Connecting The Netting With The Height Adjustment
Connecting the netting with the height adjustment Next you connect the netting of your TRAUMSCHWINGER with the height adjustment. Due to the fact that you have to spread the netting in front of you, we recommend you put a blanket on the floor. The height adjustment you should place next to you. -
Page 16: Insert The Rope Ends And Jam Them
5.2 Insert the rope ends and jam them On delivery, the track ropes can be twisted in themselves and each other, because of material and manufacturing conditions. Prior to inserting the rope ends in the height adjustment, you need to make sure that the support ropes are not twisted in itself and into each other. - Page 17 Now drag with your left hand the rope Now take the height adjustment so pair trough the right hand, without to in your right hand, the wood wedge twist the ropes. If you reach the end almost half inserted into the height of the rope, grab around.
-
Page 18: Netting Hang Up And Span
Netting hang up and span In this section you will finished assembling your TRAUMSCHWINGER For this you will need the height adjustment connected with the netting, the vertical wood and the two side wood, the rope bag and a ladder. 6.1 Netting to hang up with height adjustment Hang the connected height adjustment with the swivel into the prepared (resp. -
Page 19: Insert Side Strut
WRONG RIGHT SAFETY NOTICE If the suspension ropes lay on each other or are twisted, this can increase wear of the ropes through damage to the rope surface. Do not use sharp objects to the rope pair to push into the recess. This may damage the surface of the rope, and can interfere with the carrying capacity of the cables. -
Page 20: Attaching The Rope Bag
6.4 Attaching the rope bag As a final step you bring the rope bag between the two rope pairs above the cross of wood. Hang on the universal case with the two adjustable straps. For the motive bags (sun and sheep) you should made a knot in order to attach the cords. -
Page 21: Insert Vertical Strut (Conjunction)
7.1 Insert vertical strut (conjunction) Spread the netting in front of you so, that the label is in the upper right corner. One of the supplied wooden struts is longer than the other two. This is the vertical conjunction wood. RIGHT WRONG Ensure that the ropes running down from... -
Page 22: Adjusting The Foot Part
7.3 Adjusting the foot part Following pull the rope on the other Take the rope as in Fig. 1, and pull a side. loop of approximately 50 cm in length (depending on the mounting height of the hanging chair). Note: You can adjust the length of the Pull on the rope end as shown in FIG. -
Page 23: Mounting Of The Foot
Models for Children - BABYSCHWINGER and Model M With these models, you should adjust the height of the BABYSCHWINGER so that your child can swing freely just above the ground. In addition, it´s recommen- ded to place some damping material on the ground (1.5 m wide). Please note that hanging chairs as well as cradles are not for rocking and are no toy equipments. -
Page 24: Baby Chair
8.1 BABYSCHWINGER BABYSCHWIN- While the models M to XXL essentially differ only by the size, the has a separate web form. Head- and foot side of the net are pulled up (see figure) to secure your child against falling out. -
Page 25: Usage Of Your Traumschwinger
Usage of your TRAUMSCHWINGER You will find in this section various information about usage and maintenance your TRAUMSCHWINGER. SAFETY NOTICE If you notice damage of the material (e.g. cracks), the product may not be used anymore. When an infant or toddler is placed in the netting, a cloth must be placed underneath at least. -
Page 26: Washing Instructions
9.3 Washing instructions Prepare: First, remove the lateral and side struts and take out the TRAUMSCHWINGER. Loose the netting of the height adjustment. Spread the netting and lay the track ropes curled up on the netting. Fold the netting so that the support ropes completely enclosed with the netting. -
Page 27: Adjusting The Seat Height
9.4 Adjusting the seat height With the height adjustment, you can personally setting the optimum seat height of your TRAUMSCHWINGER. We recommend to adjusting the seat height so, that the bottom edge of the netting rests in the knees when you are under the suspension point. To adjust the height you access with each of your hand the rope pairs below the height adjustment. - Page 28 MIRAART® GmbH Bünderstraße 21 33613 Bielefeld fon: +49 521 66545 mail: info@mira-art.de web: www.mira-art.de shop: www.traumschwinger.de...
