Summary of Contents for Wayne-Dalton WDHKC-50
- Page 1 Certification Exhibit FCC ID: KJ8-0003177 IC: 3540A-0003177 FCC Rule Part: 15.249 IC Radio Standards Specification: RSS-210 ACS Report Number: 09-0189-15C Manufacturer: Wayne-Dalton Corporation Model: WDHKC-50 Manual 5015 B.U. Bowman Drive Buford, GA 30518 USA Voice: 770-831-8048 Fax: 770-831-8598...
- Page 2 Room Key Controller Model: WDHKC-50 Description The Room Key Controller is a battery operated Generic Z-Wave controller capable of triggering one Z-wave scene with up to 230 devices. When a generic room key card is inserted in the card slot, the Z-Wave scene triggers. The controller then goes to sleep to save batteries.
- Page 3 To set the custom temperatures, simply power up the thermostat to be added to the network and set the modes at the desired temperatures. This must be done before adding the thermostat to the Room Key Controller. The Room Key Controller will grab the temperature set points from the thermostat when it is added to the network.
- Page 4 Installation 1. Cut a hole in the wall at the desired mounting location with the measurements listed in figure 1 FIGURE 1 2. Use appropriate hardware to mount wall bracket aligned with the hole in the wall. Make sure the smooth side of the wall bracket is facing the wall and the rib side is facing out.
- Page 5 Z-Wave Setup NOTE: The Room Key Controller supports the following Z-Wave functions. Add Z-Wave Node to Scene with Level and promote to primary (when • adding controllers). Remove Node from Scene and Network. • Factory Reset. • Join existing network with scenes. •...
- Page 6 US and Foreign patents pending. Z-Wave® is a registered trademark of Zen-sys Corporation. Wayne-Dalton® is a registered trademark of Wayne-Dalton Corporation. FCC Regulatory Information NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 7 , y compris l’interférence qui peut causer l’opération peu désirée. WARNING : Changes or modifications to this receiver not expressly approved by Wayne-Dalton Corp. could void the user’s authority to operate this equipment © Copyright 2009 Wayne-Dalton Corp.
