Summary of Contents for Test Instrument Solutions SafetyPAT

  • Page 1 SafetyPAT P/N:110401103862...
  • Page 2 Test Instrument Solutions SafetyPat Instructions A. Features - SafetyPat The SafetyPat is a handheld battery powered unit suitable for carrying out electrical safety tests Features include; ● 110v, 230v,415V Equipment ( 110V & 415V BY Optional Adaptor ) Class 1 Equipment ●...
  • Page 3 Please check your unit fully upon opening and in the unlikely event anything is missing, report this immeadiately Open the package case and take out the Meter. Check the following items carefully to see any missing or damaged component * SafetyPat 1piece * Instruction Book 1 piece...
  • Page 4 C. Safety Please read the following instructions carefully before use Please inspect your SafetyPat and accessories before use. Do not use the Unit and accessories if they are damaged in anyway,as this may result in an electrical shock. Replace the battery as soon as the battery indicator “...
  • Page 5 Warning Signs used within this manual Danger-Caution, risk of electric shock. Indicates instructions must be followed to avoid danger to persons or equipement Warning-Caution, risk of danger. The operating instructions must be adhered to in order to avoid danger。 D. Product Outlook & Diagrams Diagram 1 Shows layout of instrument...
  • Page 6: Testing Procedures

    Diagram 2 Shows layout of instrument 1.Press “ ” to switch on/off the meter (A) Mains socket on front panel (B) (A) button Class I button (C) (B) button Class II button (D) (C) button Cord, IEC & Extension Lead (E) LCD Display (F) Socket on rear end panel for connection of earth test lead (G) Socket on rear end panel for main cord testing...
  • Page 7: Surge Test

    3:Press (C) button,Cord / Extension Lead Test 4:Press any other buttons matrix without functions. 5:Automatic switch off after approximately 2 minutes if no any buttons are pressed 6:The auto switch off is disabled during a power socket test 1. 250V. Surge Test Press “...
  • Page 8 3. Flash Indication 3.1 Under Earth Continuity test, solid “√” shows if protective conductor resistance falls within 0.01Ω~0.1Ω; “√” flashes for the resistance value between “0.10Ω~0.50Ω” and “×” displays for the range between “0.51Ω~19.9Ω”. 3.2 With Earth Continuity, Insulation Resistance tests all completed, the Meter would show “FAIL”if one of these items displays “×”If the meter displays “PASS”...
  • Page 9 The pass band on the SafetyPat is set up to include 0.5 of an ohm, a failure could be because you are testing an appliance with a long lead, having a resistance greater than 0.5 of an ohm, this would be why the appliance/...
  • Page 10 (See Diagram 3 connections) NOTE having no earth would appear on the display as × Earth Cont ×FAIL flash once you have found a good earthing point, re-test by pressing Class I button NOTE If the measured value is of a low load it will be displayed as“ ”This could mean that the appliance has a low load or that the fuse has blown, however the most come fault is that the appliance under test has not been switched on.
  • Page 11: Testing A Class-2 Appliance

    5. Testing a CLASS-2 Appliance Plug the appliance into the panel main socket. Switch on the appliance . If there is exposed metal on the appliance eg. chuck of a drill then plug the earth test lead into the socket (F) on the rear end panel. Connect the earth crocodile clip or probe to any exposed part on the appliance,...
  • Page 12 dust, especially if it hasn’t been used for some time, try cleaning the item or connecting to power for a short time to burn off any moisture, then re-test The final result will be displayed as PASS or FAIL 6. Testing a mains cord (IEC) & Extension Lead Plug the IEC Lead plug into the 13a socket on the tester, link the end of the IEC lead into the connection at the rear of the tester.
  • Page 13: Checking A Mains Power Outlet

    open circuits or reversed connections and it displays as “√”or“×” and displays “PASS or FAIL” as the final result NOTE When testing Extension Leads it should be noted that this tester has a Pass Level of up to 0.5 of an ohm. Indicated as a Pass or Fail, Some extension leads may have, because of their length more than 0.5 of an ohm in resistance.
  • Page 14: Maintenance

    If the Live and Neutral in the socket wiring is reversed or there is a fault with the protective earth connection this will be indicated as follows “LN√,LE×,NE×” If there is a fault with the Neutral connection this will be indicated: “LN×,LE √,NE×”...
  • Page 15 they rotate, this is to ensure a good contact, sometimes a protective film is applied to new batteries which can prevent good contact when first fitted We recommend that if the unit is not used for over 2 to 3 weeks that the batteries are removed from the unit. Any contamination of the battery contacts or compartment should be cleaned with a dry cloth.
  • Page 16: Warranty

    11. Warranty The Warranty period is 2 years from date of purchase, proof of purchase is required in the form of a copy of your original invoice, before any repair is carried out under this warranty. To obtain your 2 year warranty, it is a condition to have your instrument Calibrated at the start of year two by Test Instrument Calibrations, you will then receive your second year guarantee.
  • Page 17: Environmental Condition

    12. Environmental Condition Operating temperature range 0℃ to 40℃,without moisture condensation。 Storage temperature range 0 to 40C Batteries must be removed prior to storage。 13. Main Technical Parameters Earth Continuity Range 0.00Ω to 19.99Ω Pass Limit 0.01Ω -0.1Ω solid Pass Only 0.1Ω...
  • Page 18 Insulation Resistance Pass Limit CLASS Ⅰ: >1M ohms CLASS Ⅱ: >2M ohms CORD: >1M ohms Range 0.20MΩ - 19.99MΩ Test Voltage 500V Test Current 500k:﹥1mA 1K: ﹤2 mA Test Time 5 Seconds Cord Test/ Ext. Lead Correct √ PASS Open Circuit ×...
  • Page 19 Mains Socket Test Good Show LN√ LE√ NE√ Ground Show LN√ LE× NE× NE (NG) Show LN× LE√ NE× Batteries AA 1.5V x 8 Low Voltage < 9V ClassⅠ ClassⅡ Cord Earth Continuity <0.5ohms <0.5ohm Insulation >1.0Mohms >2.0 Mohms >1.0 Mohms Resistance Remark: Earth Continuity Resistance 0.5Ω...
