M&O ELECTRONICS
MOOH-BE00BT
USER MANUAL
Warnings ........................................................................ 2
FCC and environmental protection compliance .............. 4
Instructions for product usage ...................................
Product features ..............................................
Product specifications ................................................... 15
Limited product warranty .....................................
Beryllium
Acoustic
CPSIA COMPLIANT
M&O Electronics, Inc.
support@mo-electronics.com
www.mo-electronics.com
(+1) 888-65-MandO
2880 Zanker Road, Suite 203, San Jose, CA 95134, USA
Made in China
R
RoHS
2011/65/EU
page 1
..
.
......... 14
..
..
....
..
..
Bluetooth
P
H
b
g
mercury-free
lead- free
.
. 5
..
.. 17
R
Advertisement
Table of Contents
Summary of Contents for M&O Electronics MOOH-BE00BT
- Page 1 M&O ELECTRONICS MOOH-BE00BT USER MANUAL Warnings ................ 2 FCC and environmental protection compliance ....4 Instructions for product usage ........Product features ............14 Product specifications ........... 15 Limited product warranty ......... .. 17 Beryllium Bluetooth Acoustic RoHS...
- Page 2 Warnings (Read before product usage) Thank you for purchasing this Beryllium acoustic Bluetooth headphone. Before you start using the product, you are strongly recommended to carefully read these warnings and cautions described in this section. If you ignore these warnings, you may suffer various kinds of risks including, but not limited to, abusing or misusing this device, damaging this device, damaging other devices, causing temporary or permanent ear and hearing damage, hurting people, local traffic violation, and accidents after missing verbal warning signals.
- Page 3 Do NOT put the product on the ear at a high-volume level (> 50% volume level) while you are moving to avoid missing any verbal warnings signs other people are trying to offer you. Do NOT put the product on the ear at an extremely high-volume level (> 70% volume level) or at a high-volume level (>...
- Page 4 FCC and environmental protection compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference; and (2) this FCC ID: 2ALHGOHBE00BT device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Package Contents
2880 Zanker Road, Suite 203, San Jose, CA 95134, USA Made in China page 1 Bluetooth Headphone User Manual Headphone EVA Box (Warnings, FCC and environment protection (Beryllium Acoustic) (Hardness 70 degrees) compliance, Instructions for product usage, Product features, Product specifications, MODEL: MOOH-BE00BT Limited Product Warranty) page 5... -
Page 6: Product Overview
Product overview Bluetooth Headphone (Beryllium Acoustic) MODEL: MOOH-BE00BT Buttons, indication lights and ports on the product 2 Micro-B charging port Stereo audio cable port Volume - / Fast reverse Power on/off, pairing Music play/pause Status indication light Volume + / Fast forward... - Page 7 Bluetooth audio device; b) this product’s pairing name “MOOH-BE00BT” is listed in the audio device’s Bluetooth system as a paired device; c) the audio device is working and ready for accepting a Bluetooth connecting request;...
- Page 8 Bluetooth devices. This product’s pairing name “MOOH-BE00BT” shall be added into the list of those available devices to be connected in the audio device Bluetooth device manager system as a response to this product’s pairing request.
- Page 9 Bluetooth Pairing and connecting with Bluetooth device Bluetooth transmission mode shall be turned off via pressing on the power button for more than 5 seconds. Then, four series of short beep sounds shall present in a descending tone and the status indication light turns red before the system shuts down itself and stops Bluetooth audio transmission.
-
Page 10: Listening To Music
Listening to music Printed letter “R” or “L” Put on this product and be aware of the indicating the right or the unit’s direction. The right unit fits the right left unit ear, and the left unit the left ear. The unit direction shall be identified by printed letter “R”... -
Page 11: Making A Phone Call
Listening to music in the operating MODE B- passive audio operation mode When this product works in the passive audio operation mode, it acts as a passive audio speaker, and all the music play functions are only provided by the audio device connected via a 3.5 mm audio cable included in the product package. -
Page 12: Receiving A Phone Call
Receiving a phone call Answer a call by pressing and releasing the button #4. Reject a call by pressing and holding the button #4 for 3 seconds Adjust the volume of phone talk by pressing and releasing the button #3 or #5. Phone talk in the operating mode B- passive audio operation mode When this product works in the passive audio operation mode, it acts as a passive audio speaker, and all the phone call functions are only provided by the audio device connected... -
Page 13: Charging The Device
Charging the device 5V DC USB power supplies Power Bank Micro-USB Charging Cable The charging process of this product starts when connecting it to a 5 V DC USB power supply, which is implemented by plugging the included micro-USB charging cable into the charging cable port of this product and the USB port of the 5 V DC USB power supply. -
Page 14: Product Features
Product features Major features Beryllium acoustic is a feature of clean, accurate, and stable acoustic. Beryllium is a relatively rare element on earth and in the Universe, and outstanding for high stiffness to density ratio, good strength to density ratio, high velocity of sound, and high Debye temperature. -
Page 15: Product Specifications
Class II, +4 dBm max. Receiver sensitivity: -80 dBm Maximum communication range: Line of sight - more than 10 m (33 ft) Name to pair with Bluetooth devices: MOOH-BE00BT Pass-code possibly required when pairing with devices 0000 below Bluetooth version 2.0: Electroacoustic Specifications... - Page 16 Electroacoustic Specifications (continued) 20 Hz 50 Hz 100 Hz 200 Hz 500Hz 106+/-5 109+/-5 104+/-5 101+/-4 101+/-5 sensitivity Transducer (dB SPL/mW) 20KHz 2 KHz 10 KHz 1 KHz 5 KHz 99+/-3 98+/-4 94+/-6 105+/-6 98+/-6 electret 4015 omnidirectional microphone frequency response: 100 Hz to 10 KHz Microphone impedance 2.2 Kohms, sensitivity: -42+/-4 dB SPL/mW...
-
Page 17: Limited Product Warranty
Others (continued) Others (continued) When battery charge is less than 10% left, indication light flashes red and a verbal warning signal presents every minute from then on. After around 10 to 30 more Low battery warnings before minutes in normal Bluetooth transmission system shutdown: mode, depending on conditions of audio operation, less than 6% battery charge is left... - Page 18 The users are responsible for the payment of this product’s shipping cost, insurance, or transportation charges from the users to us, or any import fees, duties, and taxes. OUR MAXIMUM LIABILITY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID BY YOU FOR THE PRODUCT. IN NO EVENT SHALL WE BE LIABLE FOR INCIDENTAL, CONSEQUENTIAL, OR INDIRECT DAMAGES.
