SAT>IP™ Wi-Fi Dongle
User manual
www.selfsat.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SELFSAT-IPD30A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SELFSAT SELFSAT-IPD30A

  • Page 1 SAT>IP™ Wi-Fi Dongle User manual www.selfsat.com...
  • Page 2: Safety Notes

    Safety Notes • As the product of wireless device, there may be difference in performance after the usage environment. • Read thoroughly the manual before use. • Do not touch the device during operations to avoid risk of burns. • Keep the device unplugged if unused.
  • Page 3: Table Of Contents

    Contents 1. SAT>IP Wi-Fi Dongle • Specification / Components ............. . . •...
  • Page 4: Sat>Ip Wi-Fi Dongle

    1. SAT>IP Wi-Fi Dongle • Specification SELFSAT-IPD30A Model name ARM Cortex A5 833MHz 512MB / 2.5GB System / FLASH Memory SELFSAT SAT>IP RCU application Input device / Bluetooth remote controller HDMI 1.4 Audio/Video Output Wi-Fi 802.11n, 2.4 / 5GHz Dual Band Wi-Fi Bluetooth 4.0...
  • Page 5: Name Of Parts - Sat>Ip Wi-Fi Dongle

    • Name of parts – SAT>IP Wi-Fi Dongle Protective Rubber Pull the rubber to take out HDMI connector and micro USB power port HDMI connector Connect the device to HDMI port of TV Micro USB power port To supply power to the device Air vent Discharge heat during operation LED lamp...
  • Page 6: Operation Diagram Of Sat>Ip Wi-Fi Dongle

    √ SELFSAT>IP antenna and Wi-Fi AP are not included. √ If SELFSAT>IP antenna is not used for the connection, [SAT>IP server, antenna, SAT>IP Wi-Fi Dongle and Wi-Fi AP] are required instead. √ SAT>IP Dongle and Bluetooth remote control in the package are 1:1 paired for initial operation.
  • Page 7: Sat>Ip Wi-Fi Dongle Preparation

    Example①, ② ③ Make sure that required equipment and AP’s network ID/password are prepared to add SAT>IP Wi-Fi Dongle to the Wi-Fi network. W-Fi AP must be the one connected from SELFSAT>IP antenna which is pointing the satellite. √ In case TV/monitor outputs below than 1A(1,000mA), an operation may not be smooth due to lack of power.
  • Page 8: Wi-Fi Setting Of Bluetooth Remote Control

    (recommended) → Enter password → press “Connection” button. If there is no security option, input Wi-Fi name and press “Connection” button. √ Wi-Fi AP must be the one connected from SELFSAT>IP antenna which is pointing the satellite. √ SAT>IP function is fully manageable by Bluetooth remote control but other entertainment functions and setting of the device will need “SELFSAT SAT>IP RCU”, relative mobile application.
  • Page 9: Main Function - Sat>Ip

    Red key to see available SAT>IP server list and choose one to connect. ③ Press Green key to select one satellite that SELFSAT>IP antenna is pointing among all listed. ④ Default channel of the satellite will be shown. ⑤ Press...
  • Page 10: Entertainment Functions

    4. Entertainment functions If Wi-Fi AP is not available to use, go to “Setting” >”Set up system” >”Phone to TV / SlideShow mode” and change from “Router” to “Direct” to enjoy entertainment functions. SmartShare connection To watch contents of mobile devices, connected in same AP, using DLNA function.
  • Page 11: Sat>Ip Wi-Fi Dongle Settings

    5. SAT>IP Wi-Fi Dongle settings Setting Set and change options of the device . Select desire Wi-Fi for initial connection or change to a new. • Set up Wi-Fi : Scan/pair with available Bluetooth device. • Set up Bluetooth : Adjust the screen size using up/down/left/right buttons.
  • Page 12: Remote Control Application For Android

    “SELFSAT SAT>IP RCU”, relative mobile application. • Remote control application for Android ① Download “SELFSAT SAT>IP RCU” at Google Play Store. ② Run downloaded application and SAT>IP Wi-Fi Dongle will be auto-detected.
  • Page 13: Name Of Parts - Remote Control Application

    • Name of parts – Remote control application Power : ON / OFF Home : Go to the main screen Direction key : Up/Down/Left/Right OK : Perform the selected menu Volume : Adjust volume Channel : Move to other channels Color key** : For custom usage of occasions LANG* : Change to other language Touch pad : Touch pad/Keyboard inputs...
  • Page 14: Troubleshooting For Bluetooth Remote Control

    √ To re-connect of Bluetooth remote control and SAT>IP Wi-Fi Dongle, “SELFSAT SAT>IP RCU” has to be downloaded and paired to SAT>IP Wi-Fi Dongle in advance. ① Select “Setting” > “Set up Bluetooth” at main screen to see available devices to be connected.
  • Page 15: Common Q & A

    7. Common Q & A • No HDMI ports at TV/monitor – Additional purchase of HDMI to RGB(analog) converter is required to use the device. – Converter with external power supply port is recommended for stable operation. • Contents is not playing or TV/monitor is flashing or “No signal” is shown –...
