DQ Technology M505NR2 User Manual

Four-port adsl 2+ wireless router
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Four-port ADSL 2+
Wireless Router
User Manual
Ver 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M505NR2 and is the answer not in the manual?

Questions and answers

Related Manuals for DQ Technology M505NR2

Summary of Contents for DQ Technology M505NR2

  • Page 1 Four-port ADSL 2+ Wireless Router User Manual Ver 1.0...

  • Page 2: Table Of Contents

    Contents Safety Precautions ..................1 Overview ......................2 Application ..................2 Features ....................2 Standards Compatibility and Compliance ..........3 Hardware Description and Hardware Installation ..........5 Hardware Description ................5 3.1.1 Front Panel ................5 3.1.2 Rear Panel ................6 Hardware Installation ................
  • Page 3 5.2.6 Parental Control ..............67 5.2.7 Quality of Service ..............68 5.2.8 Routing ................... 71 5.2.9 DNS ..................73 5.2.10 DSL ................... 74 5.2.11 UPnP ................. 75 5.2.12 DNS Proxy ................ 76 5.2.13 Packet Acceleration ............76 5.2.14 Interface Grouping ............. 77 5.2.15 Multicast ................

  • Page 4: Safety Precautions

    1 Safety Precautions Read the following information carefully before operating the device. Please follow the following precaution items to protect the device from risks and damage caused by fire and electric power:  Use volume labels to mark the type of power. ...

  • Page 5: Overview

    2 Overview The DSL Router is a highly ADSL2+ Integrated Access Device and can support ADSL link with downstream up to 24 Mbps and upstream up to 1 Mbps. It is designed to provide a simple and cost-effective ADSL Internet connection for a private Ethernet or 802.11g/802.11b/802.11n wireless network.

  • Page 6: Standards Compatibility And Compliance

     Several pre-configured popular games. Just enable the game and the port settings are automatically configured.  Compatible with all standard Internet applications  Industry standard and interoperable DSL interface  Simple web-based status page displays a snapshot of system configuration, and links to the configuration pages ...
  • Page 7  ITU G.992.3 (ADSL2)  ITU G.992.5 (ADSL2+)  ANSI T1.413 Issue 2  IEEE 802.3  IEEE 802.3u  IEEE 802.11b  IEEE 802.11g  IEEE 802.11n...

  • Page 8: Hardware Description And Hardware Installation

    3 Hardware Description and Hardware Installation 3.1 Hardware Description 3.1.1 Front Panel Figure 1 Front panel The following table describes the indicators on the front panel. Indicator Color Status Description Green Power is on. Power is on and the device is initiating.

  • Page 9: Rear Panel

    Indicator Color Status Description Ethernet interface disconnected. Green WLAN is enabled. Data is being transmitted through the WLAN Green Blink wireless interface. WLAN is disabled. Connection succeeds under Wi-Fi Green Protected Setup. Negotiation is in progress under Green Blink Wi-Fi Protected Setup. Wi-Fi Protected Setup is disabled.

  • Page 10: Hardware Installation

    Interface Description device. USB port, for connecting the storage devices. Power Power interface, for connecting the power adapter. Power switch Warning: Do not press the Reset button unless you want to clear the current settings. The Reset button is in a small circular hole on the rear panel. If you want to restore the default settings, please press the Reset button gently for 1 second with a fine needle inserted into the hole and then release the button.
  • Page 11 Step3 Plug one end of the power adapter to the wall outlet and connect the other end to the Power port of the DSL Router. The followig figure displays the connection of the DSL router, PC, and telephones. Figure 3 Connecting the DSL router...

  • Page 12: Pc Network Configuration And Login

    4 PC Network Configuration and Login 4.1 PC Network Configuration Each network interface on the PC should either be configured with a statically defined IP address and DNS address, or be instructed to automatically obtain an IP address using the network DHCP server. DSL router provides a DHCP server on its LAN and it is recommended to configure your LAN to automatically obtain its IP address and DNS server IP address.
  • Page 13 Figure 4 IP and DNS configuration TCP/IP configuration steps for Windows XP are as follows: Step1 Choose Start > Control Panel > Network Connections. Step2 Right-click the Ethernet connection icon and choose Properties. Step3 On the General tab, select the Internet Protocol (TCP/IP) component and click Properties.

  • Page 14: Logging In To The Dsl Router

    Step5 Select the Obtain an IP address automatically radio button. Step6 Select the Obtain DNS server address automatically radio button. Step7 Click OK to save the settings. 4.2 Logging In to the DSL Router To log in to the DSL router, do as follows: Step1 Open a Web browser on your computer.
  • Page 15 Figure 5 Login page After logging in to the DSL router as a super user, you can query, configure, and modify all the settings, and diagnose the system.

  • Page 16: Web-Based Management

    5 Web-Based Management This chapter describes how to use Web-based management of the DSL router, which allows you to configure and control all of DSL router features and system parameters in a user-friendly GUI. 5.1 Device Information Choose Device Info, and the submenus of Device Info are shown as below: Figure 6 Submenus of device info 5.1.1 Summary Choose Device Info >...

  • Page 17: Wan

    Figure 7 Summary page This page displays the device information such as the board ID, software version, and the information of your WAN connection such as the upstream rate and the LAN IPv4 address. 5.1.2 WAN Choose Device Info > WAN and the following page appears.

  • Page 18: Statistics

    Figure 8 WAN information This page displays the information of the WAN interface, such as the connection status, IPv4 address, and connected time. 5.1.3 Statistics 5.1.4 LAN Choose Device Info > Statistics > LAN and the following page appears. Figure 9 LAN statistical information In this page, you can view the statistical information about the recevied and transmitted data packets of the Ethernet and wireless interfaces.

  • Page 19: Xtm

    Figure 10 Statistical information of WAN service In this page, you can view the statistical information about the recevied and transmitted data packets of the WAN interface. Click Reset Statistics to restore the values to zero and recount them. 5.1.6 xTM Choose Device Info >...
  • Page 21 Figure 12 xDSL statistical information In this page, you can view the statistical information about the recevied and transmitted data packets of the xDSL interfaces. Click xDSL BER Test to test the xDSL Bit Error Rate. Click Reset Statistics to restore the values to zero and recount them. xDSL BER Test Click xDSL BER Test to perform a bit error rate (BER) test on the DSL line.

  • Page 22: Route

    Figure 15 ADSL BER test result Note: If the BER reaches e-5, you cannot access the Internet. 5.1.8 Route Choose Device Info > Route and the following page appears. Figure 16 Route table In this page, you can view the route table information.

  • Page 23: Arp

    5.1.9 ARP Choose Device Info > ARP and the following page appears. Figure 17 ARP table In this page, you can view the MAC address and IP address information of the device connected to the router. 5.1.10 DHCP Choose Device Info > DHCP and the following page appears. Figure 18 DHCP list In this page, you can view the host name, the IP address assigned by the DHCP server, the MAC address this is corresponding to the IP address, and the DHCP lease...

  • Page 24: Layer2 Interface

    Figure 19 Submenus of advance setup 5.2.1 Layer2 Interface ATM Interface Choose Advanced Setup > Layer2 Interface > ATM Interface , and the following page appears.
  • Page 25 Figure 20 DSL ATM interface configuration In this page, you can add or remove the DSL ATM Interfaces. Click the Add button to display the following page. Figure 21 ATM PVC configuration In this page, you can set the VPI and VCI values, and select the DSL latency, link type (EoA is for PPPoE, IPoE, and Bridge.), connection mode, encapsulation mode, service category, and IP QoS scheduler algorithm.
  • Page 26  Select DSL Link Type: You may select EoA (it is for PPPoE, IPoE, and Bridge), PPPoA, or IPoA.  Select Connection Mode: You may select the Default Mode or the VLAN MUX Mode.  Encapsulation Mode: You may select LLC/SNAP-BRIDGING or VC/MUX in the drop-down list.
  • Page 27 Figure 23 ETH WAN interface configuration In this page, you can add or remove the ETH WAN interfaces. Click the Add button to display the following page. Figure 24 Configuring a ETH WAN interface In this page, select a ETH port and a proper connection mode, and then click the Apply/Save button to make the settings take effect.

  • Page 28: Wan Service

    Figure 25 Adding a ETH WAN interface If you want to remove this Interface, please select the Remove check box that is corresponding to the selected interface and then click the Remove button. 5.2.2 WAN Service Choose Advance Setup > WAN Service, and the following page appears. Figure 26 WAN service configuration In this page, you are allowed to add, remove, or edit a WAN service.
  • Page 29 Figure 27 WAN service interface configuration (PPPoE) Step2 In this page, you can select a ATM Interface for the WAN service. After selecting the ATM interface, click Next to display the following page.
  • Page 30 Figure 28 WAN service configuration (PPPoE) Step3 In this page, select the WAN service type to be PPP over Ethernet (PPPoE). Click Next to display the following page.
  • Page 31 Figure 29 PPP username and password (PPPoE) Step4 In this page, you can modify the PPP username, PPP password, PPPoE service name and authentication method.  PPP Username: The correct user name provided by your ISP.  PPP Password: The correct password provided by your ISP.
  • Page 32  PPPoE Service Name: If your ISP provides it to you, please enter it. If not, do not enter any information.  Authentication Method: The value can be AUTO, PAP, CHAP, or MSCHAP. Usually, you can select AUTO.  Config KeepAlive: Whether to let the PPPoE dial-up keep alive. ...
  • Page 33 Figure 30 Routing-default gateway (PPPoE) Step6 In this page, select a preferred WAN interface as the system default gateway and then click Next to display the following page.
  • Page 34 Figure 31 DNS server configuration(PPPoE) Step7 In this page, you may obtain the DNS server addresses from the selected WAN interface or manually enter the static DNS server addresses. If only a PVC with IPoA or static MER protocol is configured, you must manually enter the static DNS server addresses.
  • Page 35 Figure 32 PPPoE summary Step8 In this page, it displays the information about the PPPoE settngs. Click Apply/Save to save and apply the settings, and then the following page appears. You can modify the settings by clicking the Back button if necessary.
  • Page 36 Figure 34 WAN service interface configuration (IPoE) Step2 Select an ATM Interface, for example, atm1/(0_0_36), and then click Next to display the following page.
  • Page 37 Figure 35 WAN service configuration (IPoE) Step3 In this page, select the WAN service type to be IP over Ethernet, and r the service description. After finishing setting, click Next to display the following page.
  • Page 38 Figure 36 WAN IP settings (IPoE) Step4 In this page, you may themodify the WAN IP settings. You may select obtain an IP address automatically or manually enter the IP address provided by your ISP. Click Next and the following page appears. Note: If selecting Obtain an IP address automatically, DHCP will be enabled for PVC in MER mode.
  • Page 39 Figure 37 Network address translation settings (IPoE) Step5 In this page, you can set the network address translation settings,for example, enabling NAT, enabling firewall, and.enabling IGMP multicast. After finishing setting, click Next and the following page appears. Figure 38 Routing-default gateway (IPoE) Step6 In this page, select a preferred WAN interface as the system default gateway and then click Next to display the following page.
  • Page 40 Figure 39 DNS server configuration (IPoE) Step7 In this page, you may obtain the DNS server addresses from the selected WAN interface or manually enter static DNS server addresses. If only a PVC with IPoA or static MER protocol is configured, you must enter the static DNS server addresses.
  • Page 41 Figure 40 IPoE summary Step8 In this page, it displays the information about the IPoE settngs.Click Apply/Save to save and apply the settings, and then the following page appears. You can modify the settings by clicking the Back button if necessary.
  • Page 42 Figure 42 ATM PVC configuration (PPPoA) Step2 Select the DSL link type to be PPPoA, and select the encapsulation mode to be VC/MUX (according to the uplink equipment). After finishing setting, click the Apply/Save button to apply the setings, and the following page appears.
  • Page 43 Step3 Choose WAN Service and click Add to display the following page. Figure 44 WAN service interface configuration (PPPoA) Step4 Select the proper interface for the WAN service, and then click Next to display the following page. Figure 45 WAN service configuration (PPPoA)
  • Page 44 Step5 In this page, you may modify the service description. Click Next to display the following page. Figure 46 PPP username and password (PPPoA) Step6 In this page, you can enter the PPP username and PPP password provided by your ISP. Select the authentication method according to your requirement.
  • Page 45 Figure 47 Routing-default gateway (PPPoA) Step7 In this page, select a preferred WAN interface as the system default gateway and then click Next to display the following page.
  • Page 46 Figure 48 DNS server configuration (PPPoA) Step8 In this page, you can obtain the DNS server addresses from the selected WAN interface or manually enter the static DNS server addresses. If only a PVC with IPoA or static MER protocol is configured, you must enter the static DNS server addresses.
  • Page 47 Figure 49 PPPoA summary Step9 In this page, it displays the information about the PPPoA settngs.Click Apply/Save to apply the settings, and then the following page appears. You can modify the settings by clicking the Back button if necessary. Figure 50 Completing the settings of PPPoA WAN service Adding an IPoA WAN service This section describes the steps for adding the ipoa_0_0_38 (IPoA mode).
  • Page 48 Figure 51 ATM PVC configuration (IPoA) Step2 Select the DSL link type to be IPoA, and select the encapsulation mode to be LLC/SNAP-ROUTING (according to the uplink equipment). After finishing setting, click the Apply/Save button to display the following page. Figure 52 Adding a DSL ATM interface for IPoA service Step3 Choose WAN Service and click Add to display the following page.
  • Page 49 Figure 53 WAN service interface configuration (IPoA) Step4 Select the proper interface for the WAN service ,and then click Next to display the following page. Figure 54 WAN service configuration (IPoA)
  • Page 50 Step5 In this page, you may modify the service description. Click Next to display the following page. Figure 55 WAN IP settings (IPoA) Step6 In this page, enter the WAN IP address and the WAN subnet mask provided by your ISP and then click Next to display the following page. Figure 56 Network address translation settings (IPoA) In this page, Network Address Translation (NAT) allows you to share one Wide Area Network (WAN) IP address for multiple computers on your Local Area...
  • Page 51 Figure 57 Routing-default gateway (IPoA) Step8 In this page, select a preferred WAN interface as the system default gateway and then click Next to display the following page.
  • Page 52 Figure 58 DNS server configuration (IPoA) Step9 In this page, you should use a static DNS IP address for IPoA mode. Select the proper DNS server interface and enter the primary DNS server and the secondary DNS server. Click Next to display the following page.
  • Page 53 Figure 59 IPoA summary Step10 In this page, it displays the information about the IPoA settngs. Click Apply/Save to save and apply the settings, and then the following page appears. You can modify the settings by clicking the Back button if necessary.
  • Page 54 configuration for this WAN service.) Click the Add button to display the following page. Figure 61 WAN service interface configuration (bridge) Step2 Select the proper ATM Interface, for example atm3/(0_0_39) and then click Next to display the following page.
  • Page 55 Figure 62 WAN service configuration (bridge) Step3 In this page, you can select the WAN service type, and modify the service description. After finishing setting, click Next to display the following page. Figure 63 Bridge summary Step4 In this page, it displays the information about the bridge settngs. Click Apply/Save to save and apply the settings, and then the following page...

  • Page 56: Lan Configuration

    appears. You can modify the settings by clicking the Back button if necessary. Figure 64 Completing the settings of bridge WAN service 5.2.3 LAN Configuration Choose Advanced Setup > LAN, and the following page appears.
  • Page 57 Figure 65 LAN setup In this page, you can configure an IP address for the DSL router, enable IGMP snooping, enable the LAN side firewall, enable or disable the DHCP server, edit the DHCP option, configure the DHCP advanced setup and set the binding between a MAC address and an IP address.
  • Page 58 Configuring the Private IP Address for the DSL Router Figure 66 Configuring the IP address of the DSL router In this page, you can modify the IP address of the device. The preset IP address is 192.168.1.1. Enabling IGMP Snooping IGMP snooping enables the router to forward multicast traffic intelligently, instead of flooding all ports in the VLAN.
  • Page 59 Configuring the DHCP Server Figure 69 Setting the DHCP server If you enable the DHCP sever, the clients will automatically acquire the IP address from the DHCP server. If the DHCP server is disabled, you need to manually set the start IP address, end IP address and the lease time for the clients in the LAN.
  • Page 60 Figure 71 Configuring the DHCP60 options In this page, you can add, edit or delete the DHCP60 options. Configuring the DHCP Static IP Lease List The lease list of static IP address can reserve the static IP addresses for the hosts with the specific MAC addresses.

  • Page 61: Nat

    In this page, enter the MAC address of the LAN host and the static IP address that is reserved for the host, and then click the Apply/Save button to apply the settings. Configuring the Second IP Address and Subnet Mask for a LAN Interface In the Local Area Network (LAN) Setup page, you are allowed to set the second IP address and the subnet mask for a LAN interface.
  • Page 62 Figure 75 Virtual server setup In this page, you are allowed to add or remove a virtual server entry. To add a virtual server, do as follows: Click the Add button to display the following page. Figure 76 Adding an entry of virtual server ...
  • Page 63  External Port Start: When selecting a service, the port number will automatically be displayed. You can modify it if necessary.  External Port End: When selecting a service, the port number will automatically be displayed. You can modify it if necessary. ...
  • Page 64 Figure 78 Adding an entry of port triggering  Use interface: Select an interface that you want to configure.  Select an application: Select a proper application in the drop-down list.  Custom application: Manually define an application.  Trigger port Start: The start port number that LAN uses to trigger the open port.

  • Page 65: Security

    Note: You can use a single port number, several port numbers separated by commas, port blocks consisting of two port numbers separated by a dash, or any combination of these, for example 80, 90-140, 180. DMZ Host DMZ allows all the ports of a PC on your LAN to be exposed to the Internet. Set the IP address of the PC to be DMZ host, so that the DMZ host will not be blocked by firewall.
  • Page 66 Figure 80 Outgoing IP filtering setup By default, all outgoing IP traffic from LAN is allowed, but some IP traffic can be blocked by setting filters. In this page, you can add or remove the outgoing IP filtering rules. Click the Add button to display the following page. Figure 81 Adding an IP outgoing filtering rule In this page, you can create a filter rule to identify the outgoing IP traffic by specifying a new filter name and at least one condition.
  • Page 67 Incoming IP Filtering Setup The incoming IP filter is used to block and permit the IP packet transmisstion from the internet. Choose Security > IP Filtering > Incoming and the following page appears. Figure 82 Incoming IP filtering setup In this page, you can add or remove the incoming IP filtering rules. Click the Add button to display the following page.
  • Page 68 In this page, you can create a filter rule to identify the incoming IP traffic by specifying a new filter name and at least one condition, and you must select at least one WAN interface for the rule.  Filter Name: Set the filter name. ...
  • Page 69 Figure 84 MAC filtering setup In this page, you can add or remove the MAC filtering rule. You may change the MAC filtering policy from FORWARDED to BLOCKED by clicking the Change Policy button. Click the Add button to display the following page. Figure 85 Adding a MAC filter ...

  • Page 70: Parental Control

     Source MAC Address: Enter the source MAC address.  Frame Direction: The direction of transmission frame.  WAN Interface (Configured in bridge mode only): Select the proper WAN interface in the drop-down list. After finishing setting, click Apply/Save to save and apply the filtering rule. 5.2.6 Parental Control Time Restriction Choose Advanced Setup >...

  • Page 71: Quality Of Service

    5.2.7 Quality of Service Enabling QoS Choose Advance Setup > Quality of Service and the following page appears. Figure 88 QoS queue management configuration Select Enable QoS to enable QoS and configure the default DSCP mark. Figure 89 Enabling QoS In this page, enable the QoS function and select the default DSCP mark.
  • Page 72 If the Enable Qos checkbox is not selected, all QoS will be disabled for all interfaces. The default DSCP mark is used to mark all egress packets that do not match any classification rules. Queue Config Choose Advanced Setup > Quality of Service > Queue Config, and the following page appears.
  • Page 73 Note: The lower integer value for precedence indicates the higher priority. Click the Add button to display the following page. Figure 91 Adding a QoS queue  Name: Enter the name of QoS queue.  Enable: Enable or disable the QoS queue. ...

  • Page 74: Routing

    Figure 93 Adding a QoS classification rule In this page, enter the traffic name, select the rule order and the rule status, and specify the classification criteria and the classification results. After finishing setting, click Apply/Save to save and apply the settings. 5.2.8 Routing Default Gateway Choose Advanced Setup >...
  • Page 75 Figure 94 Default gateway setup In this page, you can modify the default gateway settings. Select a proper WAN interface in the drop-down list of Selected WAN Interface as the system default gateway. After finishing setting, click Apply/Save to save and apply the settings. Static Route Choose Advanced Setup >...

  • Page 76: Dns

    Figure 96 Adding a static routing rule  IP Version: Select the IP version to be IPv4.  Destination IP address/prefix length: Enter the destination IP address.  Interface: select the proper interface for the rule.  Gateway IP Address: The next-hop IP address. ...

  • Page 77: Dsl

    Figure 97 DNS server configuration In this page, you can select a DNS server interface from the available interfaces, manually enter the DNS server addresses, or obtain the DNS address from a WAN interface. After finishing setting, click Apply/Save to save and apply the settings. 5.2.10 Choose Advanced Setup >...

  • Page 78: Upnp

    Figure 98 DSL settings In this page, you can set the DSL settings. Usually, you do not need to modify the factory default settings. After finishing setting, click Apply/Save to save and apply the settings. 5.2.11 UPnP Choose Advanced Setup > UPnP and the following page appears.

  • Page 79: Dns Proxy

    Figure 99 UPnP configuration In this page, you can enable or disable the UPnP function. After finishing setting, click Apply/Save to save and apply the settings. 5.2.12 DNS Proxy Choose Advanced Setup > DNS Proxy and the following page appears. Figure 100 DNS proxy configuration In this page, you can enable or disable the DNS proxy function.

  • Page 80: Interface Grouping

    Figure 101 Packet Acceleration In this page, you can enable or disable Packet Flow Accelerator. After finishing setting, click Apply/Save to save and apply the settings. 5.2.14 Interface Grouping Choose Advanced Setup > Interface Grouping and the following page appears. Figure 102 Interface grouping configuration Interface grouping supports multiple ports to PVC and bridging groups.
  • Page 81 Click the Add button to display the following page. Figure 103 Adding a new interface group In this page, please follow the on-screen configuration steps to configure the parameters of the interface grouping. After finishing setting, click Apply/Save to save and apply the settings.

  • Page 82: Multicast

    5.2.15 Multicast Choose Advanced Setup > Multicast and the following page appears. Figure 104 Multicast configuration In this page, you can configure the multicast parameters of the IPv4. After finishing setting, click Apply/Save to save and apply the settings. 5.3 Wireless Choose Wireless and the submenus of Wireless are shown as below:...

  • Page 83: Basic Settings

    Figure 105 Submenus of wireless settings 5.3.1 Basic Settings Choose Wireless > Basic to display the following page.
  • Page 84 Figure 106 Wireless basic configuration This page allows you to configure the basic features of the wireless LAN interface.  Enable Wireless: Enable or disable the wireless function.  Hide Access Point: if you want to hide any access point for your router, select this option, and then a station cannot obtain the SSID through the passive scanning.

  • Page 85: Security

     Enable Wireless Multicast Forwarding (WMF): After enabling this option, the transmission quality of video service such as IPTV can be improved.  SSID: For the security reason, you should change the default SSID to a unique name.  BSSID: Display the MAC address of the wireless interface. ...
  • Page 86 Figure 107 Wireless security configuration This page allows you to configure the security features of the wireless LAN interface. In this page, you can configure the network security settings by the Wi-Fi Protected Setup (WPS) method or setting the network authentication mode. ...
  • Page 87 Figure 108 WPS setup There are 2 primary methods used in the Wi-Fi Protected Setup: - PIN entry, a mandatory method of setup for all WPS certified devices. - Push button configuration (PBC), an actual push button on the hardware or through a simulated push button in the software.
  • Page 88 Figure 109 Manual setup AP - Open Mode Figure 110 Open mode  Select SSID: Select a SSID for configuring the security settings.  Network Authentication: Select the Open mode.
  • Page 89  WEP Encryption: Enable or disable WEP encryption. After enabling this function, you can set the encryption strength, current network key, and network keys.  Encryption Strength: You can set 64-bit or 128-bit key.  Current Network Key: The current key that you use. ...
  • Page 90 Figure 112 802.1x mode  Select SSID: Select a SSID for configuring the security settings.  Network Authentication: Select the 802.1X in the drop-down list.  RADIUS Server IP Address: Enter the IP address of the RADIUS server. RADIUS server is used to authenticate the hosts on the wireless network. ...
  • Page 91 Figure 113 WPA mode  Select SSID: Select a SSID for configuring the security settings.  Network Authentication: Select the WPA-PSK mode.  WPA Group Rekey Interval: Setting the interval for renewing key.  RADIUS Server IP Address: Enter the IP address of the RADIUS server. RADIUS server is used to authenticate the hosts on the wireless network.
  • Page 92 Figure 114 WPA-PSK mode  Select SSID: Select a SSID for configuring the security settings.  Network Authentication: Select the WPA-PSK mode.  WPA/WAPI passphrase: The key for WPA encryption. Click the Click here to display button to display the current key. The default key is 87654321. ...
  • Page 93 Figure 115 WPA2 Mode  Select SSID: Select a SSID for configuring the security settings.  Network Authentication: Select the WPA2 mode.  WPA2 Preauthentication: Enable or disable pre-authentication.  Network Re-auth Interval: Set the network re-auth interval.  WPA Group Rekey Interval: Setting the interval for renewing key. ...
  • Page 94 Figure 116 WPA2-PSK mode The parameters’ description of WPA2-PSK mode, please refer to the WPA-PSK mode. - Mixed WPA2/WPA Figure 117 Mixed WPA2/WPA...

  • Page 95: Mac Filter

    The parameters’ description of Mixed WPA2/WPA mode, please refer to the WPA2 mode. - Mixed WPA2/WPA-PSK Figure 118 Mixed WPA2/WPA-PSK mode The parameters’ description of Mixed WPA2/WPA-PSK mode, please refer to the WPA-PSK mode. 5.3.3 MAC Filter Choose Wireless > MAC Filter to display the following page.
  • Page 96 Figure 119 MAC filter configuration This page is used to allow or reject the wireless clients to access the wireless network of the wireless router. In this page, you can add or remove the MAC filters. The MAC restrict modes include Disabled, Allow, and Deny. ...

  • Page 97: Wireless Bridge

    Figure 120 Adding a MAC filter In this page, enter the MAC address of the wireless client, and then click the Apply/Save button to add the MAC address to the MAC address list. 5.3.4 Wireless Bridge Choose Wireless > Wireless Bridge to display the following page. Figure 121 Wireless bridge configuration This page allows you to configure the wireless bridge features of the wireless LAN interface.
  • Page 98 Figure 122 Wireless advanced settings This page allows you to configure the advanced features of the wireless LAN interface. Usually, you do not need to change the settings in this page. Note: The advanced wireless setting is only for the advanced user. For the common user, do not change any settings in this page.

  • Page 99: Station Info

    5.3.6 Station Info Choose Wireless > Station Info to display the following page. Figure 123 Station information This page shows the authenticated wireless stations and their status. 5.4 Diagnostics Choose Diagnostics, and the following page appears.

  • Page 100: Management

    Figure 124 Diagnostics configuration This page is used to test the connection to your local network, the connection to your DSL service provider, and the connection to your Internet service provider. You may diagnose the connection by clicking the Test button or click the Test With OAMF4 button.

  • Page 101: Settings

    Figure 125 Submenus of management 5.5.1 Settings Backup Choose Management > Settings > Backup to display the following page. Figure 126 Backup settings In this page, click the Backup Settings button to save your router’s settings to your local PC. Update Choose Management >...

  • Page 102: System Log

    Figure 127 Update settings In this page, click the Browse… button to select the correct new settings file, and then click the Update Settings button to update the router’s settings. Restore Default Choose Management > Settings > Restore Default to display the following page. Figure 128 Restoring the default settings In this page, click the Restore default settings button, and then system returns to the default settings.
  • Page 103 Figure 130 Viewing the system log In this page, you can view the system log. Click the Refresh button to refresh the system log. Click the Close button to exit.  Configuring the System Log Click the Configure System Log button to display the following page. Figure 131 Configuring the system log In this page, you can set 3 types of system log modes, including Local, Remote, and Both.

  • Page 104: Client

    Note: If you want to log all the events, you need to select the Debugging log level. 5.5.3 TR-69 Client Choose Management > TR-069Client to display the following page. Figure 132 TR-069 client configuration WAN Management Protocol (TR-069) allows a Auto-Configuration Server (ACS) to perform auto-configuration, provision, collection, and diagnostics to this device.
  • Page 105 Figure 133 Time settings In this page, you may configure the router to synchronize its time with the Internet time servers. After enabling Automatically synchronize with Internet time servers, the following page appears.

  • Page 106: Access Control

    Figure 134 Setting the time server In this page, set the proper time servers, and then click the Apply/Save button to save and apply the settings. 5.5.5 Access Control Passwords Choose Management > Access Control > Passwords, and the following page appears.

  • Page 107: Update Software

    Figure 136 Services control In this page, you can enable or disable the different types of services. After finishing setting, click the Apply/Save button to save and apply the settings. Note: The WAN information is not displayed in the bridge mode. 5.5.6 Update Software Choose Management >...

  • Page 108: Reboot

    Figure 137 Updating software If you want to upload the software, click the Browse… button to choose the new software, and then click the Update Software button. Note: When software update is in progress, do not shut down the router. After software update completes, the router automatically reboots.
  • Page 109 6 Q&A (1) Q: Why all the indicators are off? A: Check the following:  The connection between the power adaptor and the power socket.  The status of the power switch. (2) Q: Why the LAN indicator is off? A: Check the following: ...

  • Page 110: Fcc Information

    FCC Information This equipment complies with CFR 47, Part 15.19 of the FCC rules. Operation of the equipment is subject to the following conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation.
  • Page 111 Regulatory information / Disclaimers Installation and use of this Wireless LAN device must be in strict accordance with the instructions included in the user documentation provided with the product. Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user’s authority to operate the equipment.
  • Page 112 FCC Part 68 Statement This equipment complies with part 68 of the FCC rules. On the rear panel of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for the equipment. If requested, this information must be provided to the telephone company.The REN is used to determine the quantity of devices which may be connected to the telephone line.
