HDMI Switch User Manual
)
(Model: SF501 & 4K501
© 2016 Lakesen International Inc. All rights reserved.
Rasfox is a registered trademark of Lakesen International Inc. All other trade names and logos are
registered trademarks of respective manufacturers.
www.lakesen.com www.rasfox.com
Support Email: support@lakesen.com
____________________________________________________________________________________
HDMI Switch
Page 1
Advertisement
Table of Contents
Related Manuals for Rasfox SF501 & 4K501
Summary of Contents for Rasfox SF501 & 4K501
- Page 1 HDMI Switch User Manual (Model: SF501 & 4K501 © 2016 Lakesen International Inc. All rights reserved. Rasfox is a registered trademark of Lakesen International Inc. All other trade names and logos are registered trademarks of respective manufacturers. www.lakesen.com www.rasfox.com Support Email: support@lakesen.com...
-
Page 2: Table Of Contents
Table of Contents Important Safety Instructions ------------------------------------------ 3 Introduction ------------------------------------------------------------------ 4 Understand the Unit ------------------------------------------------------- 4 How to Setup ----------------------------------------------------------------- 5 Operation -----------------------------------------------------------------------6 Specifications --------------------------------------------------------------- 7 FAQ Frequently Asked Questions ----------------------------------- 8 Warranty ---------------------------------------------------------------------- 10 ... -
Page 3: Important Safety Instructions
Important Safety Instructions Please read instructions carefully before operation 1. To prevent risk of electric shock, do not remove the cover from the unit. Refer all servicing to qualified service personnel only. 2. Do not use the converter near water. 3. -
Page 4: Introduction
Introduction The Rasfox HDMI Switch enables up to five HDMI source devices ( such as DVD player, cable box, gaming consoles, Apple TV, and Sky WDTV console etc .) to be connected to a single HDMI input port on your HDTV or projector. It can be used to expand the number of HDMI ports on any HDMI devices. -
Page 5: How To Setup
How to Setup 1. Take an HDMI cable and plug one end into the HDMI input port on HDTV or projector. Plug the other end into the output HDMI port on the switch. 2. Take another HDMI cable and plug one end into the HDMI output port on one of your media device or gaming console. -
Page 6: Operation
Operation Automatic Input Selection: When the switch is powered on for the first time, it senses input ports automatically and switches to the input port source automatically in the sequence 1->2->3->4->5… It bypasses input ports without signal. When a new device is turned on, the switch will detects and selects that input channel automatically. - Page 7 Note: Some source devices stay in a stand-by mode can always maintain a connection with the switch and keep its HDMI port active This non-compliant behavior does not allow the switch to perform its auto switching. In this case, you have to select your input channel by panel button or remote control manually.
-
Page 8: Specifications
Specifications For Model SF501: HDMI Version 1.3b HDMI Signal 480P, 480i, 576P, 720P, 1080I, 1080P @ 50&60Hz HDCP Compatible Pass-through DTS / DTS-HD, Dolby Digital/Dolby TrueHD, Linear PCM Audio Compatible (LPCM) Support 250Mhz/2.5 Gbps per channel MAX bandwidth 3D Compatible Power supply AC(50/60Hz)100V~240V input, DC5V 1A output Operating temperature... -
Page 9: Faq Frequently Asked Questions
FAQ Frequently Asked Questions 1. What devices is the Rasfox HDMI switch compatible with? For model SF501: This switch should work well with any media source device with HDMI (version 1.3b) output. Most media devices out there in the market are compliant with HDMI 1.3b or earlier standards, such as HD-DVD players, PS3, Xbox360 and most Blu-Ray players. - Page 10 4) Test with just one input device. Check if the input device works directly with the TV. This will also help verify the HDMI cable. If you continue to have problems, please contact us by email: contact@lakesen.com. We are always happy to help. More questions? Please check www.rasfox.com/blog HDMI to AV Converter Page 10...
-
Page 11: Warranty
Warranty 1 Year Limited Hardware Warranty. Lakesen hereby warrants to the customer of record that this product is in good-working condition and free from defects in material or workmanship under normal use for a duration of 1 year after the date of purchase. The product has been tested to meet the highest quality standards in each testing category. -
Page 12: Contact Us
Contact US You can reach our support by writing to support@lakesen.com. You may also visit www.rasfox.com www.rasfox.com/blog for more information. HDMI to AV Converter Page 12... - Page 13 Made In China HDMI to AV Converter Page 13...
