Overview
This is a digital HD (high definition) video camera recorder with the most
advanced technology; this device is a common HD video camera as well as a
professional driving recorder. It can record the high resolution image with the
pixel as high as 2560X1080P/30fps ,2304X1296P/30fps,1920X1080P/60fps
FULL HD and take the picture of 4 mega pixels. Using TF card as the storage
device, compact size, low power consumption, HD camcorder can record
more detailed perfect video image. Video also can be transferred by HDMI
transmission wire directly to the high quality LED TV (HDMI) for high
resolution displaying.
Enjoy true high-definition lift by using this product.
- 1 -
Advertisement
Table of Contents
Summary of Contents for RM Acquisition CAM300
- Page 1 Overview This is a digital HD (high definition) video camera recorder with the most advanced technology; this device is a common HD video camera as well as a professional driving recorder. It can record the high resolution image with the pixel as high as 2560X1080P/30fps ,2304X1296P/30fps,1920X1080P/60fps FULL HD and take the picture of 4 mega pixels.
- Page 2 Feature Product features: ◎ 170 degree ultra wide angle lens. ◎2560X1080P/30fps, 2304X1296P/30fps, 1920X1080P/60fps FULL HD high quality resolution. ◎ Equipped with low light sensor, can get good video quality at night. ◎ Advanced H.264 video compression technology. ◎ 4 mega pixels. ◎...
-
Page 3: Product Structure
Product Structure External GPS HDMI Photo/Delete Reset Rec/OK Micro TF Power/ Ligths Mode Right /Microphone/ Fast Left/Slow/ Screensaver Speaker Lens... -
Page 4: External Gps
External GPS Slide rail + card buckle: Install: position the DVR and the sliding rail of the GPS, sliding inside until you hearing a sound. USB port connecting to car charger The connection of external GPS is as belo ： Remarks... -
Page 5: Key Functions
When power on, GPS auto search satellite. No GPS positioning, LCD screen display dynami c lower left corner of the yellow icon ; GPS positioning, LCD screen shows a Key Functions green icon on the lower left corner. (Optional) MODE Key: to shift video recording, playback mode, system settings. To lock or unlock the file during recording. -
Page 6: Operation
Operation Load and unload the battery 1. Battery indicators as below: Full Half Empty Battery Recharge 2. This device can be charged through connecting the USB terminal of computer as well as connecting charger. Connect to 12V/24V car charger as driving recorder When used as driving recorder, it is required to turn on the Circulating Video Recording and Automatic Video Recording Upon Start On, at the same time, connect it with the car charger, when the vehicle engine is on, It will start video recording automatically;... - Page 7 Operation 1. Press the power key for 1 second to turn on/off the device. 2. For saving the power capacity of battery, to set the automatic off time in the menu, the device will turn off automatically when not any operation on the video recorder. Camcorder Mode 1.
- Page 8 Operation Language：set language. TV out：NTSC/PAL. Auto off：set idle time to power off the device. Format：Format the TF card. Stamp: Video recording/pictures whether add into the time and date, customer logo and speed info. Date：Use up or down key to change the digits and press OK to go to next item. Auto LCD off Time: set the time auto turn off the LCD screen;...
-
Page 9: Specifications
Specifications 4M CMOS sensor，1/3 inch light-sensing surface area Sensor 4 fixed focus Lens, aperture 2.0, focus 3.4mm Lens 2.7inch 16:9 TFT LCD Zoom LCD display Terminal: composite TV signal output NTSC/PAL High definition TV terminal interface: HDMI signal output. Max 1920X1080i50 or 1920X1080i60 AV (CVBS) Picture PG file format Maximum output pixel: 12.0 mega pixels... - Page 10 Warning Notice Cannot take pictures or video clips. Check the TF card whether it’s locked or has insufficient space. Stop recording half way. Please check whether your TF card supports high-speed transmission (marked with C10). “File error” pops up in playback mode. Please format the TF card.
- Page 11 GPS Player Install Instruction： (1) Firmware Installation Install the “Driver.exe” at CD disk. (2) Play the video Double-click the “Player.exe”，select the file and play it.
- Page 12 FCC Statement: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
